ANALOG DEVICES INC

Analog Devices, Inc.（NASDAQ: ADI)是全球领先的半导体公司，致力于在现实世界与数字世界之间架起桥梁，以实现智能边缘领域的突破性创新。ADI提供结合模拟、数字和软件技术的解决方案，推动数字化工厂、汽车和数字医疗等领域的持续发展，应对气候变化挑战，并建立人与世界万物的可靠互联。ADI公司2022财年收入超过120亿美元，全球员工约2.5万人。

ADPA1107ACPZN

分类: 微电路 / 微波半导体集成电路 / 放大器 / 功率放大器
数据:

简介: 45.0 dBm (35 W)、4.8 GHz to 6.0 GHz、GaN 功率放大器

RF Primary Function: GaN Power Amp, Power Amp Freq Response RF (min): 4.8GHz Freq Response RF (max): 6GHz Gain dB (typ): 30.5dB Vs (typ): 28V Is (typ): 350mA Package: 40-Lead LFCSP (6mm x 6mm w/ EP) Product Lifecycle: 推荐用于新设计 # of Channels: 1 Vs+ (min): 24V Vs+ (max): 32V Gain dB (min): 28dB Specified at Freq: 5.4GHz Eval / Ref Circuit: Evaluation board Export Classification: 3A001.b.2.a.4 Automotive: No Temp Range: -40 to 85°C Package Area: 36mm² (40-Lead LFCSP (6mm x 6mm w/ EP)) (ADPA1107ACPZN)mm² Package Height: 0.8mm (40-Lead LFCSP (6mm x 6mm w/ EP)) (ADPA1107ACPZN)mm Launch Date: 2021-07-02 EP: No

ADPA1107ACPZN-R7

分类: 微电路 / 微波半导体集成电路 / 放大器 / 功率放大器
数据:

简介: 45.0 dBm (35 W)、4.8 GHz to 6.0 GHz、GaN 功率放大器

RF Primary Function: GaN Power Amp, Power Amp Freq Response RF (min): 4.8GHz Freq Response RF (max): 6GHz Gain dB (typ): 30.5dB Vs (typ): 28V Is (typ): 350mA Package: 40-Lead LFCSP (6mm x 6mm w/ EP) Product Lifecycle: 推荐用于新设计 # of Channels: 1 Vs+ (min): 24V Vs+ (max): 32V Gain dB (min): 28dB Specified at Freq: 5.4GHz Eval / Ref Circuit: Evaluation board Export Classification: 3A001.b.2.a.4 Automotive: No Temp Range: -40 to 85°C Package Area: 36mm² (40-Lead LFCSP (6mm x 6mm w/ EP)) (ADPA1107ACPZN)mm² Package Height: 0.8mm (40-Lead LFCSP (6mm x 6mm w/ EP)) (ADPA1107ACPZN)mm Launch Date: 2021-07-02 EP: No

ADRF5519BCPZN-RL

分类: 微电路 / 半导体集成电路 / 射频电路
数据:

简介: 双通道，2.3 GHz至2.8 GHz，20 W接收器前端

RF Primary Function: Massive MIMO Receiver Front End Freq Response RF (min): 2.3GHz Freq Response RF (max): 2.8GHz Gain dB (typ): 35dB OP1dB (typ): 18dBm NF (typ): 1dB OIP3 (typ): 32dBm Vs (typ): 5V Is (typ): 110mA Package: 40-Lead LFCSP (6mm x 6mm w/ EP) Product Lifecycle: 推荐用于新设计 # of Channels: 2 Vs+ (min): 4.75V Vs+ (max): 5.25V Gain dB (min): 14dB Gain dB (max): 35dB Specified at Freq: 2.6GHz Eval / Ref Circuit: Evaluation board Export Classification: 5A991.b.6 Automotive: No
Temp Range: -40 to 105°C Package Area: 36mm² (40-Lead LFCSP (6mm x 6mm w/ EP)) (ADRF5519BCPZN)mm² Package Height: 1mm (40-Lead LFCSP (6mm x 6mm w/ EP)) (ADRF5519BCPZN)mm Launch Date: 2021-05-04 EP: No

ADRF5519BCPZN-R7

分类: 微电路 / 半导体集成电路 / 射频电路
数据:

简介: 双通道，2.3 GHz至2.8 GHz，20 W接收器前端

RF Primary Function: Massive MIMO Receiver Front End Freq Response RF (min): 2.3GHz Freq Response RF (max): 2.8GHz Gain dB (typ): 35dB OP1dB (typ): 18dBm NF (typ): 1dB OIP3 (typ): 32dBm Vs (typ): 5V Is (typ): 110mA Package: 40-Lead LFCSP (6mm x 6mm w/ EP) Product Lifecycle: 推荐用于新设计 # of Channels: 2 Vs+ (min): 4.75V Vs+ (max): 5.25V Gain dB (min): 14dB Gain dB (max): 35dB Specified at Freq: 2.6GHz Eval / Ref Circuit: Evaluation board Export Classification: 5A991.b.6 Automotive: No
Temp Range: -40 to 105°C Package Area: 36mm² (40-Lead LFCSP (6mm x 6mm w/ EP)) (ADRF5519BCPZN)mm² Package Height: 1mm (40-Lead LFCSP (6mm x 6mm w/ EP)) (ADRF5519BCPZN)mm Launch Date: 2021-05-04 EP: No

ADRF5519BCPZN

分类: 微电路 / 半导体集成电路 / 射频电路
数据:

简介: 双通道，2.3 GHz至2.8 GHz，20 W接收器前端

RF Primary Function: Massive MIMO Receiver Front End Freq Response RF (min): 2.3GHz Freq Response RF (max): 2.8GHz Gain dB (typ): 35dB OP1dB (typ): 18dBm NF (typ): 1dB OIP3 (typ): 32dBm Vs (typ): 5V Is (typ): 110mA Package: 40-Lead LFCSP (6mm x 6mm w/ EP) Product Lifecycle: 推荐用于新设计 # of Channels: 2 Vs+ (min): 4.75V Vs+ (max): 5.25V Gain dB (min): 14dB Gain dB (max): 35dB Specified at Freq: 2.6GHz Eval / Ref Circuit: Evaluation board Export Classification: 5A991.b.6 Automotive: No
Temp Range: -40 to 105°C Package Area: 36mm² (40-Lead LFCSP (6mm x 6mm w/ EP)) (ADRF5519BCPZN)mm² Package Height: 1mm (40-Lead LFCSP (6mm x 6mm w/ EP)) (ADRF5519BCPZN)mm Launch Date: 2021-05-04 EP: No

ADL9005ACPZN

分类: 微电路 / 微波半导体集成电路 / 放大器 / 低噪声放大器
数据:

简介: 采用单一正电源的0.01 GHz至26.5 GHz宽带低噪声放大器

RF Primary Function: LNA, Wideband Distributed Amps Freq Response RF (min): 10MHz Freq Response RF (max): 26.5GHz Gain dB (typ): 18.5dB OP1dB (typ): 13.5dBm NF (typ): 2.5dB OIP3 (typ): 25dBm Vs (typ): 5V Is (typ): 80mA Package: 24-Lead LFCSP (4mm x 4mm w/ EP) Product Lifecycle: 推荐用于新设计 # of Channels: 1 Vs+ (min): 4.5V Vs+ (max): 8.5V Specified at Freq: 10GHz Eval / Ref Circuit: Evaluation board Export Classification: EAR99 Automotive: No Temp Range: -40 to 85°C Package Area: 16mm² (24-Lead LFCSP (4mm x 4mm w/ EP)) (ADL9005ACPZN-R7)mm²
Package Height: 0.8mm (24-Lead LFCSP (4mm x 4mm w/ EP)) (ADL9005ACPZN-R7)mm Launch Date: 2021-02-04 EP: No

ADL9005ACPZN-R7

分类: 微电路 / 微波半导体集成电路 / 放大器 / 低噪声放大器
数据:

简介: 采用单一正电源的0.01 GHz至26.5 GHz宽带低噪声放大器

RF Primary Function: LNA, Wideband Distributed Amps Freq Response RF (min): 10MHz Freq Response RF (max): 26.5GHz Gain dB (typ): 18.5dB OP1dB (typ): 13.5dBm NF (typ): 2.5dB OIP3 (typ): 25dBm Vs (typ): 5V Is (typ): 80mA Package: 24-Lead LFCSP (4mm x 4mm w/ EP) Product Lifecycle: 推荐用于新设计 # of Channels: 1 Vs+ (min): 4.5V Vs+ (max): 8.5V Specified at Freq: 10GHz Eval / Ref Circuit: Evaluation board Export Classification: EAR99 Automotive: No Temp Range: -40 to 85°C Package Area: 16mm² (24-Lead LFCSP (4mm x 4mm w/ EP)) (ADL9005ACPZN-R7)mm²
Package Height: 0.8mm (24-Lead LFCSP (4mm x 4mm w/ EP)) (ADL9005ACPZN-R7)mm Launch Date: 2021-02-04 EP: No

ADL5580BCCZ-R7

分类: 微电路 / 半导体集成电路 / 模拟集成电路 / 放大器 / 运算放大器
数据:

简介: 具有 10 dB 增益的全差分 10 GHz ADC 驱动器

RF Primary Function: Differential Amplifier Freq Response RF (max): 10GHz Gain dB (typ): 10dB OP1dB (typ): 17.5dBm NF (typ): 11.3dB OIP3 (typ): 43.6dBm Vs (typ): 5V Is (typ): 276mA Package: 20-Terminal LGA (4mm x 4mm x 0.81mm) Product Lifecycle: 推荐用于新设计 # of Channels: 1 Vs+ (min): 4.75V Vs+ (max): 5.25V Gain dB (min): 10dB Gain dB (max): 10dB Specified at Freq: 100MHz Eval / Ref Circuit: Evaluation board Export Classification: EAR99 Automotive: No Temp Range: -40 to 85°C
Package Area: 16mm² (20-Terminal LGA (4mm x 4mm x 0.81mm)) (ADL5580BCCZ-R7)mm² Package Height: 0.81mm (20-Terminal LGA (4mm x 4mm x 0.81mm)) (ADL5580BCCZ-R7)mm Launch Date: 2020-12-17 EP: No

ADRF5515BCPZN

分类: 微电路 / 半导体集成电路 / 射频电路
数据:

简介: 双通道，3.3 GHz至4.0 GHz，20 W接收器前端

RF Primary Function: Massive MIMO Receiver Front End Freq Response RF (min): 3.4GHz Freq Response RF (max): 3.8GHz Gain dB (typ): 33dB OP1dB (typ): 18dBm NF (typ): 1dB OIP3 (typ): 32dBm Vs (typ): 5V Is (typ): 36mA Package: 40-Lead LFCSP (6mm x 6mm w/ EP) Product Lifecycle: 推荐用于新设计 # of Channels: 2 Vs+ (min): 4.75V Vs+ (max): 5.25V Gain dB (min): 16dB Gain dB (max): 33dB Specified at Freq: 3.6GHz Eval / Ref Circuit: Evaluation board Export Classification: 5A991.b.6 Automotive: No
Temp Range: -40 to 105°C Package Area: 36mm² (40-Lead LFCSP (6mm x 6mm w/ EP)) (ADRF5515BCPZN-RL)mm² Package Height: 1mm (40-Lead LFCSP (6mm x 6mm w/ EP)) (ADRF5515BCPZN-RL)mm Launch Date: 2020-11-20 EP: No

ADRF5515BCPZN-RL

分类: 微电路 / 半导体集成电路 / 射频电路
数据:

简介: 双通道，3.3 GHz至4.0 GHz，20 W接收器前端

RF Primary Function: Massive MIMO Receiver Front End Freq Response RF (min): 3.4GHz Freq Response RF (max): 3.8GHz Gain dB (typ): 33dB OP1dB (typ): 18dBm NF (typ): 1dB OIP3 (typ): 32dBm Vs (typ): 5V Is (typ): 36mA Package: 40-Lead LFCSP (6mm x 6mm w/ EP) Product Lifecycle: 推荐用于新设计 # of Channels: 2 Vs+ (min): 4.75V Vs+ (max): 5.25V Gain dB (min): 16dB Gain dB (max): 33dB Specified at Freq: 3.6GHz Eval / Ref Circuit: Evaluation board Export Classification: 5A991.b.6 Automotive: No
Temp Range: -40 to 105°C Package Area: 36mm² (40-Lead LFCSP (6mm x 6mm w/ EP)) (ADRF5515BCPZN-RL)mm² Package Height: 1mm (40-Lead LFCSP (6mm x 6mm w/ EP)) (ADRF5515BCPZN-RL)mm Launch Date: 2020-11-20 EP: No
