SAK-TC264DA-40F200WBC
分类:数据:
简介: A powerful AURIX™ microcontroller for automotive & industrial applications with a frequency of 200 MHz, up to 2.5MB of Flash and a LQFP-144 package
SRAM (incl. Cache): 752.0kByte
CAN Nodes: 5
A/D Input Lines(incl. FADC): 40
Program Memory: 2.5MByte
Watchdog Timer: yes
Real Time Clock: yes
Oscillator Watchdog: yes
On-chip Voltage Regulator: yes
On-chip Clock Generation: yes
Floating Point Unit: yes
EEPROM Emulation: yes
DSP Functionality: yes
Number of ADC Modules: 7.0
Instruction Width([bits]): 32/16
DMA Channels: 48
External Bus Interface: no
Fast Flash Programming: no
Touch/LED Matrix Control: no
Additional Features: Standby Control Unit
LIN: 4.0
更多
SPI: 4.0
eMMC: no
# of cores / lockstep cores: 2/1
Hardware Accelerator: FFT
Type of Memory: Flash
Temperature: -40°C - +125°C
Family: AURIX™ 1G
Classification: ISO 26262-compliant
Budgetary Price €/1k: 15.94
ASIL/SIL support: ASIL-D/SIL-3
SAK-TC264DC-40F200WBC
分类:数据:
简介: A powerful AURIX™ microcontroller for automotive & industrial applications with a frequency of 200 MHz, up to 2.5MB of Flash and a LQFP-176 package
SRAM (incl. Cache): 240.0kByte
CAN Nodes: 5
A/D Input Lines(incl. FADC): 43
Program Memory: 2.5MByte
EEPROM Emulation: yes
Number of ADC Modules: 7.0
Instruction Width([bits]): 32/16
DMA Channels: 48
External Bus Interface: no
Fast Flash Programming: no
Additional Features: Dual Core
Additional Features: Lockstep
Additional Features: Safety IO Monitor
Additional Features: Stand-By Controller
eMMC: no
SPI: 4.0
LIN: 4.0
# of cores / lockstep cores: 2/1
Hardware Accelerator: no
Watchdog Timer: Yes
更多
Real Time Clock: yes
Oscillator Watchdog: Yes
On-chip Clock Generation: Yes
I/O Operation Voltages max: 5.0V
On-chip Voltage Regulator: yes
Floating Point Unit: yes
DSP Functionality: yes
Additional Features: Ethernet
Type of Memory: Flash
Temperature: -40°C - +125°C
Family: AURIX™ 1G
Classification: ISO 26262-compliant
ASIL/SIL support: ASIL-D/SIL-3
# of cores / lockstep cores: 2/1
CAN Nodes: 5
Hardware Accelerator: no
Floating Point Unit: yes
I/O Operation Voltages max: 5.0V
Oscillator Watchdog: yes
LIN: 4.0
Number of ADC Modules: 7.0
External Bus Interface: no
DMA Channels: 48
SRAM (incl. Cache): 240.0kByte
Real Time Clock: yes
Program Memory: 2.5MByte
Watchdog Timer: yes
eMMC: no
SPI: 4.0
On-chip Clock Generation: yes
On-chip Voltage Regulator: yes
DSP Functionality: yes
Type of Memory: Flash
更多
Temperature: -40°C - +125°C
Family: AURIX™ 1G
Classification: ISO 26262-compliant
A/D Input Lines(incl. FADC): 43
ASIL/SIL support: ASIL-D/SIL-3
SAK-TC265D-40F200NBC
分类:数据:
简介: A powerful AURIX™ microcontroller for automotive & industrial applications with a frequency of 200 MHz, up to 2.5MB of Flash and a LQFP-176 package
SRAM (incl. Cache): 240.0kByte
CAN Nodes: 5
A/D Input Lines(incl. FADC): 53
Program Memory: 2.5MByte
EEPROM Emulation: yes
Number of ADC Modules: 7.0
Instruction Width([bits]): 32/16
DMA Channels: 48
External Bus Interface: no
Fast Flash Programming: no
Additional Features: Dual Core
Additional Features: Lockstep
Additional Features: Safety IO Monitor
Additional Features: Stand-By Controller
LIN: 4.0
SPI: 4.0
eMMC: no
# of cores / lockstep cores: 2/1
Hardware Accelerator: no
DSP Functionality: Yes
更多
Additional Features: Ethernet
Floating Point Unit: Yes
On-chip Clock Generation: Yes
On-chip Voltage Regulator: Yes
Oscillator Watchdog: Yes
Watchdog Timer: Yes
Real Time Clock: Yes
Type of Memory: Flash
Temperature: -40°C - +125°C
Family: AURIX™ 1G
Classification: ISO 26262-compliant
Budgetary Price €/1k: 14.19
ASIL/SIL support: ASIL-D/SIL-3
SAK-TC265D-40F200WBC
分类:数据:
简介: A powerful AURIX™ microcontroller for automotive & industrial applications with a frequency of 200 MHz, up to 2.5MB of Flash and a LQFP-176 package
SRAM (incl. Cache): 240.0kByte
CAN Nodes: 5
A/D Input Lines(incl. FADC): 53
Program Memory: 2.5MByte
EEPROM Emulation: yes
Number of ADC Modules: 7.0
Instruction Width([bits]): 32/16
DMA Channels: 48
External Bus Interface: no
Fast Flash Programming: no
Additional Features: Dual Core
Additional Features: Lockstep
Additional Features: Safety IO Monitor
Additional Features: Stand-By Controller
eMMC: no
SPI: 4.0
LIN: 4.0
Hardware Accelerator: no
# of cores / lockstep cores: 2/1
DSP Functionality: Yes
更多
I/O Operation Voltages max: 5.0V
On-chip Clock Generation: Yes
Floating Point Unit: Yes
Real Time Clock: Yes
Oscillator Watchdog: Yes
On-chip Voltage Regulator: Yes
Watchdog Timer: Yes
Type of Memory: Flash
Temperature: -40°C - +125°C
Family: AURIX™ 1G
Classification: ISO 26262-compliant
Budgetary Price €/1k: 13.14
ASIL/SIL support: ASIL-D/SIL-3
SAK-TC265DC-40F200WBC
分类:数据:
简介: A powerful AURIX™ microcontroller for automotive & industrial applications with a frequency of 200 MHz, up to 2.5MB of Flash and a LQFP-176 package
SRAM (incl. Cache): 240.0kByte
CAN Nodes: 5
A/D Input Lines(incl. FADC): 53
Program Memory: 2.5MByte
EEPROM Emulation: yes
Number of ADC Modules: 7.0
Instruction Width([bits]): 32/16
DMA Channels: 48
External Bus Interface: no
Fast Flash Programming: no
Additional Features: Dual Core
Additional Features: Lockstep
Additional Features: Safety IO Monitor
Additional Features: Stand-By Controller
LIN: 4.0
SPI: 4.0
eMMC: no
Hardware Accelerator: no
Watchdog Timer: Yes
Oscillator Watchdog: Yes
更多
On-chip Clock Generation: Yes
On-chip Voltage Regulator: Yes
I/O Operation Voltages max: 5.0V
Floating Point Unit: yes
Real Time Clock: Yes
Type of Memory: Flash
Temperature: -40°C - +125°C
Family: AURIX™ 1G
Classification: ISO 26262-compliant
# of cores / lockstep cores: 2/1
DSP Functionality: YES
ASIL/SIL support: ASIL-D/SIL-3
# of cores / lockstep cores: 2/1
CAN Nodes: 5
DMA Channels: 48
External Bus Interface: no
Hardware Accelerator: no
Number of ADC Modules: 7.0
On-chip Clock Generation: yes
Oscillator Watchdog: yes
SRAM (incl. Cache): 240.0kByte
eMMC: no
I/O Operation Voltages max: 5.0V
On-chip Voltage Regulator: yes
Floating Point Unit: yes
Real Time Clock: yes
Program Memory: 2.5MByte
Watchdog Timer: yes
DSP Functionality: yes
LIN: 4.0
SPI: 4.0
Type of Memory: Flash
更多
Temperature: -40°C - +125°C
Family: AURIX™ 1G
Classification: ISO 26262-compliant
A/D Input Lines(incl. FADC): 53
ASIL/SIL support: ASIL-D/SIL-3
SAK-TC267D-40F200NBC
分类:数据:
简介: A powerful AURIX™ microcontroller for automotive & industrial applications with a frequency of 200 MHz, up to 2.5MB of Flash and a LFBGA-292 package
SRAM (incl. Cache): 240.0kByte
CAN Nodes: 5
A/D Input Lines(incl. FADC): 53
Program Memory: 2.5MByte
EEPROM Emulation: yes
Number of ADC Modules: 7.0
Instruction Width([bits]): 32/16
DMA Channels: 48
External Bus Interface: no
Fast Flash Programming: no
Additional Features: Dual Core
Additional Features: Lockstep
Additional Features: Safety IO Monitor
Additional Features: Stand-By Controller
eMMC: no
SPI: 4.0
LIN: 4.0
Hardware Accelerator: no
# of cores / lockstep cores: 2/1
DSP Functionality: Yes
更多
I/O Operation Voltages max: 5.0V
Floating Point Unit: Yes
On-chip Voltage Regulator: Yes
On-chip Clock Generation: Yes
Real Time Clock: Yes
Watchdog Timer: Yes
Oscillator Watchdog: Yes
Type of Memory: Flash
Temperature: -40°C - +125°C
Family: AURIX™ 1G
Classification: ISO 26262-compliant
Budgetary Price €/1k: 17.06
ASIL/SIL support: ASIL-D/SIL-3
SAK-TC267D-40F200SBC
分类:简介: A powerful AURIX™ microcontroller for automotive & industrial applications with a frequency of 200 MHz, up to 2.5MB of Flash and a LFBGA-292 package
SRAM (incl. Cache): 240.0kByte
CAN Nodes: 5
A/D Input Lines(incl. FADC): 53
Program Memory: 2.5MByte
EEPROM Emulation: yes
Number of ADC Modules: 7.0
Instruction Width([bits]): 32/16
DMA Channels: 48
External Bus Interface: no
Fast Flash Programming: no
Additional Features: Dual Core
Additional Features: Lockstep
Additional Features: Safety IO Monitor
Additional Features: Stand-By Controller
LIN: 4.0
SPI: 4.0
eMMC: no
Hardware Accelerator: no
# of cores / lockstep cores: 2/1
Oscillator Watchdog: Yes
更多
On-chip Voltage Regulator: Yes
On-chip Clock Generation: Yes
I/O Operation Voltages max: 5.0V
Floating Point Unit: Yes
DSP Functionality: Yes
Real Time Clock: Yes
Type of Memory: Flash
Temperature: -40°C - +125°C
Family: AURIX™ 1G
Classification: ISO 26262-compliant
Watchdog Timer: 48
Watchdog Timer: YES
Budgetary Price €/1k: 16.51
ASIL/SIL support: ASIL-D/SIL-3
SAK-TC275T-64F200NDC
分类:数据:
简介: A powerful AURIX™ microcontroller for automotive & industrial applications with a frequency of 200 MHz, up to 4MB of Flash and a LQFP-176 package
SRAM (incl. Cache): 472.0kByte
CAN Nodes: 4
Program Memory: 4.0MByte
Number of ADC Modules: 14.0
EEPROM Emulation: yes
Instruction Width([bits]): 32/16
DMA Channels: 64
External Bus Interface: no
Fast Flash Programming: no
DSP Functionality: yes
On-chip Clock Generation: yes
I/O Operation Voltages: 3.3V
I/O Operation Voltages: 5.0V
Touch/LED Matrix Control: no
On-chip Voltage Regulator: yes
Real Time Clock: yes
Floating Point Unit: yes
Watchdog Timer: yes
Oscillator Watchdog: yes
eMMC: no
更多
SPI: 4.0
LIN: 4.0
# of cores / lockstep cores: 3/2
Hardware Accelerator: no
Type of Memory: Flash
Temperature: -40°C - +125°C
Family: AURIX™ 1G
Classification: ISO 26262-compliant
A/D Input Lines(incl. FADC): 48
Budgetary Price €/1k: 15.7
ASIL/SIL support: ASIL-D/SIL-3
