CSD18503KCS
数据:
分类: 半导体分立器件和附件 / 晶体管 / 普通晶体管 / 场效应晶体管 / 绝缘栅场效应晶体管
描述: 采用 TO-220 封装的单路、4.5mΩ、40V、N 沟道 NexFET™ 功率 MOSFET
VDS (V): 40
VGS (V): 20
Type: N-channel
Configuration: Single
Rds(on) at VGS=10 V (max) (mΩ): 4.5
Rds(on) at VGS=4.5 V (max) (mΩ): 6.8
VGSTH typ (typ) (V): 1.9
QG (typ) (nC): 30
QGD (typ) (nC): 4.6
QGS (typ) (nC): 7.7
ID - silicon limited at TC=25°C (A): 142
ID - package limited (A): 100
Logic level: Yes
Rating: Catalog
Operating temperature range (°C): -55 to 175
VDS (V): 40
VGS (V): 20
Type: N-channel
Configuration: Single
Rds(on) at VGS=10 V (max) (mΩ): 4.5
更多
Rds(on) at VGS=4.5 V (max) (mΩ): 6.8
VGSTH typ (typ) (V): 1.9
QG (typ) (nC): 30
QGD (typ) (nC): 4.6
QGS (typ) (nC): 7.7
ID - silicon limited at TC=25°C (A): 142
ID - package limited (A): 100
Logic level: Yes
Rating: Catalog
Operating temperature range (°C): -55 to 175
CSD17551Q3A
数据:
分类: 半导体分立器件和附件 / 晶体管 / 普通晶体管 / 场效应晶体管 / 绝缘栅场效应晶体管
描述: 采用 3mm x 3mm SON 封装的单路、9mΩ、30V、N 沟道 NexFET™ 功率 MOSFET
VDS (V): 30
VGS (V): 20
Type: N-channel
Configuration: Single
Rds(on) at VGS=10 V (max) (mΩ): 9
Rds(on) at VGS=4.5 V (max) (mΩ): 11.8
VGSTH typ (typ) (V): 1.6
QG (typ) (nC): 6
QGD (typ) (nC): 1.5
QGS (typ) (nC): 2.3
ID - silicon limited at TC=25°C (A): 48
ID - package limited (A): 48
Logic level: Yes
Rating: Catalog
Operating temperature range (°C): -55 to 150
VDS (V): 30
VGS (V): 20
Type: N-channel
Configuration: Single
Rds(on) at VGS=10 V (max) (mΩ): 9
更多
Rds(on) at VGS=4.5 V (max) (mΩ): 11.8
VGSTH typ (typ) (V): 1.6
QG (typ) (nC): 6
QGD (typ) (nC): 1.5
QGS (typ) (nC): 2.3
ID - silicon limited at TC=25°C (A): 48
ID - package limited (A): 48
Logic level: Yes
Rating: Catalog
Operating temperature range (°C): -55 to 150
CSD18533KCS
数据:
分类: 半导体分立器件和附件 / 晶体管 / 普通晶体管 / 场效应晶体管 / 绝缘栅场效应晶体管
描述: 采用 TO-220 封装的单路、6.3mΩ、60V、N 沟道 NexFET™ 功率 MOSFET
VDS (V): 60
VGS (V): 20
Type: N-channel
Configuration: Single
Rds(on) at VGS=10 V (max) (mΩ): 6.3
Rds(on) at VGS=4.5 V (max) (mΩ): 9
VGSTH typ (typ) (V): 1.9
QG (typ) (nC): 28
QGD (typ) (nC): 3.9
QGS (typ) (nC): 9.4
ID - silicon limited at TC=25°C (A): 118
ID - package limited (A): 100
Logic level: Yes
Rating: Catalog
Operating temperature range (°C): -55 to 175
VDS (V): 60
VGS (V): 20
Type: N-channel
Configuration: Single
Rds(on) at VGS=10 V (max) (mΩ): 6.3
更多
Rds(on) at VGS=4.5 V (max) (mΩ): 9
VGSTH typ (typ) (V): 1.9
QG (typ) (nC): 28
QGD (typ) (nC): 3.9
QGS (typ) (nC): 9.4
ID - silicon limited at TC=25°C (A): 118
ID - package limited (A): 100
Logic level: Yes
Rating: Catalog
Operating temperature range (°C): -55 to 175
CSD18533Q5A
数据:
分类: 半导体分立器件和附件 / 晶体管 / 普通晶体管 / 场效应晶体管 / 绝缘栅场效应晶体管
描述: 采用 5mm x 6mm SON 封装的单路、5.9mΩ、60V、N 沟道 NexFET™ 功率 MOSFET
VDS (V): 60
VGS (V): 20
Type: N-channel
Configuration: Single
Rds(on) at VGS=10 V (max) (mΩ): 5.9
Rds(on) at VGS=4.5 V (max) (mΩ): 8.5
VGSTH typ (typ) (V): 1.9
QG (typ) (nC): 29
QGD (typ) (nC): 5.4
QGS (typ) (nC): 6.6
ID - silicon limited at TC=25°C (A): 103
ID - package limited (A): 100
Logic level: Yes
Rating: Catalog
Operating temperature range (°C): -55 to 150
VDS (V): 60
VGS (V): 20
Type: N-channel
Configuration: Single
Rds(on) at VGS=10 V (max) (mΩ): 5.9
更多
Rds(on) at VGS=4.5 V (max) (mΩ): 8.5
VGSTH typ (typ) (V): 1.9
QG (typ) (nC): 29
QGD (typ) (nC): 5.4
QGS (typ) (nC): 6.6
ID - silicon limited at TC=25°C (A): 103
ID - package limited (A): 100
Logic level: Yes
Rating: Catalog
Operating temperature range (°C): -55 to 150
CSD18534KCS
数据:
分类: 半导体分立器件和附件 / 晶体管 / 普通晶体管 / 场效应晶体管 / 绝缘栅场效应晶体管
描述: 采用 TO-220 封装的单路、9.5mΩ、60V、N 沟道 NexFET™ 功率 MOSFET
VDS (V): 60
VGS (V): 20
Type: N-channel
Configuration: Single
Rds(on) at VGS=10 V (max) (mΩ): 9.5
Rds(on) at VGS=4.5 V (max) (mΩ): 13.3
VGSTH typ (typ) (V): 1.9
QG (typ) (nC): 19
QGD (typ) (nC): 3.1
QGS (typ) (nC): 4.8
ID - silicon limited at TC=25°C (A): 73
ID - package limited (A): 100
Logic level: Yes
Rating: Catalog
Operating temperature range (°C): -55 to 175
VDS (V): 60
VGS (V): 20
Type: N-channel
Configuration: Single
Rds(on) at VGS=10 V (max) (mΩ): 9.5
更多
Rds(on) at VGS=4.5 V (max) (mΩ): 13.3
VGSTH typ (typ) (V): 1.9
QG (typ) (nC): 19
QGD (typ) (nC): 3.1
QGS (typ) (nC): 4.8
ID - silicon limited at TC=25°C (A): 73
ID - package limited (A): 100
Logic level: Yes
Rating: Catalog
Operating temperature range (°C): -55 to 175
CSD86360Q5D
数据:
分类: 半导体分立器件和附件 / 晶体管 / 普通晶体管 / 场效应晶体管 / 绝缘栅场效应晶体管
描述: 采用 5mm x 6mm SON 封装的 50A、25V、N 沟道同步降压 NexFET™ 功率 MOSFET 电源块
VDS (V): 25
VGS (V): 10
Type: Power block
Configuration: PowerBlock
ID - continuous drain current at TA=25°C (A): 50
Power loss (W): 2.6
Ploss current (A): 25
Features: Power supply
Rating: Catalog
Operating temperature range (°C): -55 to 150
VDS (V): 25
VGS (V): 10
Type: Power block
Configuration: PowerBlock
ID - continuous drain current at TA=25°C (A): 50
Power loss (W): 2.6
Ploss current (A): 25
Features: Power supply
Rating: Catalog
Operating temperature range (°C): -55 to 150
CSD18502KCS
数据:
分类: 半导体分立器件和附件 / 晶体管 / 普通晶体管 / 场效应晶体管 / 绝缘栅场效应晶体管
描述: 采用 TO-220 封装的单路、2.9mΩ、40V、N 沟道 NexFET™ 功率 MOSFET
VDS (V): 40
VGS (V): 20
Type: N-channel
Configuration: Single
Rds(on) at VGS=10 V (max) (mΩ): 2.9
Rds(on) at VGS=4.5 V (max) (mΩ): 4.3
VGSTH typ (typ) (V): 1.8
QG (typ) (nC): 52
QGD (typ) (nC): 8.4
QGS (typ) (nC): 10.3
ID - silicon limited at TC=25°C (A): 212
ID - package limited (A): 100
Logic level: Yes
Rating: Catalog
Operating temperature range (°C): -55 to 175
VDS (V): 40
VGS (V): 20
Type: N-channel
Configuration: Single
Rds(on) at VGS=10 V (max) (mΩ): 2.9
更多
Rds(on) at VGS=4.5 V (max) (mΩ): 4.3
VGSTH typ (typ) (V): 1.8
QG (typ) (nC): 52
QGD (typ) (nC): 8.4
QGS (typ) (nC): 10.3
ID - silicon limited at TC=25°C (A): 212
ID - package limited (A): 100
Logic level: Yes
Rating: Catalog
Operating temperature range (°C): -55 to 175
CSD18532KCS
数据:
分类: 半导体分立器件和附件 / 晶体管 / 普通晶体管 / 场效应晶体管 / 绝缘栅场效应晶体管
描述: 采用 TO-220 封装的单路、4.2mΩ、60V、N 沟道 NexFET™ 功率 MOSFET
VDS (V): 60
VGS (V): 20
Type: N-channel
Configuration: Single
Rds(on) at VGS=10 V (max) (mΩ): 4.2
Rds(on) at VGS=4.5 V (max) (mΩ): 5.3
VGSTH typ (typ) (V): 1.8
QG (typ) (nC): 44
QGD (typ) (nC): 6.9
QGS (typ) (nC): 10
ID - silicon limited at TC=25°C (A): 169
ID - package limited (A): 100
Logic level: Yes
Rating: Catalog
Operating temperature range (°C): -55 to 175
VDS (V): 60
VGS (V): 20
Type: N-channel
Configuration: Single
Rds(on) at VGS=10 V (max) (mΩ): 4.2
更多
Rds(on) at VGS=4.5 V (max) (mΩ): 5.3
VGSTH typ (typ) (V): 1.8
QG (typ) (nC): 44
QGD (typ) (nC): 6.9
QGS (typ) (nC): 10
ID - silicon limited at TC=25°C (A): 169
ID - package limited (A): 100
Logic level: Yes
Rating: Catalog
Operating temperature range (°C): -55 to 175
CSD17555Q5A
数据:
分类: 半导体分立器件和附件 / 晶体管 / 普通晶体管 / 场效应晶体管 / 绝缘栅场效应晶体管
描述: 采用 5mm x 6mm SON 封装的单路、2.7mΩ、30V、N 沟道 NexFET™ 功率 MOSFET
VDS (V): 30
VGS (V): 20
Type: N-channel
Configuration: Single
Rds(on) at VGS=10 V (max) (mΩ): 2.7
Rds(on) at VGS=4.5 V (max) (mΩ): 3.4
VGSTH typ (typ) (V): 1.5
QG (typ) (nC): 23
QGD (typ) (nC): 5
QGS (typ) (nC): 7.5
ID - silicon limited at TC=25°C (A): 116
ID - package limited (A): 100
Logic level: Yes
Rating: Catalog
Operating temperature range (°C): -55 to 150
VDS (V): 30
VGS (V): 20
Type: N-channel
Configuration: Single
Rds(on) at VGS=10 V (max) (mΩ): 2.7
更多
Rds(on) at VGS=4.5 V (max) (mΩ): 3.4
VGSTH typ (typ) (V): 1.5
QG (typ) (nC): 23
QGD (typ) (nC): 5
QGS (typ) (nC): 7.5
ID - silicon limited at TC=25°C (A): 116
ID - package limited (A): 100
Logic level: Yes
Rating: Catalog
Operating temperature range (°C): -55 to 150
CSD17551Q5A
数据:
分类: 半导体分立器件和附件 / 晶体管 / 普通晶体管 / 场效应晶体管 / 绝缘栅场效应晶体管
描述: 采用 5mm x 6mm SON 封装的单路、8.8mΩ、30V、N 沟道 NexFET™ 功率 MOSFET
VDS (V): 30
VGS (V): 20
Type: N-channel
Configuration: Single
Rds(on) at VGS=10 V (max) (mΩ): 8.8
Rds(on) at VGS=4.5 V (max) (mΩ): 11
VGSTH typ (typ) (V): 1.7
QG (typ) (nC): 6
QGD (typ) (nC): 1.4
QGS (typ) (nC): 2.8
ID - silicon limited at TC=25°C (A): 48
ID - package limited (A): 48
Logic level: Yes
Rating: Catalog
Operating temperature range (°C): -55 to 150
VDS (V): 30
VGS (V): 20
Type: N-channel
Configuration: Single
Rds(on) at VGS=10 V (max) (mΩ): 8.8
更多
Rds(on) at VGS=4.5 V (max) (mΩ): 11
VGSTH typ (typ) (V): 1.7
QG (typ) (nC): 6
QGD (typ) (nC): 1.4
QGS (typ) (nC): 2.8
ID - silicon limited at TC=25°C (A): 48
ID - package limited (A): 48
Logic level: Yes
Rating: Catalog
Operating temperature range (°C): -55 to 150
