Partner Module: N
GPIOs: 32.0
RAM: 256.0kByte
Type: Wireless MCU
Supported Protocols: Bluetooth Low Energy 5.4
MCU Subsystem: ARM Cortex M33 configurable with 96/48 MHz
Sensitivity (best) (dBm): -106 (LE Coded PHY)
ROM: 64 kByte
Cache: 32.0kByte
Operating Temperature max: 85.0°C
Longevity - 15 years: Yes
Longevity - Extended: No
Launch Date: 31-03-2024
Currently planned availability until at least: 31-03-2039
Family: AIROC™ Bluetooth LE
Bluetooth LE: YES
Bluetooth Classic: NO
CPU: Arm® Cortex®-M33
Bluetooth LE TX Power: 10 dbm
Bluetooth LE RX Sensitivity: -98 dBm (LE1M)
Frequency max: 96.0MHz
Bluetooth Classic: Yes
Bluetooth LE: Yes
CPU: Arm® Cortex®- M4
Family: AIROC™ Bluetooth LE & Bluetooth
Frequency max: 96.0MHz
Operating Voltage max: 3.3V
Partner Module: N
Flash: 256.0kByte
RAM: 176.0kByte
ROM: 1024 kByte
Bluetooth LE RX SENSITIVITY: -95 dBm
Bluetooth EDR 2MBPS RX SENSITIVITY: -94.5 dBm
Bluetooth LE TX POWER: 4.5 dBm
Software Support: ModusToolbox™
GPIOs: 22.0
Operating Temperature max: 85.0°C
Bluetooth Specification: 5.4
Longevity - 15 years: Yes
Longevity - Extended: No
Launch Date: 31-03-2018
Currently planned availability until at least: 31-03-2033
Frequency max: 96.0MHz
GPIOs: 24.0
Partner Module: N
RAM: 384.0kByte
Operating Temperature max: 85.0°C
CPU: Arm® Cortex®-M4
Operating Voltage max: 3.63V
Software Support: ModusToolbox™
Bluetooth LE: Yes
Bluetooth Classic: No
Family: AIROC™ Bluetooth LE
ROM: 2048 kByte
Bluetooth LE RX SENSITIVITY: -94.5 dBm
Bluetooth LE TX POWER: 12 dBm
Bluetooth Specification: Bluetooth® 5.4
Longevity - 15 years: Yes
Longevity - Extended: No
Launch Date: 31-12-2019
Currently planned availability until at least: 31-12-2034
Frequency max: 24.0MHz
Operating Temperature max: 85.0°C
Operating Voltage max: 3.63V
RAM: 60.0kByte
Partner Module: Y
CPU: Arm® Cortex®-M3
Software Support: ModusToolbox®
Bluetooth Classic: No
Bluetooth LE: Yes
Family: AIROC™ Bluetooth LE
GPIOs: 14.0
ROM: 320 kByte
Bluetooth LE RX SENSITIVITY: -93 dBm
Bluetooth LE TX POWER: 4 dBm
Bluetooth Specification: 5.4
Longevity - 15 years: Yes
Longevity - Extended: No
Launch Date: 31-12-2015
Currently planned availability until at least: 31-12-2030
Bluetooth LE: Yes
Bluetooth Classic: Yes
Bluetooth Specification: 5.1
CPU: Arm® Cortex®- M4
Family: AIROC™ Bluetooth LE & Bluetooth
Frequency max: 96.0MHz
Operating Voltage max: 3.63V
Partner Module: N
Flash: 1024.0kByte
RAM: 512.0kByte
ROM: 2048 kByte
Bluetooth LE RX Sensitivity: -95.5 dBm
Bluetooth EDR 2MBPS RX SENSITIVITY: -94 dBm
Bluetooth LE TX Power: 5.5 dBm
Software Support: ModusToolbox™
GPIOs: 40.0
Operating Temperature max: 85.0°C
Longevity - 15 years: Yes
Longevity - Extended: No
Launch Date: 31-03-2020
Currently planned availability until at least: 31-03-2035
Bluetooth LE: Yes
Bluetooth Classic: Yes
Bluetooth Specification: 5.1
CPU: Arm® Cortex®- M4
Family: AIROC™ Bluetooth LE & Bluetooth
Frequency max: 96.0MHz
Operating Voltage max: 3.63V
Partner Module: Y
Flash: 1024.0kByte
RAM: 512.0kByte
ROM: 2048 kByte
Bluetooth LE RX Sensitivity: -95.5 dBm
Bluetooth EDR 2MBPS RX SENSITIVITY: -94 dBm
Bluetooth LE TX Power: 5.5 dBm
Software Support: ModusToolbox™
Operating Temperature max: 85.0°C
GPIOs: 40.0
Longevity - 15 years: Yes
Longevity - Extended: No
Launch Date: 31-03-2020
Currently planned availability until at least: 31-03-2035
Bluetooth Classic: Yes
Bluetooth LE: Yes
CPU: Arm® Cortex®- M4
Family: AIROC™ Bluetooth LE & Bluetooth
Frequency max: 96.0MHz
Operating Voltage max: 2.625V
Partner Module: N
Flash: 256.0kByte
RAM: 176.0kByte
ROM: 1024 kByte
Bluetooth LE RX SENSITIVITY: -94.5 dBm
Bluetooth EDR 2MBPS RX SENSITIVITY: -94 dBm
Bluetooth LE TX POWER: 11.5 dBm
Software Support: ModusToolbox™
Operating Temperature max: 85.0°C
GPIOs: 22.0
Bluetooth Specification: 5.4
Longevity - 15 years: Yes
Longevity - Extended: No
Launch Date: 31-03-2018
Currently planned availability until at least: 31-03-2033
Automotive Qualified: Yes
Bluetooth Classic: Yes
Bluetooth LE: Yes
CPU: ARM Cortex M4
Family: AIROC Bluetooth LE & Bluetooth
Frequency max: 96.0MHz
GPIOs: 17.0
Operating Temperature max: 105.0°C
Operating Voltage max: 3.3V
Operating Voltage max: 2.625V
Partner Module: No
Flash: 256.0kByte
RAM: 176.0kByte
ROM: 1024 kByte
Bluetooth LE RX SENSITIVITY: -94.5 dBm
Bluetooth LE RX SENSITIVITY: -94.5 dBm
Bluetooth EDR 2MBPS RX SENSITIVITY: -94 dBm
Bluetooth LE TX POWER: 11.5 dBm
Software Support: ModusToolbox
Timer/Counter/PWM Blocks: 4.0
更多
Type: Silicon
Wireless Technology: Bluetooth (BR + EDR + BLE)
Bluetooth Specification: 5.4
Longevity - 15 years: Yes
Longevity - Extended: No
Launch Date: 31-03-2019
Currently planned availability until at least: 31-03-2034
CYW89072
分类: 微电路 / 半导体集成电路 / 射频电路
描述: Bluetooth® LE 5.4 MCU with ARM Cortex M3 dedicated for automotive applications
Longevity - 15 years: Yes
Longevity - Extended: No
Launch Date: 31-03-2020
Currently planned availability until at least: 31-03-2035
Bluetooth Classic: Yes
Bluetooth LE: Yes
CPU: Arm® Cortex®- M4
GPIOs: 40.0
Operating Temperature max: 85.0°C
Operating Temperature max: 105.0°C
GPIOs: 8.0
Bluetooth LE RX Sensitivity: -96 dBm
Bluetooth LE TX Power: 12 dBm
Frequency max: 48.0MHz
GPIOs: 24.0
Operating Temperature max: 85.0°C
Partner Module: Y
RAM: 352.0kByte
Bluetooth LE: Yes
Bluetooth Classic: Yes
Family: AIROC™ Bluetooth LE & Bluetooth
Operating Voltage max: 3.6V
Operating Voltage max: 2.94V
ROM: 848 kByte
Bluetooth LE RX Sensitivity: -96.5 dBm
Bluetooth EDR 2MBPS RX SENSITIVITY: -95.5 dBm
Bluetooth LE TX Power: 9 dBm
Software Support: ModusToolbox™
CPU: Arm® Cortex®- M3
Bluetooth Specification: 5.4
Longevity - 15 years: Yes
Longevity - Extended: No
Currently planned availability until at least: 31-12-2030
Launch Date: 2025
