SN74LVC2T45-EP


数据:
分类: 微电路 / 半导体集成电路 / 接口电路 / 电平转换器

描述: 具有可配置电压转换和三态输出的双位双电源收发器（增强型产品）

Technology family: LVC Applications: GPIO, I2S Bits (#): 2 High input voltage (min) (V): 1.08 High input voltage (max) (V): 5.5 Vout (min) (V): 1.65 Vout (max) (V): 5.5 Data rate (max) (Mbps): 420 IOH (max) (mA): -32 IOL (max) (mA): 32 Supply current (max) (µA): 4 Input type: Standard CMOS Output type: 3-State, Balanced CMOS, Push-Pull Rating: HiRel Enhanced Product Operating temperature range (°C): -55 to 125 Technology family: LVC Applications: GPIO, I2S Bits (#): 2 High input voltage (min) (V): 1.08 High input voltage (max) (V): 5.5
Vout (min) (V): 1.65 Vout (max) (V): 5.5 Data rate (max) (Mbps): 420 IOH (max) (mA): -32 IOL (max) (mA): 32 Supply current (max) (µA): 4 Input type: Standard CMOS Output type: 3-State, Balanced CMOS, Push-Pull Rating: HiRel Enhanced Product Operating temperature range (°C): -55 to 125

SN74AVC6T622


数据:
分类: 微电路 / 半导体集成电路 / 接口电路 / 电平转换器

描述: 音频编解码器 AC97 电压转换收发器

Technology family: AVC Applications: I2S Rating: Catalog Operating temperature range (°C): -40 to 85 Technology family: AVC Applications: I2S Rating: Catalog Operating temperature range (°C): -40 to 85

CD4504B-EP


数据:
分类: 微电路 / 半导体集成电路 / 接口电路 / 电平转换器

描述: 用于 TTL 到 CMOS 或 CMOS 到 CMOS 操作的 CMOS 六路电压电平转换器

Technology family: CD4000 Bits (#): 6 Configuration: 6 Ch A to B 0 Ch B to A High input voltage (min) (V): 2 High input voltage (max) (V): 18 Vout (min) (V): 15538 Vout (max) (V): 18 Data rate (max) (Mbps): 24 IOH (max) (mA): -6.8 IOL (max) (mA): -6.8 Supply current (max) (µA): 18 Features: 22 Input type: Standard CMOS Output type: Balanced CMOS, Push-Pull Rating: HiRel Enhanced Product Operating temperature range (°C): -55 to 125 Technology family: CD4000 Bits (#): 6 Configuration: 6 Ch A to B 0 Ch B to A High input voltage (min) (V): 2
High input voltage (max) (V): 18 Vout (min) (V): 15538 Vout (max) (V): 18 Data rate (max) (Mbps): 24 IOH (max) (mA): -6.8 IOL (max) (mA): -6.8 Supply current (max) (µA): 18 Features: 22 Input type: Standard CMOS Output type: Balanced CMOS, Push-Pull Rating: HiRel Enhanced Product Operating temperature range (°C): -55 to 125

SN74AVC16T245-Q1


数据:
分类: 微电路 / 半导体集成电路 / 接口电路 / 电平转换器

描述: 具有可配置电压转换的汽车类 16 位双电源总线收发器

Technology family: AVC Applications: RGMII Bits (#): 16 High input voltage (min) (V): 0.78 High input voltage (max) (V): 3.6 Vout (min) (V): 1.2 Vout (max) (V): 3.6 Data rate (max) (Mbps): 380 IOH (max) (mA): -12 IOL (max) (mA): 12 Supply current (max) (µA): 60 Input type: Standard CMOS Output type: 3-State, Balanced CMOS, Push-Pull Rating: Automotive Operating temperature range (°C): -40 to 125 Technology family: AVC Applications: RGMII Bits (#): 16 High input voltage (min) (V): 0.78 High input voltage (max) (V): 3.6
Vout (min) (V): 1.2 Vout (max) (V): 3.6 Data rate (max) (Mbps): 380 IOH (max) (mA): -12 IOL (max) (mA): 12 Supply current (max) (µA): 60 Input type: Standard CMOS Output type: 3-State, Balanced CMOS, Push-Pull Rating: Automotive Operating temperature range (°C): -40 to 125

TXB0104-Q1


数据:
分类: 微电路 / 半导体集成电路 / 接口电路 / 电平转换器

描述: 具有自动方向感应和 +/-15kV ESD 保护功能的汽车类 4 位双向电压电平转换器

Technology family: TXB Applications: I2S, JTAG, SPI, UART Bits (#): 4 Data rate (max) (Mbps): 100 High input voltage (min) (V): 0.78 High input voltage (max) (V): 5.5 Vout (min) (V): 1.2 Vout (max) (V): 5.5 IOH (max) (mA): -0.02 IOL (max) (mA): 0.02 Supply current (max) (µA): 40 Input type: Standard CMOS Output type: 3-State, CMOS, Push-Pull Rating: Automotive Operating temperature range (°C): -40 to 125 Technology family: TXB Applications: I2S, JTAG, SPI, UART Bits (#): 4 Data rate (max) (Mbps): 100 High input voltage (min) (V): 0.78
High input voltage (max) (V): 5.5 Vout (min) (V): 1.2 Vout (max) (V): 5.5 IOH (max) (mA): -0.02 IOL (max) (mA): 0.02 Supply current (max) (µA): 40 Input type: Standard CMOS Output type: 3-State, CMOS, Push-Pull Rating: Automotive Operating temperature range (°C): -40 to 125

TXB0106


数据:
分类: 微电路 / 半导体集成电路 / 接口电路 / 电平转换器

描述: 具有自动方向感应和 +/-15kV ESD 保护的 6 位双向电压电平转换器

Technology family: TXB Applications: SPI Bits (#): 6 Data rate (max) (Mbps): 100 High input voltage (min) (V): 0.78 High input voltage (max) (V): 5.5 Vout (min) (V): 1.2 Vout (max) (V): 5.5 IOH (max) (mA): -0.02 IOL (max) (mA): 0.02 Supply current (max) (µA): 10 Input type: Standard CMOS Output type: 3-State, CMOS, Push-Pull Rating: Catalog Operating temperature range (°C): -40 to 85 Technology family: TXB Applications: SPI Bits (#): 6 Data rate (max) (Mbps): 100 High input voltage (min) (V): 0.78
High input voltage (max) (V): 5.5 Vout (min) (V): 1.2 Vout (max) (V): 5.5 IOH (max) (mA): -0.02 IOL (max) (mA): 0.02 Supply current (max) (µA): 10 Input type: Standard CMOS Output type: 3-State, CMOS, Push-Pull Rating: Catalog Operating temperature range (°C): -40 to 85

SN74AVC2T245


数据:
分类: 微电路 / 半导体集成电路 / 接口电路 / 电平转换器

描述: 具有可配置电压转换和三态输出的双位 2-DIR 引脚双电源总线收发器

Technology family: AVC Applications: JTAG Bits (#): 2 High input voltage (min) (V): 0.78 High input voltage (max) (V): 3.6 Vout (min) (V): 1.2 Vout (max) (V): 3.6 Data rate (max) (Mbps): 500 IOH (max) (mA): -12 IOL (max) (mA): 12 Supply current (max) (µA): 16 Input type: Standard CMOS Output type: 3-State, Balanced CMOS, Push-Pull Rating: Catalog Operating temperature range (°C): -40 to 85 Technology family: AVC Applications: JTAG Bits (#): 2 High input voltage (min) (V): 0.78 High input voltage (max) (V): 3.6
Vout (min) (V): 1.2 Vout (max) (V): 3.6 Data rate (max) (Mbps): 500 IOH (max) (mA): -12 IOL (max) (mA): 12 Supply current (max) (µA): 16 Input type: Standard CMOS Output type: 3-State, Balanced CMOS, Push-Pull Rating: Catalog Operating temperature range (°C): -40 to 85

TXS02612


数据:
分类: 微电路 / 半导体集成电路 / 接口电路 / 电平转换器

描述: 具有电压电平转换功能的 SDIO 端口扩展器

Technology family: TXS Applications: MMC, SD Card, SDIO Rating: Catalog Operating temperature range (°C): -40 to 85 Technology family: TXS Applications: MMC, SD Card, SDIO Rating: Catalog Operating temperature range (°C): -40 to 85

SN74GTL3004


数据:
分类: 微电路 / 半导体集成电路 / 接口电路 / 电平转换器

描述: 可选 GTL 电压基准

Technology family: GTL Applications: GTL Rating: Catalog Operating temperature range (°C): -40 to 85 Technology family: GTL Applications: GTL Rating: Catalog Operating temperature range (°C): -40 to 85

SN74AVC4T774


数据:
分类: 微电路 / 半导体集成电路 / 接口电路 / 电平转换器

描述: 具有可配置电压电平转换和三态输出的四位双电源总线收发器

Technology family: AVC Applications: JTAG, SPI, UART Bits (#): 4 High input voltage (min) (V): 0.78 High input voltage (max) (V): 3.6 Vout (min) (V): 1.2 Vout (max) (V): 3.6 Data rate (max) (Mbps): 380 IOH (max) (mA): -12 IOL (max) (mA): 12 Supply current (max) (µA): 16 Input type: Standard CMOS Output type: Balanced CMOS, Push-Pull Rating: Catalog Operating temperature range (°C): -40 to 125 Technology family: AVC Applications: JTAG, SPI, UART Bits (#): 4 High input voltage (min) (V): 0.78 High input voltage (max) (V): 3.6
Vout (min) (V): 1.2 Vout (max) (V): 3.6 Data rate (max) (Mbps): 380 IOH (max) (mA): -12 IOL (max) (mA): 12 Supply current (max) (µA): 16 Input type: Standard CMOS Output type: Balanced CMOS, Push-Pull Rating: Catalog Operating temperature range (°C): -40 to 125
