OPA4310
分类: 微电路 / 半导体集成电路 / 模拟集成电路 / 放大器 / 运算放大器数据:
简介: 四通道、5.5V、3MHz 高输出电流 (150mA) 快速关断 (1μs) 运算放大器
Number of channels: 4
Total supply voltage (+5 V = 5, ±5 V = 10) (max) (V): 5.5
Total supply voltage (+5 V = 5, ±5 V = 10) (min) (V): 1.5
Rail-to-rail: In, Out
GBW (typ) (MHz): 3
Slew rate (typ) (V/µs): 3
Vos (offset voltage at 25°C) (max) (mV): 1.3
Iq per channel (typ) (mA): 0.165
Vn at 1 kHz (typ) (nV√Hz): 16
Rating: Catalog
Operating temperature range (°C): -40 to 125
Offset drift (typ) (µV/°C): 0.5
Features: Shutdown, Small Size
Input bias current (max) (pA): 30
CMRR (typ) (dB): 95
Iout (typ) (A): 0.15
Architecture: CMOS
Input common mode headroom (to negative supply) (typ) (V): -0.1
Input common mode headroom (to positive supply) (typ) (V): 0.1
Output swing headroom (to negative supply) (typ) (V): 0.001
