IPC70N04S5L-4R2
制造商:
描述: 40V, N-Ch, 4.2 mΩ max, Automotive MOSFET, SS08 (5x6), OptiMOS™-5
物料参数
| R[thJC] max: | 3.0K/W |
| P[tot] max: | 50.0W |
| I[Dpuls] max: | 280.0A |
| Qualification: | Automotive |
| Package: | single SS08 (PG-TDSON-8) |
| V[DS] max: | 40.0V |
| R[DS (on)](@10V) max: | 4.2mΩ |
| Polarity: | N |
| I[D ](@25°C) max: | 70.0A |
| Technology: | OptiMOS™-5 |
| Operating Temperature max: | 175.0°C |
| Q[G](typ @10V): | 22.0nC |
| Q[G](typ @10V) max: | 30.0nC |
| V[GS(th)]: | 1.6V |
| Launch year: | 2016 |
| Currently planned availability until at least: | 2032 |
| Budgetary Price €/1k: | 0.27 |
