Function: Differential Additive RMS jitter (typ) (fs): 171 Output frequency (max) (MHz): 800 Number of outputs: 4 Output supply voltage (V): 2.5 Core supply voltage (V): 2.5 Output skew (ps): 15 Features: Dual 1:2 fanout, Output enable control, Universal inputs Operating temperature range (°C): -40 to 85 Rating: Catalog Output type: LVDS Input type: LVCMOS, LVDS, LVPECL Function: Differential Additive RMS jitter (typ) (fs): 171 Output frequency (max) (MHz): 800 Number of outputs: 4 Output supply voltage (V): 2.5 Core supply voltage (V): 2.5 Output skew (ps): 15 Features: Dual 1:2 fanout, Output enable control, Universal inputs 更多

Function: Single-ended Additive RMS jitter (typ) (fs): 70 Output frequency (max) (MHz): 250 Number of outputs: 10 Output supply voltage (V): 2.5, 3.3 Core supply voltage (V): 2.5, 3.3 Output skew (ps): 50 Features: 1:10 fanout, Output enable control Operating temperature range (°C): -40 to 85 Rating: Catalog Output type: LVCMOS Input type: LVCMOS Function: Single-ended Additive RMS jitter (typ) (fs): 70 Output frequency (max) (MHz): 250 Number of outputs: 10 Output supply voltage (V): 2.5, 3.3 Core supply voltage (V): 2.5, 3.3 Output skew (ps): 50 Features: 1:10 fanout, Output enable control 更多

Function: Single-ended Additive RMS jitter (typ) (fs): 70 Output frequency (max) (MHz): 250 Number of outputs: 8 Output supply voltage (V): 2.5, 3.3 Core supply voltage (V): 2.5, 3.3 Output skew (ps): 50 Features: 1:8 fanout, Output enable control Operating temperature range (°C): -40 to 85 Rating: Catalog Output type: LVCMOS Input type: LVCMOS Function: Single-ended Additive RMS jitter (typ) (fs): 70 Output frequency (max) (MHz): 250 Number of outputs: 8 Output supply voltage (V): 2.5, 3.3 Core supply voltage (V): 2.5, 3.3 Output skew (ps): 50 Features: 1:8 fanout, Output enable control 更多

Function: Single-ended Additive RMS jitter (typ) (fs): 70 Output frequency (max) (MHz): 250 Number of outputs: 6 Output supply voltage (V): 2.5, 3.3 Core supply voltage (V): 2.5, 3.3 Output skew (ps): 50 Features: 1:6 fanout, Output enable control Operating temperature range (°C): -40 to 85 Rating: Catalog Output type: LVCMOS Input type: LVCMOS Function: Single-ended Additive RMS jitter (typ) (fs): 70 Output frequency (max) (MHz): 250 Number of outputs: 6 Output supply voltage (V): 2.5, 3.3 Core supply voltage (V): 2.5, 3.3 Output skew (ps): 50 Features: 1:6 fanout, Output enable control 更多

Function: Single-ended Additive RMS jitter (typ) (fs): 70 Output frequency (max) (MHz): 250 Number of outputs: 3 Output supply voltage (V): 2.5, 3.3 Core supply voltage (V): 2.5, 3.3 Output skew (ps): 50 Features: 1:3 fanout, Output enable control Operating temperature range (°C): -40 to 85 Rating: Catalog Output type: LVCMOS Input type: LVCMOS Function: Single-ended Additive RMS jitter (typ) (fs): 70 Output frequency (max) (MHz): 250 Number of outputs: 3 Output supply voltage (V): 2.5, 3.3 Core supply voltage (V): 2.5, 3.3 Output skew (ps): 50 Features: 1:3 fanout, Output enable control 更多

Function: Single-ended Additive RMS jitter (typ) (fs): 70 Output frequency (max) (MHz): 250 Number of outputs: 4 Output supply voltage (V): 2.5, 3.3 Core supply voltage (V): 2.5, 3.3 Output skew (ps): 50 Features: 1:4 fanout, Output enable control Operating temperature range (°C): -40 to 85 Rating: Catalog Output type: LVCMOS Input type: LVCMOS Function: Single-ended Additive RMS jitter (typ) (fs): 70 Output frequency (max) (MHz): 250 Number of outputs: 4 Output supply voltage (V): 2.5, 3.3 Core supply voltage (V): 2.5, 3.3 Output skew (ps): 50 Features: 1:4 fanout, Output enable control 更多

Function: Single-ended Additive RMS jitter (typ) (fs): 70 Output frequency (max) (MHz): 250 Number of outputs: 12 Output supply voltage (V): 2.5, 3.3 Core supply voltage (V): 2.5, 3.3 Output skew (ps): 50 Features: 1:12 fanout, Output enable control Operating temperature range (°C): -40 to 85 Rating: Catalog Output type: LVCMOS Input type: LVCMOS Function: Single-ended Additive RMS jitter (typ) (fs): 70 Output frequency (max) (MHz): 250 Number of outputs: 12 Output supply voltage (V): 2.5, 3.3 Core supply voltage (V): 2.5, 3.3 Output skew (ps): 50 Features: 1:12 fanout, Output enable control 更多

Function: Single-ended Additive RMS jitter (typ) (fs): 370 Output frequency (max) (MHz): 52 Number of outputs: 2 Output supply voltage (V): 1.8 Core supply voltage (V): 1.8 Output skew (ps): 500 Features: 1:2 fanout Operating temperature range (°C): -40 to 85 Rating: Catalog Output type: SQUARE Input type: SINE, SQUARE Function: Single-ended Additive RMS jitter (typ) (fs): 370 Output frequency (max) (MHz): 52 Number of outputs: 2 Output supply voltage (V): 1.8 Core supply voltage (V): 1.8 Output skew (ps): 500 Features: 1:2 fanout 更多

Function: Single-ended Additive RMS jitter (typ) (fs): 300 Output frequency (max) (MHz): 52 Number of outputs: 4 Output supply voltage (V): 1.8 Core supply voltage (V): 1.8 Output skew (ps): 50 Features: SINE wave Operating temperature range (°C): -40 to 85 Rating: Catalog Output type: SINE Input type: SINE Function: Single-ended Additive RMS jitter (typ) (fs): 300 Output frequency (max) (MHz): 52 Number of outputs: 4 Output supply voltage (V): 1.8 Core supply voltage (V): 1.8 Output skew (ps): 50 Features: SINE wave 更多

Function: Differential Additive RMS jitter (typ) (fs): 57 Output frequency (max) (MHz): 2000 Number of outputs: 8 Output supply voltage (V): 2.5, 3.3 Core supply voltage (V): 2.5, 3.3 Output skew (ps): 20 Features: 2:8 fanout Operating temperature range (°C): -40 to 85 Rating: Catalog Output type: LVPECL Input type: LVCMOS, LVDS, LVPECL Function: Differential Additive RMS jitter (typ) (fs): 57 Output frequency (max) (MHz): 2000 Number of outputs: 8 Output supply voltage (V): 2.5, 3.3 Core supply voltage (V): 2.5, 3.3 Output skew (ps): 20 Features: 2:8 fanout 更多
