Rating: Catalog Integrated isolated power: No Isolation rating: Basic Number of channels: 2 Forward/reverse channels: 1 forward / 1 reverse Default output: High, Low Data rate (max) (Mbps): 4 Surge isolation voltage (VIOSM) (VPK): 6400 Transient isolation voltage (VIOTM) (VPK): 4242 Withstand isolation voltage (VISO) (Vrms): 3000 CMTI (min) (V/µs): 50000 Operating temperature range (°C): -55 to 125 Supply voltage (max) (V): 5.5 Supply voltage (min) (V): 1.71 Propagation delay time (typ) (µs): 0.14 Current consumption per channel (DC) (typ) (mA): 0.00475 Current consumption per channel (1 Mbps) (typ) (mA): 0.12 Creepage (min) (mm): 3.7 Clearance (min) (mm): 3.7 Rating: Catalog 更多

Rating: Automotive Integrated isolated power: No Isolation rating: Basic, Reinforced Number of channels: 6 Forward/reverse channels: 6 forward / 0 reverse Default output: High, Low Data rate (max) (Mbps): 100 Surge isolation voltage (VIOSM) (VPK): 10000, 12800 Transient isolation voltage (VIOTM) (VPK): 4242, 8000 Withstand isolation voltage (VISO) (Vrms): 3000, 5000 CMTI (min) (V/µs): 85000 Operating temperature range (°C): -40 to 125 Supply voltage (max) (V): 5.5 Supply voltage (min) (V): 2.25 Propagation delay time (typ) (µs): 0.0107 Current consumption per channel (DC) (typ) (mA): 0.77 Current consumption per channel (1 Mbps) (typ) (mA): 1.38 Creepage (min) (mm): 3.7, 8 Clearance (min) (mm): 3.7, 8 TI functional safety category: Functional Safety-Capable 更多

Rating: Automotive Integrated isolated power: No Isolation rating: Basic, Reinforced Number of channels: 6 Forward/reverse channels: 5 forward / 1 reverse Default output: High, Low Data rate (max) (Mbps): 100 Surge isolation voltage (VIOSM) (VPK): 10000, 12800 Transient isolation voltage (VIOTM) (VPK): 4242, 8000 Withstand isolation voltage (VISO) (Vrms): 3000, 5000 CMTI (min) (V/µs): 85000 Operating temperature range (°C): -40 to 125 Supply voltage (max) (V): 5.5 Supply voltage (min) (V): 2.25 Propagation delay time (typ) (µs): 0.0107 Current consumption per channel (DC) (typ) (mA): 0.78 Current consumption per channel (1 Mbps) (typ) (mA): 1.38 Creepage (min) (mm): 3.7, 8 Clearance (min) (mm): 3.7, 8 TI functional safety category: Functional Safety-Capable 更多

Rating: Automotive Integrated isolated power: No Isolation rating: Basic, Reinforced Number of channels: 6 Forward/reverse channels: 4 forward / 2 reverse Default output: High, Low Data rate (max) (Mbps): 100 Surge isolation voltage (VIOSM) (VPK): 10000, 12800 Transient isolation voltage (VIOTM) (VPK): 4242, 8000 Withstand isolation voltage (VISO) (Vrms): 3000, 5000 CMTI (min) (V/µs): 85000 Operating temperature range (°C): -40 to 125 Supply voltage (max) (V): 5.5 Supply voltage (min) (V): 2.25 Propagation delay time (typ) (µs): 0.0107 Current consumption per channel (DC) (typ) (mA): 0.77 Current consumption per channel (1 Mbps) (typ) (mA): 1.38 Creepage (min) (mm): 3.7, 8 Clearance (min) (mm): 3.7, 8 TI functional safety category: Functional Safety-Capable 更多

Rating: Automotive Integrated isolated power: No Isolation rating: Basic, Reinforced Number of channels: 6 Forward/reverse channels: 3 forward / 3 reverse Default output: High, Low Data rate (max) (Mbps): 100 Surge isolation voltage (VIOSM) (VPK): 10000, 12800 Transient isolation voltage (VIOTM) (VPK): 4242, 8000 Withstand isolation voltage (VISO) (Vrms): 3000, 5000 CMTI (min) (V/µs): 85000 Operating temperature range (°C): -40 to 125 Supply voltage (max) (V): 5.5 Supply voltage (min) (V): 2.25 Propagation delay time (typ) (µs): 0.0107 Current consumption per channel (DC) (typ) (mA): 0.8 Current consumption per channel (1 Mbps) (typ) (mA): 1.4 Creepage (min) (mm): 3.7, 8 Clearance (min) (mm): 3.7, 8 TI functional safety category: Functional Safety-Capable 更多

Rating: Catalog Integrated isolated power: No Isolation rating: Basic Number of channels: 4 Forward/reverse channels: 3 forward / 1 reverse Default output: High, Low Data rate (max) (Mbps): 4 Surge isolation voltage (VIOSM) (VPK): 6400 Transient isolation voltage (VIOTM) (VPK): 4242 Withstand isolation voltage (VISO) (Vrms): 3000 CMTI (min) (V/µs): 50000 Operating temperature range (°C): -55 to 125 Supply voltage (max) (V): 5.5 Supply voltage (min) (V): 1.71 Propagation delay time (typ) (µs): 0.14 Current consumption per channel (DC) (typ) (mA): 0.0042 Current consumption per channel (1 Mbps) (typ) (mA): 0.116 Creepage (min) (mm): 3.7 Clearance (min) (mm): 3.7 Rating: Catalog 更多

Rating: Catalog Integrated isolated power: No Isolation rating: Basic, Reinforced Number of channels: 6 Forward/reverse channels: 5 forward / 1 reverse Default output: High, Low Data rate (max) (Mbps): 100 Surge isolation voltage (VIOSM) (VPK): 10000, 12800 Transient isolation voltage (VIOTM) (VPK): 4242, 8000 Withstand isolation voltage (VISO) (Vrms): 3000, 5000 CMTI (min) (V/µs): 85000 Operating temperature range (°C): -55 to 125 Supply voltage (max) (V): 5.5 Supply voltage (min) (V): 2.25 Propagation delay time (typ) (µs): 0.0107 Current consumption per channel (DC) (typ) (mA): 0.78 Current consumption per channel (1 Mbps) (typ) (mA): 1.38 Creepage (min) (mm): 3.7, 8 Clearance (min) (mm): 3.7, 8 Rating: Catalog 更多

Rating: Catalog Integrated isolated power: No Isolation rating: Basic, Reinforced Number of channels: 6 Forward/reverse channels: 3 forward / 3 reverse Default output: High, Low Data rate (max) (Mbps): 100 Surge isolation voltage (VIOSM) (VPK): 10000, 12800 Transient isolation voltage (VIOTM) (VPK): 4242, 8000 Withstand isolation voltage (VISO) (Vrms): 3000, 5000 CMTI (min) (V/µs): 85000 Operating temperature range (°C): -55 to 125 Supply voltage (max) (V): 5.5 Supply voltage (min) (V): 2.25 Propagation delay time (typ) (µs): 0.0107 Current consumption per channel (DC) (typ) (mA): 0.8 Current consumption per channel (1 Mbps) (typ) (mA): 1.4 Creepage (min) (mm): 3.7, 8 Clearance (min) (mm): 3.7, 8 Rating: Catalog 更多

Rating: Catalog Integrated isolated power: No Isolation rating: Basic, Reinforced Number of channels: 6 Forward/reverse channels: 4 forward / 2 reverse Default output: High, Low Data rate (max) (Mbps): 100 Surge isolation voltage (VIOSM) (VPK): 10000, 12800 Transient isolation voltage (VIOTM) (VPK): 4242, 8000 Withstand isolation voltage (VISO) (Vrms): 3000, 5000 CMTI (min) (V/µs): 85000 Operating temperature range (°C): -55 to 125 Supply voltage (max) (V): 5.5 Supply voltage (min) (V): 2.25 Propagation delay time (typ) (µs): 0.0107 Current consumption per channel (DC) (typ) (mA): 0.77 Current consumption per channel (1 Mbps) (typ) (mA): 1.38 Creepage (min) (mm): 3.7, 8 Clearance (min) (mm): 3.7, 8 Rating: Catalog 更多

Rating: Catalog Isolation rating: Reinforced Number of channels: 4 Forward/reverse channels: 1 forward / 3 reverse Data rate (max) (Mbps): 100 Working isolation voltage (VIOWM) (Vrms): 1000 Surge isolation voltage (VIOSM) (VPK): 10000 Transient isolation voltage (VIOTM) (VPK): 7071 Withstand isolation voltage (VISO) (Vrms): 5000 CMTI (min) (kV/µs): 100 Operating temperature range (°C): -40 to 125 Type: Digital isolator Rating: Catalog Isolation rating: Reinforced Number of channels: 4 Forward/reverse channels: 1 forward / 3 reverse Data rate (max) (Mbps): 100 Working isolation voltage (VIOWM) (Vrms): 1000 Surge isolation voltage (VIOSM) (VPK): 10000 Transient isolation voltage (VIOTM) (VPK): 7071 更多
