INFINEON

Infineon 英飞凌专注于迎接现代社会的三大科技挑战：高能效、移动性和安全性，为汽车和工业功率器件、芯片卡和安全应用提供半导体和系统解决方案。英飞凌的产品素以高可靠性、卓越质量和创新性著称，并在模拟和混合信号、射频、功率以及嵌入式控制装置领域掌握尖端技术。

IDP40E65D2

分类: 半导体分立器件和附件 / 二极管 / 普通二极管 / 功率二极管
数据:

简介: 650 V silicon power diode in TO-220 real2pin package

IF: 40.0A I(FSM): NoneA VF: 1.6V IR: NoneµA Irrm: 2.9A Qrr: 0.13µC trr: 75.0ns Ptot: NoneW RthJC: NoneK/W Operating Temperature: None°C Mounting: THT Package: TO-220 Configuration: Single Voltage Class: NoneV

1ED3123MC12H

分类: 微电路 / 半导体集成电路 / 接口电路 / 驱动器
数据:

简介: 14 A, 5.7 kV (rms) single-channel isolated gate driver with separate output, UL 1577 & VDE 0884-11 certified, 8 V UVLO

Channels: 1.0 Configuration: High-side Input Vcc: NoneV Isolation Type: Galvanic isolation - Reinforced Output Current(Sink): 14.0A Output Current(Source): 13.5A Package: PG-DSO-8 Qualification: Industrial Turn Off Propagation Delay: 90.0ns Turn On Propagation Delay: 90.0ns VBS UVLO(On): 10.0V VBS UVLO(Off): 8.0V VCC UVLO(Off): 2.5V VCC UVLO(On): 3.1V Voltage Class: 2300.0V

1ED3142MU12F

分类: 微电路 / 半导体集成电路 / 接口电路 / 驱动器
数据:

简介: 6.5 A, 3 kV (rms) single-channel isolated gate driver with separate output, UL 1577 certified, 13.6 V UVLO

Voltage Class: 2300.0V Output Current(Source): 6.0A Output Current(Sink): 6.5A Configuration: High-side Qualification: Industrial Isolation Type: Galvanic isolation - Functional Turn Off Propagation Delay: 45.0ns Turn On Propagation Delay: 45.0ns Input Vcc: NoneV VBS UVLO(On): 13.6V VBS UVLO(Off): 12.6V Channels: 1.0

1ED3140MU12F

分类: 微电路 / 半导体集成电路 / 接口电路 / 驱动器
数据:

简介: 6.5 A, 3 kV (rms) single-channel isolated gate driver with separate output, UL 1577 certified, 9.3 V UVLO

Voltage Class: 2300.0V Output Current(Source): 6.0A Output Current(Sink): 6.5A Configuration: High-side Qualification: Industrial Isolation Type: Galvanic isolation - Functional Turn On Propagation Delay: 45.0ns Turn Off Propagation Delay: 45.0ns Input Vcc: NoneV VBS UVLO(On): 9.3V VBS UVLO(Off): 8.6V Channels: 1.0

1ED3240MC12H

分类: 微电路 / 半导体集成电路 / 接口电路 / 驱动器
数据:

简介: 10 A, 5.7 kV (rms) single-channel isolated gate driver with two-level slew-rate control, UL 1577 & VDE 0884-11 certified

Channels: 1.0 Configuration: High-side Input Vcc: NoneV Isolation Type: Galvanic isolation - Reinforced Output Current(Sink): 10.0A Output Current(Source): 10.0A Package: PG-DSO-8 Qualification: Industrial Turn Off Propagation Delay: 110.0ns Turn On Propagation Delay: 110.0ns VBS UVLO(Off): 10.4V VBS UVLO(On): 12.5V VCC UVLO(Off): 2.5V VCC UVLO(On): 3.1V Voltage Class: 2300.0V

IDP08E65D2

分类: 半导体分立器件和附件 / 二极管 / 普通二极管 / 功率二极管
数据:

简介: 650 V silicon power diode in TO-220 real2pin package

IF: 8.0A I(FSM): NoneA VF: 1.6V IR: NoneµA Irrm: 2.5A Qrr: 0.08µC trr: 40.0ns Ptot: NoneW RthJC: NoneK/W Operating Temperature: None°C Mounting: THT Package: TO-220 Configuration: Single Voltage Class: NoneV

IDP30E65D2

分类: 半导体分立器件和附件 / 二极管 / 普通二极管 / 功率二极管
数据:

简介: 650 V silicon power diode in TO-220 real2pin package

Configuration: Single I(FSM): NoneA IF: 30.0A IR: NoneµA Irrm: 5.7A Mounting: THT Operating Temperature: None°C Ptot: NoneW Package: TO-220 Qrr: 0.25µC RthJC: NoneK/W VF: 1.6V trr: 70.0ns Voltage Class: NoneV

1ED3241MC12H

分类: 微电路 / 半导体集成电路 / 接口电路 / 驱动器
数据:

简介: 18 A, 5.7 kV (rms) single-channel isolated gate driver with two-level slew-rate control, UL 1577 & VDE 0884-11 certified

Channels: 1.0 Configuration: High-side Input Vcc: NoneV Isolation Type: Galvanic isolation - Reinforced Output Current(Sink): 18.0A Output Current(Source): 18.0A Package: PG-DSO-8 Qualification: Industrial Turn Off Propagation Delay: 110.0ns Turn On Propagation Delay: 110.0ns VBS UVLO(Off): 10.4V VBS UVLO(On): 12.5V VCC UVLO(Off): 2.5V VCC UVLO(On): 3.1V Voltage Class: 2300.0V

1ED3250MC12H

分类: 微电路 / 半导体集成电路 / 接口电路 / 驱动器
数据:

简介: 10 A, 5.7 kV (rms) single-channel isolated gate driver with two-level slew-rate control and active Miller clamp, UL 1577 & VDE 0884-11 certified

Channels: 1.0 Configuration: High-side Input Vcc: NoneV Isolation Type: Galvanic isolation - Reinforced Output Current(Sink): 10.0A Output Current(Source): 5.0A Package: PG-DSO-8 Qualification: Industrial Turn Off Propagation Delay: 110.0ns Turn On Propagation Delay: 110.0ns VBS UVLO(Off): 10.4V VBS UVLO(On): 12.5V VCC UVLO(Off): 2.5V VCC UVLO(On): 3.1V Voltage Class: 2300.0V

1ED3320MC12N

分类: 微电路 / 半导体集成电路 / 接口电路 / 驱动器
数据:

简介: 6 A, 5.7 kV (rms) single-channel isolated gate driver with short-circuit protection, active Miller clamp and soft-off, UL 1577 & VDE 0884-11 certified

Configuration: High-side Package: PG-DSO-16 Channels: 1.0 Qualification: Industrial Voltage Class: 2300.0V VBS UVLO(Off): 11.0V VBS UVLO(On): 12.0V Isolation Type: Galvanic isolation - Reinforced Output Current(Source): 3.3A Output Current(Sink): 6.0A Turn Off Propagation Delay: 85.0ns Turn On Propagation Delay: 85.0ns
