Configuration: 4:1 Number of channels: 2 Power supply voltage - single (V): 1.8, 2.5, 3.3, 5 Protocols: Analog Ron (typ) (Ω): 100 CON (typ) (pF): 5.6 ON-state leakage current (max) (µA): 2 Bandwidth (MHz): 50 Operating temperature range (°C): -40 to 125 Input/output continuous current (max) (mA): 25 Rating: Automotive Drain supply voltage (max) (V): 5.5 Supply voltage (max) (V): 5.5 Configuration: 4:1 Number of channels: 2 Power supply voltage - single (V): 1.8, 2.5, 3.3, 5 Protocols: Analog Ron (typ) (Ω): 100 CON (typ) (pF): 5.6 ON-state leakage current (max) (µA): 2 更多

Configuration: 2:1 SPDT Number of channels: 3 Power supply voltage - single (V): 1.8, 2.5, 3.3, 5 Protocols: Analog Ron (typ) (Ω): 23 CON (typ) (pF): 5.6 ON-state leakage current (max) (µA): 2 Bandwidth (MHz): 50 Operating temperature range (°C): -40 to 125 Input/output continuous current (max) (mA): 25 Rating: Automotive Drain supply voltage (max) (V): 5.5 Supply voltage (max) (V): 5.5 Configuration: 2:1 SPDT Number of channels: 3 Power supply voltage - single (V): 1.8, 2.5, 3.3, 5 Protocols: Analog Ron (typ) (Ω): 23 CON (typ) (pF): 5.6 ON-state leakage current (max) (µA): 2 更多

Configuration: 1:1 SPST Number of channels: 1 Power supply voltage - single (V): 1.8, 2.5, 3.3, 5 Protocols: Analog Ron (typ) (Ω): 7.5 CON (typ) (pF): 13 ON-state leakage current (max) (µA): 1 Supply current (typ) (µA): 1 Bandwidth (MHz): 300 Operating temperature range (°C): -40 to 125 Input/output continuous current (max) (mA): 50 Rating: Automotive Drain supply voltage (max) (V): 5.5 Supply voltage (max) (V): 5.5 Configuration: 1:1 SPST Number of channels: 1 Power supply voltage - single (V): 1.8, 2.5, 3.3, 5 Protocols: Analog Ron (typ) (Ω): 7.5 CON (typ) (pF): 13 更多

Configuration: 1:1 SPST Number of channels: 8 Power supply voltage - single (V): 2.5, 3.3 Protocols: Analog Ron (typ) (Ω): 5 CON (typ) (pF): 5 ON-state leakage current (max) (µA): 20 Bandwidth (MHz): 100 Operating temperature range (°C): -40 to 85 Features: Powered-off protection, Signal path translation Input/output continuous current (max) (mA): 128 Rating: Catalog Drain supply voltage (max) (V): 3.6 Supply voltage (max) (V): 3.6 Configuration: 1:1 SPST Number of channels: 8 Power supply voltage - single (V): 2.5, 3.3 Protocols: Analog Ron (typ) (Ω): 5 CON (typ) (pF): 5 更多

Configuration: 8:1 Number of channels: 1 Power supply voltage - single (V): 2.5, 3.3, 5 Protocols: Analog Ron (typ) (Ω): 150 CON (typ) (pF): 6.7 ON-state leakage current (max) (µA): 1 Supply current (typ) (µA): 2 Operating temperature range (°C): -40 to 125 Features: Injection current control Input/output continuous current (max) (mA): 25 Rating: Catalog Drain supply voltage (max) (V): 6 Supply voltage (max) (V): 6 Configuration: 8:1 Number of channels: 1 Power supply voltage - single (V): 2.5, 3.3, 5 Protocols: Analog Ron (typ) (Ω): 150 CON (typ) (pF): 6.7 更多

Configuration: 2:1 SPDT Number of channels: 4 Power supply voltage - single (V): 2.5, 3.3 Protocols: Analog, I2C, I2S, JTAG, RGMII, SPI, TDM, UART Ron (typ) (Ω): 4 CON (typ) (pF): 10.5 Supply current (typ) (µA): 250 Bandwidth (MHz): 500 Operating temperature range (°C): -40 to 85 Features: Powered-off protection, Supports input voltage beyond supply Input/output continuous current (max) (mA): 64 Rating: Catalog Drain supply voltage (max) (V): 3.6 Supply voltage (max) (V): 3.6 Configuration: 2:1 SPDT Number of channels: 4 Power supply voltage - single (V): 2.5, 3.3 Protocols: Analog, I2C, I2S, JTAG, RGMII, SPI, TDM, UART Ron (typ) (Ω): 4 CON (typ) (pF): 10.5 更多

Configuration: 2:1 SPDT Number of channels: 2 Power supply voltage - single (V): 5 Protocols: Analog Ron (typ) (Ω): 0.45 ON-state leakage current (max) (µA): 0.02 Supply current (typ) (µA): 0.005 Operating temperature range (°C): -40 to 85 Input/output continuous current (max) (mA): 400 Rating: Catalog Drain supply voltage (max) (V): 5.5 Supply voltage (max) (V): 5.5 Configuration: 2:1 SPDT Number of channels: 2 Power supply voltage - single (V): 5 Protocols: Analog Ron (typ) (Ω): 0.45 ON-state leakage current (max) (µA): 0.02 Supply current (typ) (µA): 0.005 Operating temperature range (°C): -40 to 85 更多

Configuration: 1:1 SPST Number of channels: 2 Power supply voltage - single (V): 2.5, 3.3 Protocols: Analog, I2C, UART Ron (typ) (Ω): 3 CON (typ) (pF): 8 Supply current (typ) (µA): 250 Bandwidth (MHz): 500 Operating temperature range (°C): -40 to 85 Features: Powered-off protection, Supports input voltage beyond supply Input/output continuous current (max) (mA): 64 Rating: Catalog Drain supply voltage (max) (V): 3.6 Supply voltage (max) (V): 3.6 Configuration: 1:1 SPST Number of channels: 2 Power supply voltage - single (V): 2.5, 3.3 Protocols: Analog, I2C, UART Ron (typ) (Ω): 3 CON (typ) (pF): 8 更多

Configuration: 1:1 SPST Number of channels: 10 Power supply voltage - single (V): 2.5, 3.3 Protocols: Analog Ron (typ) (Ω): 4.5 CON (typ) (pF): 9 Supply current (typ) (µA): 750 Bandwidth (MHz): 500 Operating temperature range (°C): -40 to 85 Features: Powered-off protection, Supports input voltage beyond supply Input/output continuous current (max) (mA): 64 Rating: Catalog Drain supply voltage (max) (V): 3.6 Supply voltage (max) (V): 3.6 Configuration: 1:1 SPST Number of channels: 10 Power supply voltage - single (V): 2.5, 3.3 Protocols: Analog Ron (typ) (Ω): 4.5 CON (typ) (pF): 9 更多

Configuration: 1:1 SPST Number of channels: 16 Power supply voltage - single (V): 5 Protocols: Analog Ron (typ) (Ω): 3 CON (typ) (pF): 14 ON-state leakage current (max) (µA): 10 Bandwidth (MHz): 200 Operating temperature range (°C): -40 to 85 Features: Powered-off protection, Undershoot protection Input/output continuous current (max) (mA): 128 Rating: Catalog Drain supply voltage (max) (V): 5.5 Supply voltage (max) (V): 5.5 Configuration: 1:1 SPST Number of channels: 16 Power supply voltage - single (V): 5 Protocols: Analog Ron (typ) (Ω): 3 CON (typ) (pF): 14 更多
