INFINEON

Infineon 英飞凌专注于迎接现代社会的三大科技挑战：高能效、移动性和安全性，为汽车和工业功率器件、芯片卡和安全应用提供半导体和系统解决方案。英飞凌的产品素以高可靠性、卓越质量和创新性著称，并在模拟和混合信号、射频、功率以及嵌入式控制装置领域掌握尖端技术。

SAK-TC277TC-64F200SDC

分类:
数据:

简介: A powerful AURIX™ microcontroller for automotive & industrial applications with a frequency of 200MHz, up to 4MB of Flash and LFBGA-292 Package

SRAM (incl. Cache): 424.0kByte CAN Nodes: 4 A/D Input Lines(incl. FADC): 60 Program Memory: 4.0MByte Number of ADC Modules: 14.0 EEPROM Emulation: yes Instruction Width([bits]): 32/16 DMA Channels: 64 External Bus Interface: no Fast Flash Programming: no DSP Functionality: yes On-chip Clock Generation: yes I/O Operation Voltages: 3.3V I/O Operation Voltages: 5.0V Touch/LED Matrix Control: no On-chip Voltage Regulator: yes Real Time Clock: yes Floating Point Unit: yes Watchdog Timer: yes Oscillator Watchdog: yes 更多

LIN: 4.0 SPI: 4.0 eMMC: no # of cores / lockstep cores: 3/2 Hardware Accelerator: no Type of Memory: Flash Temperature: -40°C - +125°C Family: AURIX™ 1G Classification: ISO 26262-compliant ASIL/SIL support: ASIL-D/SIL-3

SAK-TC277TF-64F200NDC

分类:
数据:

简介: Debug, Trave, Measure and Calibrate

# of cores / lockstep cores: 3/2 DMA Channels: 64 I/O Operation Voltages max: 5.0V Oscillator Watchdog: yes On-chip Clock Generation: yes Real Time Clock: yes Program Memory: 4.0MByte SRAM (incl. Cache): 472.0kByte Watchdog Timer: yes eMMC: no CAN Nodes: 5 DSP Functionality: yes Floating Point Unit: yes On-chip Voltage Regulator: yes External Bus Interface: no Hardware Accelerator: no LIN: 4.0 SPI: 4.0 Type of Memory: Flash Temperature: -40°C - +125°C 更多

Family: AURIX™ 1G Classification: ISO 26262-compliant A/D Input Lines(incl. FADC): 60 Number of ADC Modules: 14.0 ASIL/SIL support: ASIL-D/SIL-3

SAK-TC277TP-64F200NDC

分类:
数据:

简介: A powerful AURIX™ microcontroller for automotive & industrial applications with a frequency of 200MHz, up to 4MB of Flash and LFBGA-292 Package

SRAM (incl. Cache): 472.0kByte CAN Nodes: 4 A/D Input Lines(incl. FADC): 60 Program Memory: 4.0MByte Number of ADC Modules: 14.0 EEPROM Emulation: yes Instruction Width([bits]): 32/16 DMA Channels: 64 External Bus Interface: no Fast Flash Programming: no DSP Functionality: yes On-chip Clock Generation: yes I/O Operation Voltages: 3.3V I/O Operation Voltages: 5.0V Touch/LED Matrix Control: no On-chip Voltage Regulator: yes Real Time Clock: yes Floating Point Unit: yes Watchdog Timer: yes Oscillator Watchdog: yes 更多

eMMC: no SPI: 4.0 LIN: 4.0 # of cores / lockstep cores: 3/2 Hardware Accelerator: no Type of Memory: Flash Temperature: -40°C - +125°C Family: AURIX™ 1G Classification: ISO26262-compliant Budgetary Price €/1k: 18.4 Budgetary Price €/1k: 18.4 ASIL/SIL support: ASIL-D/SIL-3

SAK-TC277TP-64F200SDC

分类:
数据:

简介: A powerful AURIX™ microcontroller for automotive & industrial applications with a frequency of 200MHz, up to 4MB of Flash and a LFBGA-292 Package

SAK-TC297T-96F300NBC

分类:
数据:

简介: A powerful AURIX™ microcontroller for automotive & industrial applications with a frequency of 300MHz, up to 6MB of Flash and a LFBGA-292 Package

SRAM (incl. Cache): 728.0kByte CAN Nodes: 6 A/D Input Lines(incl. FADC): 60 Program Memory: 6.0MByte Number of ADC Modules: 21.0 EEPROM Emulation: yes Instruction Width([bits]): 32/16 DMA Channels: 128 External Bus Interface: no Fast Flash Programming: no DSP Functionality: yes On-chip Clock Generation: yes I/O Operation Voltages: 3.3V I/O Operation Voltages: 5.0V Touch/LED Matrix Control: no Watchdog Timer: yes Real Time Clock: yes Oscillator Watchdog: yes On-chip Voltage Regulator: yes Floating Point Unit: yes 更多

Additional Features: Ethernet eMMC: no SPI: 4.0 LIN: 5.0 # of cores / lockstep cores: 3/1 Hardware Accelerator: no Type of Memory: Flash Temperature: -40°C - +125°C Family: AURIX™ 1G Classification: ISO26262-compliant ASIL/SIL support: ASIL-D/SIL-3

SAK-TC297TA-128F300NBC

分类:
数据:

简介: A powerful AURIX™ microcontroller with a frequency of 300MHz, up to 8MB of Flash and LFBGA-292 Package

LIN: 5.0 SPI: 4.0 eMMC: no # of cores / lockstep cores: 3/1 Hardware Accelerator: FFT DMA Channels: 128 DSP Functionality: yes Floating Point Unit: yes Program Memory: 8.0MByte SRAM (incl. Cache): 2776.0kByte Real Time Clock: yes Oscillator Watchdog: yes On-chip Voltage Regulator: ys On-chip Clock Generation: yes Number of ADC Modules: 16.0 I/O Operation Voltages max: 5.0V External Bus Interface: no Additional Features: Ethernet Additional Features: Ethernet Watchdog Timer: yes 更多

CAN Nodes: 6 Type of Memory: Flash Temperature: -40°C - +125°C Family: AURIX™ 1G Classification: ISO26262-compliant A/D Input Lines(incl. FADC): 60 Budgetary Price €/1k: 40.75 ASIL/SIL support: ASIL-D/SIL-3

SAK-TC297TA-128F300SBC

分类:
数据:

简介: A powerful AURIX™ microcontroller with a frequency of 300MHz, up to 8MB of Flash and LFBGA-292 Package

eMMC: no LIN: 5.0 SPI: 4.0 Hardware Accelerator: FFT # of cores / lockstep cores: 3/1 Additional Features: Ethernet DMA Channels: 128 CAN Nodes: 6 DSP Functionality: yes External Bus Interface: no Floating Point Unit: yes I/O Operation Voltages max: 5.0V On-chip Clock Generation: yes On-chip Voltage Regulator: yes Oscillator Watchdog: yes SRAM (incl. Cache): 2777.0kByte Watchdog Timer: Yes Real Time Clock: yes Program Memory: 8.0MByte Number of ADC Modules: 16.0 更多

Type of Memory: Flash Temperature: -40°C - +125°C Family: AURIX™ 1G Classification: ISO26262-compliant A/D Input Lines(incl. FADC): 60 Budgetary Price €/1k: 34.63 Budgetary Price €/1k: 34.63 ASIL/SIL support: ASIL-D/SIL-3

SAK-TC297TA-64F300SBC

分类:
数据:

简介: A powerful AURIX™ microcontroller with a frequency of 300MHz, up to 4MB of Flash and LFBGA-292 Package

LIN: 5.0 SPI: 4.0 eMMC: no Hardware Accelerator: FFT # of cores / lockstep cores: 3/1 Additional Features: Ethernet DMA Channels: 128 DSP Functionality: Yes External Bus Interface: no Floating Point Unit: yes CAN Nodes: 6 Real Time Clock: Yes Program Memory: 4.0MByte Oscillator Watchdog: Yes On-chip Voltage Regulator: Yes On-chip Clock Generation: Yes SRAM (incl. Cache): 2778.0kByte I/O Operation Voltages max: 5.0V Watchdog Timer: yes Number of ADC Modules: 16.0 更多

Type of Memory: Flash Temperature: -40°C - +125°C Family: AURIX™ 1G Classification: ISO26262-compliant A/D Input Lines(incl. FADC): 60 Budgetary Price €/1k: 38.07 ASIL/SIL support: ASIL-D/SIL-3

SAK-TC297TC-96F300SBC

分类:
数据:

简介: A powerful AURIX™ microcontroller for automotive & industrial applications with a frequency of 300MHz, up to 6MB of Flash and a LFBGA-292 package

SRAM (incl. Cache): 456.0kByte CAN Nodes: 6 A/D Input Lines(incl. FADC): 72 Program Memory: 6.0MByte Number of ADC Modules: 21.0 EEPROM Emulation: yes Instruction Width([bits]): 32/16 DMA Channels: 128 External Bus Interface: no Fast Flash Programming: no DSP Functionality: yes On-chip Clock Generation: yes I/O Operation Voltages: 3.3V I/O Operation Voltages: 5.0V Touch/LED Matrix Control: no Watchdog Timer: yes Real Time Clock: yes On-chip Voltage Regulator: yes Oscillator Watchdog: yes Floating Point Unit: yes 更多

SAK-TC297TF-128F300NBC

分类:
数据:

简介: Debug, Trave, Measure and Calibrate

# of cores / lockstep cores: 3/1 A/D Input Lines(incl. FADC): 72 CAN Nodes: 6 DSP Functionality: yes DMA Channels: 128 External Bus Interface: no I/O Operation Voltages max: 5.0V Oscillator Watchdog: yes On-chip Voltage Regulator: yes Program Memory: 6.0MByte Real Time Clock: yes eMMC: no SPI: 4.0 LIN: 5.0 Floating Point Unit: yes Hardware Accelerator: no On-chip Clock Generation: yes Watchdog Timer: yes Number of ADC Modules: 16.0 SRAM (incl. Cache): 726.0kByte 更多

Type of Memory: Flash Temperature: -40°C - +125°C Family: AURIX™ 1G Classification: ISO 26262-compliant ASIL/SIL support: ASIL-D/SIL-3
