Rating: Catalog Integrated isolated power: No Isolation rating: Basic, Reinforced Number of channels: 2 Forward/reverse channels: 2 forward / 0 reverse Default output: High, Low Data rate (max) (Mbps): 100 Surge isolation voltage (VIOSM) (VPK): 10000, 12800 Transient isolation voltage (VIOTM) (VPK): 4242, 7071, 8000 Withstand isolation voltage (VISO) (Vrms): 3000, 5000 CMTI (min) (V/µs): 85000 Operating temperature range (°C): -55 to 125 Supply voltage (max) (V): 5.5 Supply voltage (min) (V): 2.25 Propagation delay time (typ) (µs): 0.0107 Current consumption per channel (DC) (typ) (mA): 0.95 Current consumption per channel (1 Mbps) (typ) (mA): 1.5 Creepage (min) (mm): 4, 8, 8.5 Clearance (min) (mm): 4, 8, 8.5 Rating: Catalog 更多

Rating: Catalog Integrated isolated power: No Isolation rating: Basic, Reinforced Number of channels: 2 Forward/reverse channels: 1 forward / 1 reverse Default output: High, Low Data rate (max) (Mbps): 100 Surge isolation voltage (VIOSM) (VPK): 7800, 10000, 12800 Transient isolation voltage (VIOTM) (VPK): 4242, 7071, 8000 Withstand isolation voltage (VISO) (Vrms): 3000, 5000 CMTI (min) (V/µs): 85000 Operating temperature range (°C): -55 to 125 Supply voltage (max) (V): 5.5 Supply voltage (min) (V): 2.25 Propagation delay time (typ) (µs): 0.0107 Current consumption per channel (DC) (typ) (mA): 1 Current consumption per channel (1 Mbps) (typ) (mA): 1.6 Creepage (min) (mm): 4, 8, 8.5 Clearance (min) (mm): 4, 8, 8.5 Rating: Catalog 更多

Rating: Automotive Integrated isolated power: No Isolation rating: Basic, Reinforced Number of channels: 3 Forward/reverse channels: 3 forward / 0 reverse Default output: High, Low Data rate (max) (Mbps): 100 Surge isolation voltage (VIOSM) (VPK): 4000, 8000 Transient isolation voltage (VIOTM) (VPK): 4242, 8000 Withstand isolation voltage (VISO) (Vrms): 3000, 5000 CMTI (min) (V/µs): 85000 Operating temperature range (°C): -40 to 125 Supply voltage (max) (V): 5.5 Supply voltage (min) (V): 2.25 Propagation delay time (typ) (µs): 0.0107 Current consumption per channel (DC) (typ) (mA): 0.87 Current consumption per channel (1 Mbps) (typ) (mA): 1.47 Creepage (min) (mm): 3.7, 8 Clearance (min) (mm): 3.7, 8 TI functional safety category: Functional Safety-Capable 更多

Rating: Automotive Integrated isolated power: No Isolation rating: Basic, Reinforced Number of channels: 3 Forward/reverse channels: 2 forward / 1 reverse Default output: High, Low Data rate (max) (Mbps): 100 Surge isolation voltage (VIOSM) (VPK): 4000, 8000 Transient isolation voltage (VIOTM) (VPK): 4242, 8000 Withstand isolation voltage (VISO) (Vrms): 3000, 5000 CMTI (min) (V/µs): 85000 Operating temperature range (°C): -40 to 125 Supply voltage (max) (V): 5.5 Supply voltage (min) (V): 2.25 Propagation delay time (typ) (µs): 0.0107 Current consumption per channel (DC) (typ) (mA): 0.97 Current consumption per channel (1 Mbps) (typ) (mA): 1.53 Creepage (min) (mm): 3.7, 8 Clearance (min) (mm): 3.7, 8 TI functional safety category: Functional Safety-Capable 更多

Rating: Automotive Integrated isolated power: No Isolation rating: Basic, Reinforced Number of channels: 4 Forward/reverse channels: 4 forward / 0 reverse Default output: High, Low Data rate (max) (Mbps): 100 Surge isolation voltage (VIOSM) (VPK): 10000, 12800 Transient isolation voltage (VIOTM) (VPK): 4242, 8000 Withstand isolation voltage (VISO) (Vrms): 3000, 5000 CMTI (min) (V/µs): 85000 Operating temperature range (°C): -40 to 125 Supply voltage (max) (V): 5.5 Supply voltage (min) (V): 2.25 Propagation delay time (typ) (µs): 0.0107 Current consumption per channel (DC) (typ) (mA): 0.78 Current consumption per channel (1 Mbps) (typ) (mA): 1.38 Creepage (min) (mm): 3.7, 8 Clearance (min) (mm): 3.7, 8 TI functional safety category: Functional Safety-Capable 更多

Rating: Automotive Integrated isolated power: No Isolation rating: Basic, Reinforced Number of channels: 4 Forward/reverse channels: 3 forward / 1 reverse Default output: High, Low Data rate (max) (Mbps): 100 Surge isolation voltage (VIOSM) (VPK): 10000, 12800 Transient isolation voltage (VIOTM) (VPK): 4242, 8000 Withstand isolation voltage (VISO) (Vrms): 3000, 5000, 5700 CMTI (min) (V/µs): 85000 Operating temperature range (°C): -40 to 125 Supply voltage (max) (V): 5.5 Supply voltage (min) (V): 2.25 Propagation delay time (typ) (µs): 0.0107 Current consumption per channel (DC) (typ) (mA): 0.88 Current consumption per channel (1 Mbps) (typ) (mA): 1.48 Creepage (min) (mm): 3.7, 8, 14.5 Clearance (min) (mm): 3.7, 8, 14.5 TI functional safety category: Functional Safety-Capable 更多

Rating: Automotive Integrated isolated power: No Isolation rating: Basic, Reinforced Number of channels: 4 Forward/reverse channels: 2 forward / 2 reverse Default output: High, Low Data rate (max) (Mbps): 100 Surge isolation voltage (VIOSM) (VPK): 10000, 12800 Transient isolation voltage (VIOTM) (VPK): 4242, 8000 Withstand isolation voltage (VISO) (Vrms): 3000, 5000 CMTI (min) (V/µs): 85000 Operating temperature range (°C): -40 to 125 Supply voltage (max) (V): 5.5 Supply voltage (min) (V): 2.25 Propagation delay time (typ) (µs): 0.0107 Current consumption per channel (DC) (typ) (mA): 0.72 Current consumption per channel (1 Mbps) (typ) (mA): 1.45 Creepage (min) (mm): 3.7, 8 Clearance (min) (mm): 3.7, 8 TI functional safety category: Functional Safety-Capable 更多

Rating: Catalog Integrated isolated power: No Isolation rating: Basic, Reinforced Number of channels: 3 Forward/reverse channels: 3 forward / 0 reverse Default output: High, Low Data rate (max) (Mbps): 100 Surge isolation voltage (VIOSM) (VPK): 10000, 12800 Transient isolation voltage (VIOTM) (VPK): 4242, 8000 Withstand isolation voltage (VISO) (Vrms): 3000, 5000 CMTI (min) (V/µs): 85000 Operating temperature range (°C): -55 to 125 Supply voltage (max) (V): 5.5 Supply voltage (min) (V): 2.25 Propagation delay time (typ) (µs): 0.0107 Current consumption per channel (DC) (typ) (mA): 0.87 Current consumption per channel (1 Mbps) (typ) (mA): 1.47 Creepage (min) (mm): 3.7, 8 Clearance (min) (mm): 3.7, 8 Rating: Catalog 更多

Rating: Catalog Integrated isolated power: No Isolation rating: Basic, Reinforced Number of channels: 3 Forward/reverse channels: 2 forward / 1 reverse Default output: High, Low Data rate (max) (Mbps): 100 Surge isolation voltage (VIOSM) (VPK): 7800, 10000, 12800 Transient isolation voltage (VIOTM) (VPK): 4242, 8000 Withstand isolation voltage (VISO) (Vrms): 3000, 5000 CMTI (min) (V/µs): 85000 Operating temperature range (°C): -55 to 125 Supply voltage (max) (V): 5.5 Supply voltage (min) (V): 2.25 Propagation delay time (typ) (µs): 0.0107 Current consumption per channel (DC) (typ) (mA): 0.97 Current consumption per channel (1 Mbps) (typ) (mA): 1.53 Creepage (min) (mm): 3.7, 8 Clearance (min) (mm): 3.7, 8 Rating: Catalog 更多

Rating: Catalog Integrated isolated power: No Isolation rating: Basic, Reinforced Number of channels: 4 Forward/reverse channels: 4 forward / 0 reverse Default output: High, Low Data rate (max) (Mbps): 100 Surge isolation voltage (VIOSM) (VPK): 10000, 12800 Transient isolation voltage (VIOTM) (VPK): 4242, 8000 Withstand isolation voltage (VISO) (Vrms): 3000, 5000 CMTI (min) (V/µs): 85000 Operating temperature range (°C): -55 to 125 Supply voltage (max) (V): 5.5 Supply voltage (min) (V): 2.25 Propagation delay time (typ) (µs): 0.0107 Current consumption per channel (DC) (typ) (mA): 1.725 Current consumption per channel (1 Mbps) (typ) (mA): 2.325 Creepage (min) (mm): 3.7, 8 Clearance (min) (mm): 3.7, 8 Rating: Catalog 更多
