状态: Active Compliance: Pb A H P Channels: 1 Input Level: ECL Output Level: TTL VCC Typ (V): 3.3 fMax Typ (MHz): 350 tpd Typ (ns): 1.5 tR & tF Max (ps): 950 Package Type: SOIC-8 MSL Type: 1 MSL Temp (°C): 260 ON Target: N Reference Price: Price N/A

状态: Active, Not Rec Compliance: Pb A H P Channels: 10 Input Level: TTL Output Level: ECL VCC Typ (V): 3.3 fMax Typ (MHz): 1500 tpd Typ (ns): 0.5 tR & tF Max (ps): 450 Package Type: LQFP-32 MSL Type: 2 MSL Temp (°C): 260 ON Target: Y Reference Price: Price N/A

状态: Active Compliance: Pb A H P Channels: 3 Input Level: ECL Output Level: ECL VCC Typ (V): 3.3 fMax Typ (MHz): 650 tpd Typ (ns): 0.5 tR & tF Max (ps): 500 Package Type: SOIC-20W MSL Type: 3 MSL Temp (°C): 260 ON Target: N Reference Price: Price N/A

状态: Active Compliance: Pb A H P Channels: 1 Input Level: TTL Output Level: ECL VCC Typ (V): 3.3 fMax Typ (MHz): 1000 tpd Typ (ns): 0.37 tR & tF Max (ps): 225 Package Type: SOIC-8 MSL Type: 1 MSL Temp (°C): 260 ON Target: N Reference Price: Price N/A

Bootstrap supply voltage (max) (V): 120 Power switch: MOSFET Input supply voltage (min) (V): 8 Input supply voltage (max) (V): 17 Peak output current (A): 4 Operating temperature range (°C): -40 to 150 Undervoltage lockout (typ) (V): 8 Rating: Catalog Propagation delay time (µs): 0.02 Rise time (ns): 7.2 Fall time (ns): 5.5 Iq (mA): 0.001 Input threshold: TTL Channel input logic: TTL Switch node voltage (V): -20 Features: Negative voltage handling Driver configuration: Dual, Noninverting, TTL compatible Bootstrap supply voltage (max) (V): 120 Power switch: MOSFET Input supply voltage (min) (V): 8 更多

Vs ABS (max) (V): 20 Peak output current (A): 0.4 Rating: Military Operating temperature range (°C): 0 to 0 Vs ABS (max) (V): 20 Peak output current (A): 0.4 Rating: Military Operating temperature range (°C): 0 to 0

Input Vcc max: 20.0V Channels: 6.0 Configuration: Three Phase Voltage Class: 600.0V Qualification: Industrial Output Current(Source): 0.25A Output Current(Sink): 0.5A Turn Off Propagation Delay: 700.0ns Turn On Propagation Delay: 750.0ns V[CC] UVLO(Off): 8.2V V[CC] UVLO(On): 8.6V V[BS] UVLO(Off): 8.2V V[BS] UVLO(On): 8.6V Isolation Type: Functional levelshift JI (Junction Isolated)

Number of full bridges: 2 Vs (min) (V): 4.5 Vs ABS (max) (V): 50 Full-scale current (A): 2.5 Peak output current (A): 4 RDS(ON) (HS + LS) (mΩ): 330 Sleep current (µA): 2 Control mode: STEP/DIR Control interface: Hardware (GPIO) Microstepping levels: 256 Rating: Automotive Operating temperature range (°C): -40 to 125 Number of full bridges: 2 Vs (min) (V): 4.5 Vs ABS (max) (V): 50 Full-scale current (A): 2.5 Peak output current (A): 4 RDS(ON) (HS + LS) (mΩ): 330 Sleep current (µA): 2 Control mode: STEP/DIR 更多

Bootstrap supply voltage (max) (V): 120 Power switch: MOSFET Input supply voltage (min) (V): 8 Input supply voltage (max) (V): 17 Peak output current (A): 4 Operating temperature range (°C): -40 to 150 Undervoltage lockout (typ) (V): 8 Rating: Catalog Propagation delay time (µs): 0.02 Rise time (ns): 7.2 Fall time (ns): 5.5 Iq (mA): 0.001 Input threshold: TTL Channel input logic: TTL Switch node voltage (V): -20 Features: Enable, Negative voltage handling Driver configuration: Dual, Noninverting, TTL compatible Bootstrap supply voltage (max) (V): 120 Power switch: MOSFET Input supply voltage (min) (V): 8 更多

Technology family: HC Supply current (max) (µA): 200 Rating: Space Operating temperature range (°C): 25 to 25 Technology family: HC Supply current (max) (µA): 200 Rating: Space Operating temperature range (°C): 25 to 25
