Configuration: 8:1 Number of channels: 1 Power supply voltage - single (V): 1.8, 2.5, 3.3, 5 Power supply voltage - dual (V): +/-2.5, +/-5 Protocols: Analog Ron (typ) (Ω): 40 CON (typ) (pF): 25 ON-state leakage current (max) (µA): 2 Supply current (typ) (µA): 16 Bandwidth (MHz): 180 Operating temperature range (°C): -40 to 125 Features: Break-before-make Input/output continuous current (max) (mA): 25 Rating: Automotive Drain supply voltage (max) (V): 6 Supply voltage (max) (V): 10 Negative rail supply voltage (max) (V): 0 Configuration: 8:1 Number of channels: 1 Power supply voltage - single (V): 1.8, 2.5, 3.3, 5 更多

Configuration: 1:1 SPST Number of channels: 8 Power supply voltage - single (V): 2.5, 3.3 Protocols: Analog Ron (typ) (Ω): 4 CON (typ) (pF): 9 Supply current (typ) (µA): 1000 Bandwidth (MHz): 500 Operating temperature range (°C): -40 to 85 Features: Powered-off protection, Supports input voltage beyond supply Input/output continuous current (max) (mA): 64 Rating: Catalog Drain supply voltage (max) (V): 3.6 Supply voltage (max) (V): 3.6 Configuration: 1:1 SPST Number of channels: 8 Power supply voltage - single (V): 2.5, 3.3 Protocols: Analog Ron (typ) (Ω): 4 CON (typ) (pF): 9 更多

Configuration: 1:1 SPST Number of channels: 24 Power supply voltage - single (V): 2.5, 3.3 Protocols: Analog Ron (typ) (Ω): 5 CON (typ) (pF): 13 ON-state leakage current (max) (µA): 20 Bandwidth (MHz): 100 Operating temperature range (°C): -40 to 85 Features: Powered-off protection, Signal path translation Input/output continuous current (max) (mA): 128 Rating: Catalog Drain supply voltage (max) (V): 3.6 Supply voltage (max) (V): 3.6 Configuration: 1:1 SPST Number of channels: 24 Power supply voltage - single (V): 2.5, 3.3 Protocols: Analog Ron (typ) (Ω): 5 CON (typ) (pF): 13 更多

Configuration: 2:1 SPDT Number of channels: 1 Power supply voltage - single (V): 0.8, 1.2, 1.8, 2.5 Protocols: Analog Ron (typ) (Ω): 6 CON (typ) (pF): 9 ON-state leakage current (max) (µA): 1 Bandwidth (MHz): 500 Operating temperature range (°C): -40 to 85 Input/output continuous current (max) (mA): 50 Rating: Catalog Drain supply voltage (max) (V): 2.7 Supply voltage (max) (V): 2.7 Configuration: 2:1 SPDT Number of channels: 1 Power supply voltage - single (V): 0.8, 1.2, 1.8, 2.5 Protocols: Analog Ron (typ) (Ω): 6 CON (typ) (pF): 9 ON-state leakage current (max) (µA): 1 更多

Configuration: 1:1 SPST Number of channels: 8 Power supply voltage - single (V): 2.5, 3.3 Protocols: Analog Ron (typ) (Ω): 4 CON (typ) (pF): 9 Supply current (typ) (µA): 1000 Bandwidth (MHz): 500 Operating temperature range (°C): -40 to 85 Features: Powered-off protection, Supports input voltage beyond supply Input/output continuous current (max) (mA): 64 Rating: Catalog Drain supply voltage (max) (V): 3.6 Supply voltage (max) (V): 3.6 Configuration: 1:1 SPST Number of channels: 8 Power supply voltage - single (V): 2.5, 3.3 Protocols: Analog Ron (typ) (Ω): 4 CON (typ) (pF): 9 更多

Configuration: 4:1 Number of channels: 2 Power supply voltage - single (V): 2.5, 3.3 Protocols: Analog Ron (typ) (Ω): 5 CON (typ) (pF): 4 ON-state leakage current (max) (µA): 20 Bandwidth (MHz): 100 Operating temperature range (°C): -40 to 85 Features: Powered-off protection, Signal path translation Input/output continuous current (max) (mA): 128 Rating: Catalog Drain supply voltage (max) (V): 3.6 Supply voltage (max) (V): 3.6 Configuration: 4:1 Number of channels: 2 Power supply voltage - single (V): 2.5, 3.3 Protocols: Analog Ron (typ) (Ω): 5 CON (typ) (pF): 4 更多

Configuration: 2:1 SPDT Number of channels: 4 Power supply voltage - single (V): 2.5, 3.3 Protocols: Analog, I2C, I2S, JTAG, RGMII, SPI, TDM, UART Ron (typ) (Ω): 5 CON (typ) (pF): 4 ON-state leakage current (max) (µA): 20 Bandwidth (MHz): 100 Operating temperature range (°C): -40 to 85 Features: Powered-off protection, Signal path translation Input/output continuous current (max) (mA): 128 Rating: Catalog Drain supply voltage (max) (V): 3.6 Supply voltage (max) (V): 3.6 Configuration: 2:1 SPDT Number of channels: 4 Power supply voltage - single (V): 2.5, 3.3 Protocols: Analog, I2C, I2S, JTAG, RGMII, SPI, TDM, UART Ron (typ) (Ω): 5 CON (typ) (pF): 4 更多

Configuration: 4:1 Number of channels: 2 Power supply voltage - single (V): 2.5, 3.3 Protocols: Analog Ron (typ) (Ω): 3.5 CON (typ) (pF): 13 Supply current (typ) (µA): 700 Bandwidth (MHz): 500 Operating temperature range (°C): -40 to 85 Features: Powered-off protection, Supports input voltage beyond supply Input/output continuous current (max) (mA): 64 Rating: Catalog Drain supply voltage (max) (V): 3.6 Supply voltage (max) (V): 3.6 Configuration: 4:1 Number of channels: 2 Power supply voltage - single (V): 2.5, 3.3 Protocols: Analog Ron (typ) (Ω): 3.5 CON (typ) (pF): 13 更多

Configuration: 1:1 SPST Number of channels: 1 Power supply voltage - single (V): 2.5, 3.3 Protocols: Analog Ron (typ) (Ω): 5 CON (typ) (pF): 12 ON-state leakage current (max) (µA): 20 Operating temperature range (°C): -40 to 85 Features: Powered-off protection, Signal path translation Input/output continuous current (max) (mA): 128 Rating: Catalog Drain supply voltage (max) (V): 3.6 Supply voltage (max) (V): 3.6 Configuration: 1:1 SPST Number of channels: 1 Power supply voltage - single (V): 2.5, 3.3 Protocols: Analog Ron (typ) (Ω): 5 CON (typ) (pF): 12 ON-state leakage current (max) (µA): 20 更多

Configuration: 8:1 Number of channels: 1 Power supply voltage - single (V): 1.8, 2.5, 3.3, 5 Protocols: Analog Ron (typ) (Ω): 22 CON (typ) (pF): 23.4 ON-state leakage current (max) (µA): 2 Bandwidth (MHz): 35 Operating temperature range (°C): -40 to 125 Input/output continuous current (max) (mA): 25 Rating: Automotive Drain supply voltage (max) (V): 5.5 Supply voltage (max) (V): 5.5 Configuration: 8:1 Number of channels: 1 Power supply voltage - single (V): 1.8, 2.5, 3.3, 5 Protocols: Analog Ron (typ) (Ω): 22 CON (typ) (pF): 23.4 ON-state leakage current (max) (µA): 2 更多
