TXS0108E

数据:
分类: 微电路 / 半导体集成电路 / 接口电路 / 电平转换器

描述: 适用于开漏和推挽应用的八位双向电压电平转换器

Technology family: TXS Applications: I2C, MDIO, SMbus Bits (#): 8 Data rate (max) (Mbps): 100 High input voltage (min) (V): 1 High input voltage (max) (V): 5.5 Vout (min) (V): 1.4 Vout (max) (V): 5.5 IOH (max) (mA): 0 IOL (max) (mA): 0 Supply current (max) (µA): 8 Features: Edge rate accelerator, Output enable, Vcc isolation Input type: Transmission Gate Output type: 3-State, Transmission Gate Rating: Catalog Operating temperature range (°C): -40 to 125 Technology family: TXS Applications: I2C, MDIO, SMbus Bits (#): 8 Data rate (max) (Mbps): 100 更多

High input voltage (min) (V): 1 High input voltage (max) (V): 5.5 Vout (min) (V): 1.4 Vout (max) (V): 5.5 IOH (max) (mA): 0 IOL (max) (mA): 0 Supply current (max) (µA): 8 Features: Edge rate accelerator, Output enable, Vcc isolation Input type: Transmission Gate Output type: 3-State, Transmission Gate Rating: Catalog Operating temperature range (°C): -40 to 125

TXS0101

数据:
分类: 微电路 / 半导体集成电路 / 接口电路 / 电平转换器

描述: 适用于漏极开路和推挽应用的 1 位双向电压电平转换器

Technology family: TXS Bits (#): 1 Data rate (max) (Mbps): 24 High input voltage (min) (V): 1.45 High input voltage (max) (V): 5.5 Vout (min) (V): 1.65 Vout (max) (V): 5.5 IOH (max) (mA): 0 IOL (max) (mA): 0 Supply current (max) (µA): 14.4 Input type: Transmission Gate Output type: 3-State, Transmission Gate Rating: Catalog Operating temperature range (°C): -40 to 85 Technology family: TXS Bits (#): 1 Data rate (max) (Mbps): 24 High input voltage (min) (V): 1.45 High input voltage (max) (V): 5.5 Vout (min) (V): 1.65 更多

Vout (max) (V): 5.5 IOH (max) (mA): 0 IOL (max) (mA): 0 Supply current (max) (µA): 14.4 Input type: Transmission Gate Output type: 3-State, Transmission Gate Rating: Catalog Operating temperature range (°C): -40 to 85

TXB0102

数据:
分类: 微电路 / 半导体集成电路 / 接口电路 / 电平转换器

描述: 具有自动方向感应和 +/-15kV ESD 保护的 2 位双向电压电平转换器

Technology family: TXB Applications: GPIO, SPI, UART Bits (#): 2 Data rate (max) (Mbps): 100 High input voltage (min) (V): 0.78 High input voltage (max) (V): 5.5 Vout (min) (V): 1.2 Vout (max) (V): 5.5 IOH (max) (mA): -0.02 IOL (max) (mA): 0.02 Supply current (max) (µA): 8 Input type: Standard CMOS Output type: 3-State, CMOS, Push-Pull Rating: Catalog Operating temperature range (°C): -40 to 85 Technology family: TXB Applications: GPIO, SPI, UART Bits (#): 2 Data rate (max) (Mbps): 100 High input voltage (min) (V): 0.78 更多

High input voltage (max) (V): 5.5 Vout (min) (V): 1.2 Vout (max) (V): 5.5 IOH (max) (mA): -0.02 IOL (max) (mA): 0.02 Supply current (max) (µA): 8 Input type: Standard CMOS Output type: 3-State, CMOS, Push-Pull Rating: Catalog Operating temperature range (°C): -40 to 85

SN74LVCC4245A-EP

数据:
分类: 微电路 / 半导体集成电路 / 接口电路 / 电平转换器

描述: 增强型产品，具有可配置输出电压和三态输出的八路双电源总线收发器

Technology family: LVC Bits (#): 8 High input voltage (min) (V): 2 High input voltage (max) (V): 5.5 Vout (min) (V): 2.7 Vout (max) (V): 5.5 Data rate (max) (Mbps): 200 IOH (max) (mA): -24 IOL (max) (mA): 24 Supply current (max) (µA): 130 Features: Output enable Input type: Standard CMOS Output type: 3-State, Balanced CMOS, Push-Pull Rating: HiRel Enhanced Product Operating temperature range (°C): -55 to 125 Technology family: LVC Bits (#): 8 High input voltage (min) (V): 2 High input voltage (max) (V): 5.5 Vout (min) (V): 2.7 更多

Vout (max) (V): 5.5 Data rate (max) (Mbps): 200 IOH (max) (mA): -24 IOL (max) (mA): 24 Supply current (max) (µA): 130 Features: Output enable Input type: Standard CMOS Output type: 3-State, Balanced CMOS, Push-Pull Rating: HiRel Enhanced Product Operating temperature range (°C): -55 to 125

TXB0101

数据:
分类: 微电路 / 半导体集成电路 / 接口电路 / 电平转换器

描述: 具有自动方向感应和 +/-15kV ESD 保护的 1 位双向电压电平转换器

Technology family: TXB Bits (#): 1 Data rate (max) (Mbps): 100 High input voltage (min) (V): 0.78 High input voltage (max) (V): 5.5 Vout (min) (V): 1.2 Vout (max) (V): 5.5 IOH (max) (mA): -0.02 IOL (max) (mA): 0.02 Supply current (max) (µA): 8 Input type: Standard CMOS Output type: 3-State, CMOS, Push-Pull Rating: Catalog Operating temperature range (°C): -40 to 85 Technology family: TXB Bits (#): 1 Data rate (max) (Mbps): 100 High input voltage (min) (V): 0.78 High input voltage (max) (V): 5.5 Vout (min) (V): 1.2 更多

Vout (max) (V): 5.5 IOH (max) (mA): -0.02 IOL (max) (mA): 0.02 Supply current (max) (µA): 8 Input type: Standard CMOS Output type: 3-State, CMOS, Push-Pull Rating: Catalog Operating temperature range (°C): -40 to 85

TXS0102

数据:
分类: 微电路 / 半导体集成电路 / 接口电路 / 电平转换器

描述: 适用于漏极开路和推挽应用的 2 位双向电压电平转换器

Technology family: TXS Applications: I2C, MDIO Bits (#): 2 Data rate (max) (Mbps): 24 High input voltage (min) (V): 1.45 High input voltage (max) (V): 5.5 Vout (min) (V): 1.65 Vout (max) (V): 5.5 IOH (max) (mA): 0 IOL (max) (mA): 0 Supply current (max) (µA): 10 Input type: Transmission Gate Output type: 3-State, Transmission Gate Rating: Catalog Operating temperature range (°C): -40 to 85 Technology family: TXS Applications: I2C, MDIO Bits (#): 2 Data rate (max) (Mbps): 24 High input voltage (min) (V): 1.45 更多

High input voltage (max) (V): 5.5 Vout (min) (V): 1.65 Vout (max) (V): 5.5 IOH (max) (mA): 0 IOL (max) (mA): 0 Supply current (max) (µA): 10 Input type: Transmission Gate Output type: 3-State, Transmission Gate Rating: Catalog Operating temperature range (°C): -40 to 85

TXB0108

数据:
分类: 微电路 / 半导体集成电路 / 接口电路 / 电平转换器

描述: 具有自动方向感应和 +/-15kV ESD 保护的 8 位双向电压电平转换器

Technology family: TXB Applications: GPIO Bits (#): 8 Data rate (max) (Mbps): 100 High input voltage (min) (V): 0.78 High input voltage (max) (V): 5.5 Vout (min) (V): 1.2 Vout (max) (V): 5.5 IOH (max) (mA): -0.02 IOL (max) (mA): 0.02 Supply current (max) (µA): 10 Input type: Standard CMOS Output type: 3-State, CMOS, Push-Pull Rating: Catalog Operating temperature range (°C): -40 to 85 Technology family: TXB Applications: GPIO Bits (#): 8 Data rate (max) (Mbps): 100 High input voltage (min) (V): 0.78 更多

High input voltage (max) (V): 5.5 Vout (min) (V): 1.2 Vout (max) (V): 5.5 IOH (max) (mA): -0.02 IOL (max) (mA): 0.02 Supply current (max) (µA): 10 Input type: Standard CMOS Output type: 3-State, CMOS, Push-Pull Rating: Catalog Operating temperature range (°C): -40 to 85

TXS0104E

数据:
分类: 微电路 / 半导体集成电路 / 接口电路 / 电平转换器

描述: 适用于开漏和推挽应用的四位双向电压电平转换器

Technology family: TXS Applications: SPIO Bits (#): 4 Data rate (max) (Mbps): 24 High input voltage (min) (V): 1.45 High input voltage (max) (V): 5.5 Vout (min) (V): 1.65 Vout (max) (V): 5.5 IOH (max) (mA): 0 IOL (max) (mA): 0 Supply current (max) (µA): 10 Features: Edge rate accelerator, Output enable, Vcc isolation Input type: Transmission Gate Output type: 3-State, Transmission Gate Rating: Catalog Operating temperature range (°C): -40 to 125 Technology family: TXS Applications: SPIO Bits (#): 4 Data rate (max) (Mbps): 24 更多

High input voltage (min) (V): 1.45 High input voltage (max) (V): 5.5 Vout (min) (V): 1.65 Vout (max) (V): 5.5 IOH (max) (mA): 0 IOL (max) (mA): 0 Supply current (max) (µA): 10 Features: Edge rate accelerator, Output enable, Vcc isolation Input type: Transmission Gate Output type: 3-State, Transmission Gate Rating: Catalog Operating temperature range (°C): -40 to 125

SN74GTL2107

数据:
分类: 微电路 / 半导体集成电路 / 接口电路 / 电平转换器

描述: 12 位 GTL-/GTL/GTL+ 至 LVTTL 转换器

Technology family: GTL Applications: GTL Rating: Catalog Operating temperature range (°C): -40 to 85 Technology family: GTL Applications: GTL Rating: Catalog Operating temperature range (°C): -40 to 85

TXB0104

数据:
分类: 微电路 / 半导体集成电路 / 接口电路 / 电平转换器

描述: 具有自动方向感应和 +/-15kV ESD 保护的 4 位双向电压电平转换器

Technology family: TXB Applications: I2S, JTAG, SPI, UART Bits (#): 4 Data rate (max) (Mbps): 100 High input voltage (min) (V): 0.78 High input voltage (max) (V): 5.5 Vout (min) (V): 1.2 Vout (max) (V): 5.5 IOH (max) (mA): -0.02 IOL (max) (mA): 0.02 Supply current (max) (µA): 10 Input type: Standard CMOS Output type: 3-State, CMOS, Push-Pull Rating: Catalog Operating temperature range (°C): -40 to 85 Technology family: TXB Applications: I2S, JTAG, SPI, UART Bits (#): 4 Data rate (max) (Mbps): 100 High input voltage (min) (V): 0.78 更多
