IGW50N60H3
制造商:
描述: 600 V, 50 A IGBT Discrete in TO-247 package
物料参数
| E[on]: | 1.45mJ |
| I[C](@ 100°) max: | 50.0A |
| I[C](@ 25°) max: | 100.0A |
| I[Cpuls] max: | 200.0A |
| Q[Gate]: | 315.0nC |
| V[CE(sat)]: | 1.85V |
| V[CE] max: | 600.0V |
| t[d(off)]: | 235.0ns |
| t[d(on)]: | 23.0ns |
| t[f]: | 24.0ns |
| t[r]: | 37.0ns |
| Switching Frequency max: | 100.0kHz |
| Package: | TO-247 |
| Switching Frequency: | HighSpeed3 20-100 kHz |
| E[off](Hard Switching): | 0.91mJ |
| Technology: | IGBT HighSpeed 3 |
| P[tot] max: | 333.0W |
| R[G]: | 7.0Ω |
