Rating: Catalog Integrated isolated power: No Isolation rating: Basic, Reinforced Number of channels: 4 Forward/reverse channels: 2 forward / 2 reverse Default output: High, Low Data rate (max) (Mbps): 100 Surge isolation voltage (VIOSM) (VPK): 10000, 12800 Transient isolation voltage (VIOTM) (VPK): 4242, 8000 Withstand isolation voltage (VISO) (Vrms): 3000, 5000 CMTI (min) (V/µs): 85000 Operating temperature range (°C): -55 to 125 Supply voltage (max) (V): 5.5 Supply voltage (min) (V): 2.25 Propagation delay time (typ) (µs): 0.0107 Current consumption per channel (DC) (typ) (mA): 1.75 Current consumption per channel (1 Mbps) (typ) (mA): 2.325 Creepage (min) (mm): 3.7, 8 Clearance (min) (mm): 3.7, 8 Rating: Catalog 更多

Rating: Catalog Integrated isolated power: No Isolation rating: Basic, Reinforced Number of channels: 4 Forward/reverse channels: 3 forward / 1 reverse Default output: High, Low Data rate (max) (Mbps): 100 Surge isolation voltage (VIOSM) (VPK): 7800, 10000, 12800 Transient isolation voltage (VIOTM) (VPK): 4242, 8000 Withstand isolation voltage (VISO) (Vrms): 3000, 5000 CMTI (min) (V/µs): 85000 Operating temperature range (°C): -55 to 125 Supply voltage (max) (V): 5.5 Supply voltage (min) (V): 2.25 Propagation delay time (typ) (µs): 0.0107 Current consumption per channel (DC) (typ) (mA): 0.88 Current consumption per channel (1 Mbps) (typ) (mA): 1.48 Creepage (min) (mm): 3.7, 8 Clearance (min) (mm): 3.7, 8 Rating: Catalog 更多

Rating: Automotive Integrated isolated power: No Isolation rating: Basic Number of channels: 4 Forward/reverse channels: 2 forward / 2 reverse Default output: High Data rate (max) (Mbps): 50 Surge isolation voltage (VIOSM) (VPK): 4000 Transient isolation voltage (VIOTM) (VPK): 422 Withstand isolation voltage (VISO) (Vrms): 2500 CMTI (min) (V/µs): 25000 Operating temperature range (°C): -40 to 125 Supply voltage (max) (V): 5 Supply voltage (min) (V): 2.7 Propagation delay time (typ) (µs): 0.021 Current consumption per channel (DC) (typ) (mA): 1.25 Current consumption per channel (1 Mbps) (typ) (mA): 1.25 Creepage (min) (mm): 3.7 Clearance (min) (mm): 3.7 Rating: Automotive 更多

Rating: Automotive Integrated isolated power: No Isolation rating: Basic Number of channels: 1 Forward/reverse channels: 1 forward / 0 reverse Default output: High, Low Data rate (max) (Mbps): 25 Surge isolation voltage (VIOSM) (VPK): 7800 Transient isolation voltage (VIOTM) (VPK): 4242 Withstand isolation voltage (VISO) (Vrms): 3000 CMTI (min) (V/µs): 25000 Operating temperature range (°C): -40 to 125 Supply voltage (max) (V): 5 Supply voltage (min) (V): 3.3 Propagation delay time (typ) (µs): 0.031 Current consumption per channel (DC) (typ) (mA): 1.4 Current consumption per channel (1 Mbps) (typ) (mA): 1.4 Creepage (min) (mm): 4 Clearance (min) (mm): 4 Rating: Automotive 更多

Rating: Automotive Integrated isolated power: No Isolation rating: Basic Number of channels: 3 Forward/reverse channels: 3 forward / 0 reverse Default output: High, Low Data rate (max) (Mbps): 25 Surge isolation voltage (VIOSM) (VPK): 7800 Transient isolation voltage (VIOTM) (VPK): 4242 Withstand isolation voltage (VISO) (Vrms): 3000 CMTI (min) (V/µs): 25000 Operating temperature range (°C): -40 to 125 Supply voltage (max) (V): 5 Supply voltage (min) (V): 3.3 Propagation delay time (typ) (µs): 0.031 Current consumption per channel (DC) (typ) (mA): 0.77 Current consumption per channel (1 Mbps) (typ) (mA): 0.77 Creepage (min) (mm): 8 Clearance (min) (mm): 8 Rating: Automotive 更多

Rating: Automotive Integrated isolated power: No Isolation rating: Basic Number of channels: 3 Forward/reverse channels: 2 forward / 1 reverse Default output: High, Low Data rate (max) (Mbps): 25 Surge isolation voltage (VIOSM) (VPK): 7800 Transient isolation voltage (VIOTM) (VPK): 4242 Withstand isolation voltage (VISO) (Vrms): 3000 CMTI (min) (V/µs): 25000 Operating temperature range (°C): -40 to 125 Supply voltage (max) (V): 5 Supply voltage (min) (V): 3.3 Propagation delay time (typ) (µs): 0.031 Current consumption per channel (DC) (typ) (mA): 1 Current consumption per channel (1 Mbps) (typ) (mA): 1 Creepage (min) (mm): 8 Clearance (min) (mm): 8 Rating: Automotive 更多

Rating: HiRel Enhanced Product Integrated isolated power: No Isolation rating: Basic Number of channels: 2 Forward/reverse channels: 1 forward / 1 reverse Default output: High Data rate (max) (Mbps): 1 Surge isolation voltage (VIOSM) (VPK): 4000 Transient isolation voltage (VIOTM) (VPK): 4242 Withstand isolation voltage (VISO) (Vrms): 2500 CMTI (min) (V/µs): 25000 Operating temperature range (°C): -55 to 125 Supply voltage (max) (V): 5.5 Supply voltage (min) (V): 3 Propagation delay time (typ) (µs): 0.009 Current consumption per channel (DC) (typ) (mA): 1.5 Current consumption per channel (1 Mbps) (typ) (mA): 1.5 Creepage (min) (mm): 4 Clearance (min) (mm): 4 Rating: HiRel Enhanced Product 更多

Rating: Automotive Integrated isolated power: No Isolation rating: Basic Number of channels: 2 Forward/reverse channels: 2 forward / 0 reverse Default output: High, Low Data rate (max) (Mbps): 25 Surge isolation voltage (VIOSM) (VPK): 7800 Transient isolation voltage (VIOTM) (VPK): 4242 Withstand isolation voltage (VISO) (Vrms): 3000 CMTI (min) (V/µs): 25000 Operating temperature range (°C): -40 to 125 Supply voltage (max) (V): 5 Supply voltage (min) (V): 3.3 Propagation delay time (typ) (µs): 0.031 Current consumption per channel (DC) (typ) (mA): 0.85 Current consumption per channel (1 Mbps) (typ) (mA): 0.85 Creepage (min) (mm): 4 Clearance (min) (mm): 4 Rating: Automotive 更多

Rating: Automotive Integrated isolated power: No Isolation rating: Basic Number of channels: 2 Forward/reverse channels: 1 forward / 1 reverse Default output: High, Low Data rate (max) (Mbps): 25 Surge isolation voltage (VIOSM) (VPK): 7800 Transient isolation voltage (VIOTM) (VPK): 4242 Withstand isolation voltage (VISO) (Vrms): 3000 CMTI (min) (V/µs): 25000 Operating temperature range (°C): -40 to 125 Supply voltage (max) (V): 5 Supply voltage (min) (V): 3.3 Propagation delay time (typ) (µs): 0.031 Current consumption per channel (DC) (typ) (mA): 1.2 Current consumption per channel (1 Mbps) (typ) (mA): 1.2 Creepage (min) (mm): 4 Clearance (min) (mm): 4 Rating: Automotive 更多

Rating: Automotive Integrated isolated power: No Isolation rating: Basic Number of channels: 4 Forward/reverse channels: 4 forward / 0 reverse Default output: High, Low Data rate (max) (Mbps): 25 Surge isolation voltage (VIOSM) (VPK): 7800 Transient isolation voltage (VIOTM) (VPK): 4242 Withstand isolation voltage (VISO) (Vrms): 3000 CMTI (min) (V/µs): 25000 Operating temperature range (°C): -40 to 125 Supply voltage (max) (V): 5 Supply voltage (min) (V): 3.3 Propagation delay time (typ) (µs): 0.031 Current consumption per channel (DC) (typ) (mA): 0.68 Current consumption per channel (1 Mbps) (typ) (mA): 0.68 Creepage (min) (mm): 8 Clearance (min) (mm): 8 Rating: Automotive 更多
