Rating: Catalog Integrated isolated power: No Isolation rating: Reinforced Number of channels: 4 Forward/reverse channels: 2 forward / 2 reverse Default output: High, Low Data rate (max) (Mbps): 50 Surge isolation voltage (VIOSM) (VPK): 10000 Transient isolation voltage (VIOTM) (VPK): 7071 Withstand isolation voltage (VISO) (Vrms): 5000 CMTI (min) (V/µs): 100000 Operating temperature range (°C): -40 to 125 Supply voltage (max) (V): 5.5 Supply voltage (min) (V): 1.71 Propagation delay time (typ) (µs): 0.011 Current consumption per channel (DC) (typ) (mA): 1 Current consumption per channel (1 Mbps) (typ) (mA): 1.65 Creepage (min) (mm): 8 Clearance (min) (mm): 8 TI functional safety category: Functional Safety-Capable 更多

Rating: Space Integrated isolated power: No Isolation rating: Basic Number of channels: 4 Forward/reverse channels: 3 forward / 1 reverse Default output: High, Low Data rate (max) (Mbps): 100 Surge isolation voltage (VIOSM) (VPK): 5200 Transient isolation voltage (VIOTM) (VPK): 4242 Withstand isolation voltage (VISO) (Vrms): 3000 CMTI (min) (V/µs): 85000 Operating temperature range (°C): -55 to 125 Supply voltage (max) (V): 5.5 Supply voltage (min) (V): 2.25 Propagation delay time (typ) (µs): 0.0107 Current consumption per channel (DC) (typ) (mA): 0.88 Current consumption per channel (1 Mbps) (typ) (mA): 1.48 Creepage (min) (mm): 3.7 Clearance (min) (mm): 3.7 Rating: Space 更多

Rating: Automotive Integrated isolated power: No Isolation rating: Basic, Reinforced Number of channels: 2 Forward/reverse channels: 2 forward / 0 reverse Default output: High, Low Data rate (max) (Mbps): 50 Surge isolation voltage (VIOSM) (VPK): 6500, 10000 Transient isolation voltage (VIOTM) (VPK): 4242, 7071 Withstand isolation voltage (VISO) (Vrms): 3000, 5000 CMTI (min) (V/µs): 100000 Operating temperature range (°C): -40 to 125 Supply voltage (max) (V): 5.5 Supply voltage (min) (V): 1.71 Propagation delay time (typ) (µs): 0.011 Current consumption per channel (DC) (typ) (mA): 1.2 Current consumption per channel (1 Mbps) (typ) (mA): 1.8 Creepage (min) (mm): 4, 8 Clearance (min) (mm): 4, 8 TI functional safety category: Functional Safety-Capable 更多

Rating: Catalog Integrated isolated power: No Isolation rating: Reinforced Number of channels: 3 Forward/reverse channels: 2 forward / 1 reverse Default output: High, Low Data rate (max) (Mbps): 50 Surge isolation voltage (VIOSM) (VPK): 10000 Transient isolation voltage (VIOTM) (VPK): 7071 Withstand isolation voltage (VISO) (Vrms): 5000 CMTI (min) (V/µs): 100000 Operating temperature range (°C): -40 to 125 Supply voltage (max) (V): 5.5 Supply voltage (min) (V): 1.71 Propagation delay time (typ) (µs): 0.011 Current consumption per channel (DC) (typ) (mA): 1 Current consumption per channel (1 Mbps) (typ) (mA): 1.65 Creepage (min) (mm): 8 Clearance (min) (mm): 8 TI functional safety category: Functional Safety-Capable 更多

Rating: Automotive Integrated isolated power: No Isolation rating: Reinforced Number of channels: 4 Forward/reverse channels: 3 forward / 1 reverse Default output: High, Low Data rate (max) (Mbps): 50 Surge isolation voltage (VIOSM) (VPK): 10000 Transient isolation voltage (VIOTM) (VPK): 7071 Withstand isolation voltage (VISO) (Vrms): 5000 CMTI (min) (V/µs): 100000 Operating temperature range (°C): -40 to 125 Supply voltage (max) (V): 5.5 Supply voltage (min) (V): 1.71 Propagation delay time (typ) (µs): 0.011 Current consumption per channel (DC) (typ) (mA): 1 Current consumption per channel (1 Mbps) (typ) (mA): 1.65 Creepage (min) (mm): 8 Clearance (min) (mm): 8 TI functional safety category: Functional Safety-Capable 更多

Rating: Automotive Integrated isolated power: No Isolation rating: Basic, Reinforced Number of channels: 2 Forward/reverse channels: 1 forward / 1 reverse Default output: High, Low Data rate (max) (Mbps): 50 Surge isolation voltage (VIOSM) (VPK): 6500, 10000 Transient isolation voltage (VIOTM) (VPK): 4242, 7071 Withstand isolation voltage (VISO) (Vrms): 3000, 5000 CMTI (min) (V/µs): 100000 Operating temperature range (°C): -40 to 125 Supply voltage (max) (V): 5.5 Supply voltage (min) (V): 1.71 Propagation delay time (typ) (µs): 0.011 Current consumption per channel (DC) (typ) (mA): 1.2 Current consumption per channel (1 Mbps) (typ) (mA): 1.8 Creepage (min) (mm): 4, 8 Clearance (min) (mm): 4, 8 TI functional safety category: Functional Safety-Capable 更多

Rating: Catalog Integrated isolated power: No Isolation rating: Basic Number of channels: 2 Forward/reverse channels: 1 forward / 1 reverse Default output: High, Low Data rate (max) (Mbps): 50 Surge isolation voltage (VIOSM) (VPK): 6500 Transient isolation voltage (VIOTM) (VPK): 4242 Withstand isolation voltage (VISO) (Vrms): 3000 CMTI (min) (V/µs): 100000 Operating temperature range (°C): -40 to 125 Supply voltage (max) (V): 5.5 Supply voltage (min) (V): 1.71 Propagation delay time (typ) (µs): 0.011 Current consumption per channel (DC) (typ) (mA): 1.2 Current consumption per channel (1 Mbps) (typ) (mA): 1.8 Creepage (min) (mm): 4 Clearance (min) (mm): 4 TI functional safety category: Functional Safety-Capable 更多

Rating: Catalog Integrated isolated power: No Isolation rating: Reinforced Number of channels: 4 Forward/reverse channels: 3 forward / 1 reverse Default output: High, Low Data rate (max) (Mbps): 50 Surge isolation voltage (VIOSM) (VPK): 10000 Transient isolation voltage (VIOTM) (VPK): 7071 Withstand isolation voltage (VISO) (Vrms): 5000 CMTI (min) (V/µs): 100000 Operating temperature range (°C): -40 to 125 Supply voltage (max) (V): 5.5 Supply voltage (min) (V): 1.71 Propagation delay time (typ) (µs): 0.011 Current consumption per channel (DC) (typ) (mA): 1 Current consumption per channel (1 Mbps) (typ) (mA): 1.65 Creepage (min) (mm): 8 Clearance (min) (mm): 8 TI functional safety category: Functional Safety-Capable 更多

Rating: Automotive Isolation rating: Reinforced Number of channels: 4 Forward/reverse channels: 3 forward / 1 reverse Data rate (max) (Mbps): 100 Working isolation voltage (VIOWM) (Vrms): 1000 Surge isolation voltage (VIOSM) (VPK): 10000 Transient isolation voltage (VIOTM) (VPK): 7071 Withstand isolation voltage (VISO) (Vrms): 5000 CMTI (min) (kV/µs): 100 Operating temperature range (°C): -40 to 125 TI functional safety category: Functional Safety-Capable Type: Digital isolator Rating: Automotive Isolation rating: Reinforced Number of channels: 4 Forward/reverse channels: 3 forward / 1 reverse Data rate (max) (Mbps): 100 Working isolation voltage (VIOWM) (Vrms): 1000 Surge isolation voltage (VIOSM) (VPK): 10000 更多

Rating: Automotive Integrated isolated power: No Isolation rating: Reinforced Number of channels: 4 Forward/reverse channels: 3 forward / 1 reverse Default output: High, Low Data rate (max) (Mbps): 100 Surge isolation voltage (VIOSM) (VPK): 12800 Transient isolation voltage (VIOTM) (VPK): 8000 Withstand isolation voltage (VISO) (Vrms): 5000 CMTI (min) (V/µs): 85000 Operating temperature range (°C): -40 to 150 Supply voltage (max) (V): 5.5 Supply voltage (min) (V): 2.25 Propagation delay time (typ) (µs): 0.0107 Current consumption per channel (DC) (typ) (mA): 0.88 Current consumption per channel (1 Mbps) (typ) (mA): 1.48 Creepage (min) (mm): 8 Clearance (min) (mm): 8 TI functional safety category: Functional Safety-Capable 更多
