Rating: Automotive Integrated isolated power: No Isolation rating: Basic Number of channels: 4 Forward/reverse channels: 3 forward / 1 reverse Default output: High, Low Data rate (max) (Mbps): 25 Surge isolation voltage (VIOSM) (VPK): 7800 Transient isolation voltage (VIOTM) (VPK): 4242 Withstand isolation voltage (VISO) (Vrms): 3000 CMTI (min) (V/µs): 25000 Operating temperature range (°C): -40 to 125 Supply voltage (max) (V): 5 Supply voltage (min) (V): 3.3 Propagation delay time (typ) (µs): 0.031 Current consumption per channel (DC) (typ) (mA): 0.9 Current consumption per channel (1 Mbps) (typ) (mA): 0.9 Creepage (min) (mm): 8 Clearance (min) (mm): 8 Rating: Automotive 更多

Rating: Automotive Integrated isolated power: No Isolation rating: Basic Number of channels: 4 Forward/reverse channels: 2 forward / 2 reverse Default output: High, Low Data rate (max) (Mbps): 25 Surge isolation voltage (VIOSM) (VPK): 7800 Transient isolation voltage (VIOTM) (VPK): 4242 Withstand isolation voltage (VISO) (Vrms): 3000 CMTI (min) (V/µs): 25000 Operating temperature range (°C): -40 to 125 Supply voltage (max) (V): 5 Supply voltage (min) (V): 3.3 Propagation delay time (typ) (µs): 0.031 Current consumption per channel (DC) (typ) (mA): 0.9 Current consumption per channel (1 Mbps) (typ) (mA): 0.9 Creepage (min) (mm): 8 Clearance (min) (mm): 8 Rating: Automotive 更多

Rating: Catalog Integrated isolated power: No Isolation rating: Reinforced Number of channels: 1 Forward/reverse channels: 1 forward / 0 reverse Default output: High, Low Data rate (max) (Mbps): 100 Surge isolation voltage (VIOSM) (VPK): 12800 Transient isolation voltage (VIOTM) (VPK): 8000 Withstand isolation voltage (VISO) (Vrms): 5700 CMTI (min) (V/µs): 85000 Operating temperature range (°C): -55 to 125 Supply voltage (max) (V): 5.5 Supply voltage (min) (V): 2.25 Propagation delay time (typ) (µs): 0.0107 Current consumption per channel (DC) (typ) (mA): 1.2 Current consumption per channel (1 Mbps) (typ) (mA): 1.8 Creepage (min) (mm): 8, 14.5 Clearance (min) (mm): 8, 14.5 Rating: Catalog 更多

Rating: Catalog Integrated isolated power: No Isolation rating: Reinforced Number of channels: 3 Forward/reverse channels: 3 forward / 0 reverse Default output: High, Low Data rate (max) (Mbps): 100 Surge isolation voltage (VIOSM) (VPK): 12800 Transient isolation voltage (VIOTM) (VPK): 8000 Withstand isolation voltage (VISO) (Vrms): 5700 CMTI (min) (V/µs): 85000 Operating temperature range (°C): -55 to 125 Supply voltage (max) (V): 5.5 Supply voltage (min) (V): 2.25 Propagation delay time (typ) (µs): 0.0107 Current consumption per channel (DC) (typ) (mA): 0.93 Current consumption per channel (1 Mbps) (typ) (mA): 1.57 Creepage (min) (mm): 8, 14.5 Clearance (min) (mm): 8, 14.5 Rating: Catalog 更多

Rating: Catalog Integrated isolated power: No Isolation rating: Reinforced Number of channels: 3 Forward/reverse channels: 2 forward / 1 reverse Default output: High, Low Data rate (max) (Mbps): 100 Surge isolation voltage (VIOSM) (VPK): 12800 Transient isolation voltage (VIOTM) (VPK): 8000 Withstand isolation voltage (VISO) (Vrms): 5700 CMTI (min) (V/µs): 85000 Operating temperature range (°C): -55 to 125 Supply voltage (max) (V): 5.5 Supply voltage (min) (V): 2.25 Propagation delay time (typ) (µs): 0.0107 Current consumption per channel (DC) (typ) (mA): 1.03 Current consumption per channel (1 Mbps) (typ) (mA): 1.67 Creepage (min) (mm): 8, 14.5 Clearance (min) (mm): 8, 14.5 Rating: Catalog 更多

Rating: Catalog Integrated isolated power: No Isolation rating: Reinforced Number of channels: 2 Forward/reverse channels: 2 forward / 0 reverse Default output: High, Low Data rate (max) (Mbps): 100 Surge isolation voltage (VIOSM) (VPK): 12800 Transient isolation voltage (VIOTM) (VPK): 8000 Withstand isolation voltage (VISO) (Vrms): 5700 CMTI (min) (V/µs): 85000 Operating temperature range (°C): -55 to 125 Supply voltage (max) (V): 5.5 Supply voltage (min) (V): 2.25 Propagation delay time (typ) (µs): 0.0107 Current consumption per channel (DC) (typ) (mA): 1.05 Current consumption per channel (1 Mbps) (typ) (mA): 1.7 Creepage (min) (mm): 8, 14.5 Clearance (min) (mm): 8, 14.5 Rating: Catalog 更多

Rating: Catalog Integrated isolated power: No Isolation rating: Reinforced Number of channels: 4 Forward/reverse channels: 4 forward / 0 reverse Default output: High, Low Data rate (max) (Mbps): 100 Surge isolation voltage (VIOSM) (VPK): 12800 Transient isolation voltage (VIOTM) (VPK): 8000 Withstand isolation voltage (VISO) (Vrms): 5700 CMTI (min) (V/µs): 85000 Operating temperature range (°C): -55 to 125 Supply voltage (max) (V): 5.5 Supply voltage (min) (V): 2.25 Propagation delay time (typ) (µs): 0.0107 Current consumption per channel (DC) (typ) (mA): 0.88 Current consumption per channel (1 Mbps) (typ) (mA): 1.53 Creepage (min) (mm): 8, 14.5 Clearance (min) (mm): 8, 14.5 Rating: Catalog 更多

Rating: Catalog Integrated isolated power: No Isolation rating: Basic Number of channels: 4 Forward/reverse channels: 2 forward / 2 reverse Default output: Low Data rate (max) (Mbps): 25 Surge isolation voltage (VIOSM) (VPK): 7800 Transient isolation voltage (VIOTM) (VPK): 4242 Withstand isolation voltage (VISO) (Vrms): 3000 CMTI (min) (V/µs): 25000 Operating temperature range (°C): -40 to 125 Supply voltage (max) (V): 5 Supply voltage (min) (V): 3.3 Propagation delay time (typ) (µs): 0.031 Current consumption per channel (DC) (typ) (mA): 0.9 Current consumption per channel (1 Mbps) (typ) (mA): 0.9 Creepage (min) (mm): 8 Clearance (min) (mm): 8 Rating: Catalog 更多

Rating: Catalog Integrated isolated power: No Isolation rating: Basic Number of channels: 3 Forward/reverse channels: 3 forward / 0 reverse Default output: High Data rate (max) (Mbps): 25 Surge isolation voltage (VIOSM) (VPK): 7800 Transient isolation voltage (VIOTM) (VPK): 4242 Withstand isolation voltage (VISO) (Vrms): 3000 CMTI (min) (V/µs): 25000 Operating temperature range (°C): -40 to 125 Supply voltage (max) (V): 5 Supply voltage (min) (V): 3.3 Propagation delay time (typ) (µs): 0.031 Current consumption per channel (DC) (typ) (mA): 0.77 Current consumption per channel (1 Mbps) (typ) (mA): 0.77 Creepage (min) (mm): 8 Clearance (min) (mm): 8 Rating: Catalog 更多

Rating: Catalog Integrated isolated power: No Isolation rating: Basic Number of channels: 3 Forward/reverse channels: 3 forward / 0 reverse Default output: Low Data rate (max) (Mbps): 25 Surge isolation voltage (VIOSM) (VPK): 7800 Transient isolation voltage (VIOTM) (VPK): 4242 Withstand isolation voltage (VISO) (Vrms): 3000 CMTI (min) (V/µs): 25000 Operating temperature range (°C): -40 to 125 Supply voltage (max) (V): 5 Supply voltage (min) (V): 3.3 Propagation delay time (typ) (µs): 0.031 Current consumption per channel (DC) (typ) (mA): 0.77 Current consumption per channel (1 Mbps) (typ) (mA): 0.77 Creepage (min) (mm): 8 Clearance (min) (mm): 8 Rating: Catalog 更多
