Number of channels: 1 Total supply voltage (+5 V = 5, ±5 V = 10) (max) (V): 5 Total supply voltage (+5 V = 5, ±5 V = 10) (min) (V): 2 Rail-to-rail: No GBW (typ) (MHz): 7 Slew rate (typ) (V/µs): 3 Vos (offset voltage at 25°C) (max) (mV): 6 Iq per channel (typ) (mA): 1.75 Vn at 1 kHz (typ) (nV√Hz): 8 Rating: Catalog Operating temperature range (°C): -40 to 85 Offset drift (typ) (µV/°C): 0 Input bias current (max) (pA): 150000 CMRR (typ) (dB): 60 Iout (typ) (A): 0.0012 Architecture: Bipolar Input common mode headroom (to negative supply) (typ) (V): 1 Input common mode headroom (to positive supply) (typ) (V): -1 Output swing headroom (to negative supply) (typ) (V): 0.1 Output swing headroom (to positive supply) (typ) (V): -0.1

Number of channels: 2 Total supply voltage (+5 V = 5, ±5 V = 10) (max) (V): 5 Total supply voltage (+5 V = 5, ±5 V = 10) (min) (V): 2 Rail-to-rail: No GBW (typ) (MHz): 7 Slew rate (typ) (V/µs): 3 Vos (offset voltage at 25°C) (max) (mV): 6 Iq per channel (typ) (mA): 1.75 Vn at 1 kHz (typ) (nV√Hz): 8 Rating: Catalog Operating temperature range (°C): -40 to 85 Offset drift (typ) (µV/°C): 0 Input bias current (max) (pA): 150000 CMRR (typ) (dB): 60 Iout (typ) (A): 0.0012 Architecture: Bipolar Input common mode headroom (to negative supply) (typ) (V): 1 Input common mode headroom (to positive supply) (typ) (V): -1 Output swing headroom (to negative supply) (typ) (V): 0.1 Output swing headroom (to positive supply) (typ) (V): -0.1

Number of channels: 1 Total supply voltage (+5 V = 5, ±5 V = 10) (max) (V): 36 Total supply voltage (+5 V = 5, ±5 V = 10) (min) (V): 7 Rail-to-rail: No GBW (typ) (MHz): 1 Slew rate (typ) (V/µs): 0.5 Vos (offset voltage at 25°C) (max) (mV): 5 Iq per channel (typ) (mA): 1.7 Vn at 1 kHz (typ) (nV√Hz): 20 Rating: Catalog Operating temperature range (°C): 0 to 70 Offset drift (typ) (µV/°C): 0 Input bias current (max) (pA): 500000 CMRR (typ) (dB): 90 Iout (typ) (A): 0.025 Architecture: Bipolar Input common mode headroom (to negative supply) (typ) (V): 2 Input common mode headroom (to positive supply) (typ) (V): -2 Output swing headroom (to negative supply) (typ) (V): 2 Output swing headroom (to positive supply) (typ) (V): -2

Number of channels: 4 Total supply voltage (+5 V = 5, ±5 V = 10) (max) (V): 36 Total supply voltage (+5 V = 5, ±5 V = 10) (min) (V): 7 Rail-to-rail: No GBW (typ) (MHz): 1 Slew rate (typ) (V/µs): 0.5 Vos (offset voltage at 25°C) (max) (mV): 5 Iq per channel (typ) (mA): 1.7 Vn at 1 kHz (typ) (nV√Hz): 20 Rating: Catalog Operating temperature range (°C): 0 to 70 Offset drift (typ) (µV/°C): 0 Input bias current (max) (pA): 500000 CMRR (typ) (dB): 90 Iout (typ) (A): 0.025 Architecture: Bipolar Input common mode headroom (to negative supply) (typ) (V): 2 Input common mode headroom (to positive supply) (typ) (V): -2 Output swing headroom (to negative supply) (typ) (V): 2 Output swing headroom (to positive supply) (typ) (V): -2

Number of channels: 1 Total supply voltage (+5 V = 5, ±5 V = 10) (max) (V): 36 Total supply voltage (+5 V = 5, ±5 V = 10) (min) (V): 7 Rail-to-rail: In to V+ GBW (typ) (MHz): 2 Slew rate (typ) (V/µs): 3.4 Vos (offset voltage at 25°C) (max) (mV): 3 Iq per channel (typ) (mA): 0.29 Vn at 1 kHz (typ) (nV√Hz): 40 Rating: Catalog Operating temperature range (°C): -40 to 85 Offset drift (typ) (µV/°C): 6 Input bias current (max) (pA): 60 CMRR (typ) (dB): 90 Iout (typ) (A): 0.045 Architecture: FET Input common mode headroom (to negative supply) (typ) (V): 3 Input common mode headroom (to positive supply) (typ) (V): 1 Output swing headroom (to negative supply) (typ) (V): 1.3 Output swing headroom (to positive supply) (typ) (V): -1.3

Number of channels: 2 Total supply voltage (+5 V = 5, ±5 V = 10) (max) (V): 36 Total supply voltage (+5 V = 5, ±5 V = 10) (min) (V): 7 Rail-to-rail: In to V+ GBW (typ) (MHz): 2 Slew rate (typ) (V/µs): 3.4 Vos (offset voltage at 25°C) (max) (mV): 2 Iq per channel (typ) (mA): 0.312 Vn at 1 kHz (typ) (nV√Hz): 40 Rating: Catalog Operating temperature range (°C): -40 to 85 Offset drift (typ) (µV/°C): 6 Input bias current (max) (pA): 60 CMRR (typ) (dB): 90 Iout (typ) (A): 0.045 Architecture: FET Input common mode headroom (to negative supply) (typ) (V): 3 Input common mode headroom (to positive supply) (typ) (V): 1 Output swing headroom (to negative supply) (typ) (V): 1.3 Output swing headroom (to positive supply) (typ) (V): -1.3

Output swing headroom (to positive supply) (typ) (V): -2.7 THD + N at 1 kHz (typ) (%): 0.00003 Number of channels: 1 Total supply voltage (+5 V = 5, ±5 V = 10) (max) (V): 36 Total supply voltage (+5 V = 5, ±5 V = 10) (min) (V): 9 Vos (offset voltage at 25°C) (max) (mV): 0.1 Offset drift (typ) (µV/°C): 0.4 Input bias current (max) (pA): 5 GBW (typ) (MHz): 16 Features: Burr-Brown™ Audio Slew rate (typ) (V/µs): 55 Rail-to-rail: No Iq per channel (typ) (mA): 7 Vn at 1 kHz (typ) (nV√Hz): 5.2 CMRR (typ) (dB): 110 Rating: Catalog Operating temperature range (°C): -25 to 85 Iout (typ) (A): 0.045 Architecture: FET Input common mode headroom (to negative supply) (typ) (V): 3.5 Input common mode headroom (to positive supply) (typ) (V): -3.5 Output swing headroom (to negative supply) (typ) (V): 2.7 Output swing headroom (to positive supply) (typ) (V): -2.7 THD + N at 1 kHz (typ) (%): 0.00003

Number of channels: 2 Total supply voltage (+5 V = 5, ±5 V = 10) (max) (V): 40 Total supply voltage (+5 V = 5, ±5 V = 10) (min) (V): 4 Vos (offset voltage at 25°C) (max) (mV): 0.6 Offset drift (typ) (µV/°C): 2 Input bias current (max) (pA): 70000 GBW (typ) (MHz): 1.7 Slew rate (typ) (V/µs): 0.5 Rail-to-rail: In to V- Iq per channel (typ) (mA): 0.2 Vn at 1 kHz (typ) (nV√Hz): 17 CMRR (typ) (dB): 110 Rating: Catalog Operating temperature range (°C): -40 to 85 Iout (typ) (A): 0.003 Architecture: Bipolar Input common mode headroom (to negative supply) (typ) (V): -0.3 Input common mode headroom (to positive supply) (typ) (V): -1 Output swing headroom (to negative supply) (typ) (V): 0.7 Output swing headroom (to positive supply) (typ) (V): -0.7

Number of channels: 2 Total supply voltage (+5 V = 5, ±5 V = 10) (max) (V): 40 Total supply voltage (+5 V = 5, ±5 V = 10) (min) (V): 4 Vos (offset voltage at 25°C) (max) (mV): 0.4 Offset drift (typ) (µV/°C): 2 Input bias current (max) (pA): 70000 GBW (typ) (MHz): 1.7 Slew rate (typ) (V/µs): 0.5 Rail-to-rail: In to V- Iq per channel (typ) (mA): 0.2 Vn at 1 kHz (typ) (nV√Hz): 17 CMRR (typ) (dB): 110 Rating: Catalog Operating temperature range (°C): -40 to 85 Iout (typ) (A): 0.003 Architecture: Bipolar Input common mode headroom (to negative supply) (typ) (V): -0.3 Input common mode headroom (to positive supply) (typ) (V): -1 Output swing headroom (to negative supply) (typ) (V): 0.7 Output swing headroom (to positive supply) (typ) (V): -0.7

Number of channels: 4 Total supply voltage (+5 V = 5, ±5 V = 10) (max) (V): 40 Total supply voltage (+5 V = 5, ±5 V = 10) (min) (V): 4 Rail-to-rail: In to V- GBW (typ) (MHz): 2 Slew rate (typ) (V/µs): 0.5 Vos (offset voltage at 25°C) (max) (mV): 1.1 Iq per channel (typ) (mA): 0.2 Vn at 1 kHz (typ) (nV√Hz): 17 Rating: Catalog Operating temperature range (°C): to Offset drift (typ) (µV/°C): 2 Input bias current (max) (pA): 70000 CMRR (typ) (dB): 102 Iout (typ) (A): 0.003 Architecture: Bipolar Input common mode headroom (to negative supply) (typ) (V): -0.3 Input common mode headroom (to positive supply) (typ) (V): -1 Output swing headroom (to negative supply) (typ) (V): 0.7 Output swing headroom (to positive supply) (typ) (V): -0.7
