Number of channels: 4 Total supply voltage (+5 V = 5, ±5 V = 10) (max) (V): 40 Total supply voltage (+5 V = 5, ±5 V = 10) (min) (V): 2.7 Rail-to-rail: In, Out GBW (typ) (MHz): 4.5 Slew rate (typ) (V/µs): 21 Vos (offset voltage at 25°C) (max) (mV): 0.895 Iq per channel (typ) (mA): 0.56 Vn at 1 kHz (typ) (nV√Hz): 10.8 Rating: HiRel Enhanced Product Operating temperature range (°C): -55 to 125 Offset drift (typ) (µV/°C): 0.3 Features: EMI Hardened, High Cload Drive, MUX Friendly, Small Size CMRR (typ) (dB): 130 Iout (typ) (A): 0.075 Architecture: CMOS Input common mode headroom (to negative supply) (typ) (V): -0.01 Input common mode headroom (to positive supply) (typ) (V): 0.01 Output swing headroom (to negative supply) (typ) (V): 0.025 Output swing headroom (to positive supply) (typ) (V): -0.025

Common-mode voltage (max) (V): 110 Common-mode voltage (min) (V): -5 Input offset (±) (max) (µV): 8, 10, 15, 20 Input offset drift (±) (typ) (µV/°C): 0.1 Voltage gain (V/V): 10, 20, 50, 100, 200 CMRR (min) (dB): 150 Bandwidth (kHz): 1100 Supply voltage (max) (V): 20 Supply voltage (min) (V): 2.7 Iq (max) (mA): 3.2 Number of channels: 1 Comparators (#): 0 Gain error (%): 0.01, 0.015 Gain error drift (±) (max) (ppm/°C): 1 Slew rate (V/µs): 8 Features: Bidirectional, Low-side Capable, Ultra precise Rating: Catalog Operating temperature range (°C): -40 to 125

Common-mode voltage (max) (V): 110 Common-mode voltage (min) (V): -5 Input offset (±) (max) (µV): 150 Input offset drift (±) (typ) (µV/°C): 0.1 Voltage gain (V/V): 10, 20, 50, 100, 200 CMRR (min) (dB): 120 Bandwidth (kHz): 1100 Supply voltage (max) (V): 20 Supply voltage (min) (V): 2.7 Iq (max) (mA): 3.2 Number of channels: 1 Comparators (#): 0 Gain error (%): 0.1 Gain error drift (±) (max) (ppm/°C): 5 Slew rate (V/µs): 8 Features: Bidirectional, High precision, Low-side Capable Rating: Catalog Operating temperature range (°C): -40 to 125

Creepage (min) (mm): 15.7 Clearance (min) (mm): 15.7 Input offset (±) (max) (V): 0.0002 Input offset drift (±) (typ) (V/°C): 0.0000001 Rating: Catalog Operating temperature range (°C): -40 to 125

Input common mode headroom (to positive supply) (typ) (V): -2.5 Noise at 0.1 Hz to 10 Hz (typ) (µVPP): 0.1 Number of channels: 1 Vs (max) (V): 36 Vs (min) (V): 8 Input offset (±) (max) (µV): 35 Voltage gain (min) (V/V): 0.2 Voltage gain (max) (V/V): 1000 Noise at 1 kHz (typ) (nV√Hz): 3.2 CMRR (min) (dB): 120 Input offset drift (±) (max) (V/°C): 0.0000004 Input bias current (±) (max) (nA): 20 Iq (typ) (mA): 6 Bandwidth at min gain (typ) (MHz): 22 Gain error (±) (max) (%): 0.15 Operating temperature range (°C): -40 to 125 Rating: Catalog Type: Resistor Gain nonlinearity (±) (max) (%): 0.0002 Output swing headroom (to negative supply) (typ) (V): 1.4 Output swing headroom (to positive supply) (typ) (V): -1.4 Input common mode headroom (to negative supply) (typ) (V): 2.5 Input common mode headroom (to positive supply) (typ) (V): -2.5 Noise at 0.1 Hz to 10 Hz (typ) (µVPP): 0.1

Output swing headroom (to positive supply) (typ) (V): -0.001 Number of channels: 1 Total supply voltage (+5 V = 5, ±5 V = 10) (max) (V): 5.5 Total supply voltage (+5 V = 5, ±5 V = 10) (min) (V): 1.5 Rail-to-rail: In, Out GBW (typ) (MHz): 3 Slew rate (typ) (V/µs): 3 Vos (offset voltage at 25°C) (max) (mV): 1.3 Iq per channel (typ) (mA): 0.165 Vn at 1 kHz (typ) (nV√Hz): 16 Rating: Catalog Operating temperature range (°C): -40 to 125 Offset drift (typ) (µV/°C): 0.5 Features: Shutdown, Small Size Input bias current (max) (pA): 30 CMRR (typ) (dB): 95 Iout (typ) (A): 0.15 Architecture: CMOS Input common mode headroom (to negative supply) (typ) (V): -0.1 Input common mode headroom (to positive supply) (typ) (V): 0.1 Output swing headroom (to negative supply) (typ) (V): 0.001 Output swing headroom (to positive supply) (typ) (V): -0.001

Iq per channel (typ) (mA): 17 Input bias current (±) (max) (nA): 10000 Rail-to-rail: In to V+ Rating: Catalog Operating temperature range (°C): -40 to 125 Features: Hysteresis VICR (max) (V): 5.25 VICR (min) (V): 1.5

Output swing headroom (to positive supply) (typ) (V): -1.4 Number of channels: 4 Total supply voltage (+5 V = 5, ±5 V = 10) (max) (V): 36 Total supply voltage (+5 V = 5, ±5 V = 10) (min) (V): 3 Rail-to-rail: In to V- GBW (typ) (MHz): 1.2 Slew rate (typ) (V/µs): 0.5 Vos (offset voltage at 25°C) (max) (mV): 3 Iq per channel (typ) (mA): 0.175 Vn at 1 kHz (typ) (nV√Hz): 35 Rating: Catalog Operating temperature range (°C): -40 to 125 Offset drift (typ) (µV/°C): 7 Features: Cost Optimized, EMI Hardened, Standard Amps Input bias current (max) (pA): 35000 CMRR (typ) (dB): 80 Iout (typ) (A): 0.04 Architecture: Bipolar Input common mode headroom (to negative supply) (typ) (V): 0 Input common mode headroom (to positive supply) (typ) (V): -1.5 Output swing headroom (to negative supply) (typ) (V): 0.005 Output swing headroom (to positive supply) (typ) (V): -1.4

Output swing headroom (to positive supply) (typ) (V): -1.4 Number of channels: 4 Total supply voltage (+5 V = 5, ±5 V = 10) (max) (V): 36 Total supply voltage (+5 V = 5, ±5 V = 10) (min) (V): 3 Rail-to-rail: In to V- GBW (typ) (MHz): 1.2 Slew rate (typ) (V/µs): 0.5 Vos (offset voltage at 25°C) (max) (mV): 3 Iq per channel (typ) (mA): 0.175 Vn at 1 kHz (typ) (nV√Hz): 35 Rating: Catalog Operating temperature range (°C): -40 to 85 Offset drift (typ) (µV/°C): 7 Features: Cost Optimized, EMI Hardened, Standard Amps Input bias current (max) (pA): 35000 CMRR (typ) (dB): 80 Iout (typ) (A): 0.04 Architecture: Bipolar Input common mode headroom (to negative supply) (typ) (V): 0 Input common mode headroom (to positive supply) (typ) (V): -1.5 Output swing headroom (to negative supply) (typ) (V): 0.005 Output swing headroom (to positive supply) (typ) (V): -1.4

Iq per channel (typ) (mA): 20 Input bias current (±) (max) (nA): 10000 Rail-to-rail: In to V+ Rating: Automotive Operating temperature range (°C): -40 to 125 Features: Hysteresis, Split-supply VICR (max) (V): 5.25 VICR (min) (V): 1.5
