状态: 已停产 Compliance: Pb A H P Type: Unidirectional Channels: 1 Input Level: CMOS VCCA Min (V): 3 VCCA Max (V): 18 VCCB Min (V): 3 VCCB Max (V): 18 IO Max (mA): 4.2 ICC Max (μA): - tpd Max (ns): 340 Data Rate (Mbps): - TA Min (°C): -55 TA Max (°C): 125 Package Type: SOIC-16 MSL Type: 1 MSL Temp (°C): 260 ON Target: No 参考价格: Price N/A

状态: 已停产 Compliance: Pb A H P Type: Unidirectional Channels: 1 Input Level: CMOS VCCA Min (V): 3 VCCA Max (V): 18 VCCB Min (V): 3 VCCB Max (V): 18 IO Max (mA): 4.2 ICC Max (μA): - tpd Max (ns): 340 Data Rate (Mbps): - TA Min (°C): -55 TA Max (°C): 125 Package Type: TSSOP-16 MSL Type: 1 MSL Temp (°C): 260 ON Target: No 参考价格: Price N/A

状态: 量产中 Compliance: Pb A H P Type: Bidirectional Channels: 8 Input Level: TTL VCCA Min (V): 4.5 VCCA Max (V): 5.5 VCCB Min (V): 2.7 VCCB Max (V): 3.6 IO Max (mA): 24 ICC Max (μA): 80 tpd Max (ns): 5.5 Data Rate (Mbps): n/a TA Min (°C): -40 TA Max (°C): 85 Package Type: TSSOP-24 MSL Type: 1 MSL Temp (°C): 260 ON Target: No 参考价格: $0.5507

状态: 量产中 Compliance: Pb A H P Type: Bidirectional Channels: 8 Input Level: TTL VCCA Min (V): 4.5 VCCA Max (V): 5.5 VCCB Min (V): 2.7 VCCB Max (V): 3.6 IO Max (mA): 24 ICC Max (μA): 80 tpd Max (ns): 5.5 Data Rate (Mbps): n/a TA Min (°C): -40 TA Max (°C): 85 Package Type: SOIC-24 MSL Type: 3 MSL Temp (°C): 260 ON Target: No 参考价格: $0.5851

Technology family: AXC Applications: RGMII Bits (#): 8 High input voltage (min) (V): 0.455 High input voltage (max) (V): 3.6 Vout (min) (V): 0.65 Vout (max) (V): 3.6 Data rate (max) (Mbps): 380 IOH (max) (mA): -12 IOL (max) (mA): 12 Supply current (max) (µA): 60 Input type: Standard CMOS Output type: 3-State, Balanced CMOS, Push-Pull Rating: Automotive Operating temperature range (°C): -40 to 125 Technology family: AXC Applications: RGMII Bits (#): 8 High input voltage (min) (V): 0.455 High input voltage (max) (V): 3.6 更多

Technology family: AXC Applications: I2S, JTAG, SPI, UART Bits (#): 4 High input voltage (min) (V): 0.455 High input voltage (max) (V): 3.6 Vout (min) (V): 0.65 Vout (max) (V): 3.6 Data rate (max) (Mbps): 310 IOH (max) (mA): -12 IOL (max) (mA): 12 Supply current (max) (µA): 40 Input type: Standard CMOS Output type: 3-State, Balanced CMOS, Push-Pull Rating: Catalog Operating temperature range (°C): -40 to 125 Technology family: AXC Applications: I2S, JTAG, SPI, UART Bits (#): 4 High input voltage (min) (V): 0.455 High input voltage (max) (V): 3.6 更多

Technology family: AXC Applications: JTAG, SPI, UART Bits (#): 4 High input voltage (min) (V): 0.455 High input voltage (max) (V): 3.6 Vout (min) (V): 0.65 Vout (max) (V): 3.6 Data rate (max) (Mbps): 380 IOH (max) (mA): -12 IOL (max) (mA): 12 Supply current (max) (µA): 20 Input type: Standard CMOS Output type: 3-State, Balanced CMOS, Push-Pull Rating: Catalog Operating temperature range (°C): -40 to 125 Technology family: AXC Applications: JTAG, SPI, UART Bits (#): 4 High input voltage (min) (V): 0.455 High input voltage (max) (V): 3.6 更多

Technology family: AXC Applications: JTAG, SPI, UART Bits (#): 4 High input voltage (min) (V): 0.455 High input voltage (max) (V): 3.6 Vout (min) (V): 0.65 Vout (max) (V): 3.6 Data rate (max) (Mbps): 380 IOH (max) (mA): -12 IOL (max) (mA): 12 Supply current (max) (µA): 40 Input type: Standard CMOS Output type: 3-State, Balanced CMOS, Push-Pull Rating: Catalog Operating temperature range (°C): -40 to 125 Technology family: AXC Applications: JTAG, SPI, UART Bits (#): 4 High input voltage (min) (V): 0.455 High input voltage (max) (V): 3.6 更多

Technology family: AXC Applications: GPIO Bits (#): 1 High input voltage (min) (V): 0.455 High input voltage (max) (V): 3.6 Vout (min) (V): 0.65 Vout (max) (V): 3.6 Data rate (max) (Mbps): 500 IOH (max) (mA): -12 IOL (max) (mA): 12 Supply current (max) (µA): 14 Input type: Standard CMOS Output type: 3-State, Balanced CMOS, Push-Pull Rating: Catalog Operating temperature range (°C): -40 to 125 Technology family: AXC Applications: GPIO Bits (#): 1 High input voltage (min) (V): 0.455 High input voltage (max) (V): 3.6 更多

Technology family: LSF Applications: I2C, MDIO, SMBus Bits (#): 4 Data rate (max) (Mbps): 100 High input voltage (min) (V): 0.9 High input voltage (max) (V): 5.5 Vout (min) (V): 0.9 Vout (max) (V): 5.5 IOH (max) (mA): 0 IOL (max) (mA): 0 Supply current (max) (µA): 0.01 Features: Output enable Input type: Transmission Gate Output type: 3-State, Transmission Gate Rating: Automotive Operating temperature range (°C): -40 to 125 Technology family: LSF Applications: I2C, MDIO, SMBus Bits (#): 4 Data rate (max) (Mbps): 100 更多
