Number of channels: 4 Total supply voltage (+5 V = 5, ±5 V = 10) (max) (V): 40 Total supply voltage (+5 V = 5, ±5 V = 10) (min) (V): 4 Vos (offset voltage at 25°C) (max) (mV): 0.85 Offset drift (typ) (µV/°C): 2 Input bias current (max) (pA): 70000 GBW (typ) (MHz): 1.7 Slew rate (typ) (V/µs): 0.5 Rail-to-rail: In to V- Iq per channel (typ) (mA): 0.2 Vn at 1 kHz (typ) (nV√Hz): 17 CMRR (typ) (dB): 115 Rating: Catalog Operating temperature range (°C): -40 to 85 Iout (typ) (A): 0.003 Architecture: Bipolar Input common mode headroom (to negative supply) (typ) (V): -0.3 Input common mode headroom (to positive supply) (typ) (V): -1 Output swing headroom (to negative supply) (typ) (V): 0.7 Output swing headroom (to positive supply) (typ) (V): -0.7

Number of channels: 1 Total supply voltage (+5 V = 5, ±5 V = 10) (max) (V): 40 Total supply voltage (+5 V = 5, ±5 V = 10) (min) (V): 4 Vos (offset voltage at 25°C) (max) (mV): 0.6 Offset drift (typ) (µV/°C): 2 Input bias current (max) (pA): 70000 GBW (typ) (MHz): 1.7 Slew rate (typ) (V/µs): 0.5 Rail-to-rail: In to V- Iq per channel (typ) (mA): 0.2 Vn at 1 kHz (typ) (nV√Hz): 17 CMRR (typ) (dB): 110 Rating: Catalog Operating temperature range (°C): -40 to 85 Iout (typ) (A): 0.003 Architecture: Bipolar Input common mode headroom (to negative supply) (typ) (V): -0.3 Input common mode headroom (to positive supply) (typ) (V): -1 Output swing headroom (to negative supply) (typ) (V): 0.7 Output swing headroom (to positive supply) (typ) (V): -0.7

Number of channels: 1 Total supply voltage (+5 V = 5, ±5 V = 10) (max) (V): 40 Total supply voltage (+5 V = 5, ±5 V = 10) (min) (V): 4 Vos (offset voltage at 25°C) (max) (mV): 0.3 Offset drift (typ) (µV/°C): 2 Input bias current (max) (pA): 70000 GBW (typ) (MHz): 1.7 Slew rate (typ) (V/µs): 0.5 Rail-to-rail: In to V- Iq per channel (typ) (mA): 0.2 Vn at 1 kHz (typ) (nV√Hz): 17 CMRR (typ) (dB): 110 Rating: Catalog Operating temperature range (°C): -40 to 85 Iout (typ) (A): 0.003 Architecture: Bipolar Input common mode headroom (to negative supply) (typ) (V): -0.3 Input common mode headroom (to positive supply) (typ) (V): -1 Output swing headroom (to negative supply) (typ) (V): 0.7 Output swing headroom (to positive supply) (typ) (V): -0.7

Number of channels: 4 Total supply voltage (+5 V = 5, ±5 V = 10) (max) (V): 15 Total supply voltage (+5 V = 5, ±5 V = 10) (min) (V): 5 Rail-to-rail: In to V-, Out GBW (typ) (MHz): 0.35 Slew rate (typ) (V/µs): 0.11 Vos (offset voltage at 25°C) (max) (mV): 3 Iq per channel (typ) (mA): 0.04 Vn at 1 kHz (typ) (nV√Hz): 42 Rating: Catalog Operating temperature range (°C): -40 to 85 Offset drift (typ) (µV/°C): 1.3 Input bias current (max) (pA): 4 CMRR (typ) (dB): 83 Iout (typ) (A): 0.021 Architecture: CMOS Input common mode headroom (to negative supply) (typ) (V): -0.4 Input common mode headroom (to positive supply) (typ) (V): -1.9 Output swing headroom (to negative supply) (typ) (V): 0.004 Output swing headroom (to positive supply) (typ) (V): -0.013

Number of channels: 2 Total supply voltage (+5 V = 5, ±5 V = 10) (max) (V): 15 Total supply voltage (+5 V = 5, ±5 V = 10) (min) (V): 5 Rail-to-rail: In to V-, Out GBW (typ) (MHz): 0.35 Slew rate (typ) (V/µs): 0.11 Vos (offset voltage at 25°C) (max) (mV): 3 Iq per channel (typ) (mA): 0.043 Vn at 1 kHz (typ) (nV√Hz): 42 Rating: Catalog Operating temperature range (°C): -40 to 85 Offset drift (typ) (µV/°C): 1.3 Input bias current (max) (pA): 4 CMRR (typ) (dB): 83 Iout (typ) (A): 0.021 Architecture: CMOS Input common mode headroom (to negative supply) (typ) (V): -0.4 Input common mode headroom (to positive supply) (typ) (V): -1.9 Output swing headroom (to negative supply) (typ) (V): 0.004 Output swing headroom (to positive supply) (typ) (V): -0.013

Output swing headroom (to positive supply) (typ) (V): -0.2 Number of channels: 1 Total supply voltage (+5 V = 5, ±5 V = 10) (max) (V): 16 Total supply voltage (+5 V = 5, ±5 V = 10) (min) (V): 3.8 Vos (offset voltage at 25°C) (max) (mV): 0.003 GBW (typ) (MHz): 1.9 Features: Zero Drift Slew rate (typ) (V/µs): 2.8 Rail-to-rail: In to V-, Out Offset drift (typ) (µV/°C): 0.003 Iq per channel (typ) (mA): 1.5 Vn at 1 kHz (typ) (nV√Hz): 23 CMRR (typ) (dB): 140 Rating: Automotive, Catalog Operating temperature range (°C): -40 to 125 Input bias current (max) (pA): 60 Iout (typ) (A): 0.003 Architecture: CMOS Input common mode headroom (to negative supply) (typ) (V): 0 Input common mode headroom (to positive supply) (typ) (V): -1.9 Output swing headroom (to negative supply) (typ) (V): 0.1 Output swing headroom (to positive supply) (typ) (V): -0.2

Output swing headroom (to positive supply) (typ) (V): -0.2 Number of channels: 1 Total supply voltage (+5 V = 5, ±5 V = 10) (max) (V): 16 Total supply voltage (+5 V = 5, ±5 V = 10) (min) (V): 3.8 Vos (offset voltage at 25°C) (max) (mV): 0.003 GBW (typ) (MHz): 1.9 Features: Zero Drift Slew rate (typ) (V/µs): 2.8 Rail-to-rail: In to V-, Out Offset drift (typ) (µV/°C): 0.003 Iq per channel (typ) (mA): 1.5 Vn at 1 kHz (typ) (nV√Hz): 23 CMRR (typ) (dB): 140 Rating: Catalog Operating temperature range (°C): -40 to 85 Input bias current (max) (pA): 60 Iout (typ) (A): 0.003 Architecture: CMOS Input common mode headroom (to negative supply) (typ) (V): 0 Input common mode headroom (to positive supply) (typ) (V): -1.9 Output swing headroom (to negative supply) (typ) (V): 0.1 Output swing headroom (to positive supply) (typ) (V): -0.2

Slew rate (typ) (V/µs): 15 Vos (offset voltage at 25°C) (max) (mV): 3 Offset drift (typ) (V/°C): 0.00001 Iq per channel (typ) (mA): 4.2 Rating: Catalog, Military Operating temperature range (°C): -55 to 125 Input bias current (max) (pA): 50 CMRR (typ) (dB): 95 Rail-to-rail: No Architecture: FET

Slew rate (typ) (V/µs): 8 Vos (offset voltage at 25°C) (max) (mV): 1 Offset drift (typ) (V/°C): 0.000015 Iq per channel (typ) (mA): 20 Rating: Catalog Operating temperature range (°C): -55 to 125 Input bias current (max) (pA): 50 CMRR (typ) (dB): 106 Rail-to-rail: No Architecture: FET

Common-mode input low (min) (V): -200 Common-mode input high (max) (V): 200 Input offset (±) (max) (V): 0.001 Iq (typ) (mA): 2 Slew rate (typ) (V/µs): 2.6 Voltage gain (min) (V/V): 1 Voltage gain (max) (V/V): 1 Small-signal bandwidth (typ) (Hz): 200000 Rating: Catalog Operating temperature range (°C): -40 to 85 Gain drift (max) (ppm/°C): 10 Gain error (±) (max) (%): 0.05
