Number of series cells: 1 Charge current (max) (A): 3 Vin (max) (V): 14 Cell chemistry: Li-Ion/Li-Polymer Battery charge voltage (min) (V): 3.84 Battery charge voltage (max) (V): 4.6 Absolute max Vin (max) (V): 22 Control topology: Switch-Mode Buck Control interface: I2C Vin (min) (V): 3.9 Rating: Catalog Operating temperature range (°C): -40 to 85 Number of series cells: 1 Charge current (max) (A): 3 Vin (max) (V): 14 Cell chemistry: Li-Ion/Li-Polymer Battery charge voltage (min) (V): 3.84 Battery charge voltage (max) (V): 4.6 Absolute max Vin (max) (V): 22 Control topology: Switch-Mode Buck 更多

Number of series cells: 1 Charge current (max) (A): 5 Vin (max) (V): 14 Cell chemistry: Li-Ion/Li-Polymer Battery charge voltage (min) (V): 3.84 Battery charge voltage (max) (V): 4.6 Absolute max Vin (max) (V): 22 Control topology: Switch-Mode Buck Control interface: I2C Vin (min) (V): 3.9 Rating: Catalog Operating temperature range (°C): -40 to 85 Number of series cells: 1 Charge current (max) (A): 5 Vin (max) (V): 14 Cell chemistry: Li-Ion/Li-Polymer Battery charge voltage (min) (V): 3.84 Battery charge voltage (max) (V): 4.6 Absolute max Vin (max) (V): 22 Control topology: Switch-Mode Buck 更多

Number of series cells: 1 Charge current (max) (A): 5 Vin (max) (V): 14 Cell chemistry: Li-Ion/Li-Polymer Battery charge voltage (min) (V): 3.84 Battery charge voltage (max) (V): 4.6 Absolute max Vin (max) (V): 22 Control topology: Switch-Mode Buck Control interface: I2C Vin (min) (V): 3.9 Rating: Catalog Operating temperature range (°C): -40 to 85 Number of series cells: 1 Charge current (max) (A): 5 Vin (max) (V): 14 Cell chemistry: Li-Ion/Li-Polymer Battery charge voltage (min) (V): 3.84 Battery charge voltage (max) (V): 4.6 Absolute max Vin (max) (V): 22 Control topology: Switch-Mode Buck 更多

Cell chemistry: Li-Ion/Li-Polymer, LiFePO4 Number of series cells: 2-4 Cells, Single Cell Communication interface: SMBus Battery capacity (min) (mAh): 100 Battery capacity (max) (mAh): 65000 Implementation: Pack External capacity indication: LED Operating temperature range (°C): -40 to 85 Cell balancing: External, Internal Rating: Catalog Cell chemistry: Li-Ion/Li-Polymer, LiFePO4 Number of series cells: 2-4 Cells, Single Cell Communication interface: SMBus Battery capacity (min) (mAh): 100 Battery capacity (max) (mAh): 65000 Implementation: Pack External capacity indication: LED Operating temperature range (°C): -40 to 85 Cell balancing: External, Internal Rating: Catalog

Function: Protection Number of series cells (min): 2 Number of series cells (max): 2 Operating current (typ) (µA): 3 Rating: Automotive Vin (max) (V): 16 TI functional safety category: Functional Safety-Capable Overvoltage protection: 4.3 Operating temperature range (°C): -40 to 105 Battery overvoltage protection (min) (V): 4.3 Battery overvoltage protection (max) (V): 4.3 Function: Protection Number of series cells (min): 2 Number of series cells (max): 2 Operating current (typ) (µA): 3 Rating: Automotive Vin (max) (V): 16 TI functional safety category: Functional Safety-Capable Overvoltage protection: 4.3 Operating temperature range (°C): -40 to 105 更多

Number of series cells: 1 Charge current (max) (A): 1 Vin (max) (V): 6.5 Cell chemistry: Li-Ion/Li-Polymer Battery charge voltage (min) (V): 4.2 Battery charge voltage (max) (V): 4.2 Absolute max Vin (max) (V): 7 Control topology: Linear Control interface: Standalone (RC-Settable) Features: BAT temp thermistor monitoring (hot/cold profile) Vin (min) (V): 4.5 Rating: Automotive Operating temperature range (°C): -40 to 125 Number of series cells: 1 Charge current (max) (A): 1 Vin (max) (V): 6.5 Cell chemistry: Li-Ion/Li-Polymer Battery charge voltage (min) (V): 4.2 Battery charge voltage (max) (V): 4.2 Absolute max Vin (max) (V): 7 更多

Function: Protection Number of series cells (min): 2, 3, 4 Number of series cells (max): 3, 4 Features: LDO output, Overvoltage, Single pin output drive, Undervoltage Operating current (typ) (µA): 1 Rating: Catalog Vin (max) (V): 20 Overvoltage protection: 4.25, 4.35, 4.45, 4.5 Operating temperature range (°C): -40 to 110 Battery overvoltage protection (min) (V): 3.85 Battery overvoltage protection (max) (V): 4.6 Function: Protection Number of series cells (min): 2, 3, 4 Number of series cells (max): 3, 4 Features: LDO output, Overvoltage, Single pin output drive, Undervoltage Operating current (typ) (µA): 1 Rating: Catalog Vin (max) (V): 20 Overvoltage protection: 4.25, 4.35, 4.45, 4.5 Operating temperature range (°C): -40 to 110 更多

Cell chemistry: Li-Ion/Li-Polymer Number of series cells: Single Cell Communication interface: HDQ, I2C Battery capacity (min) (mAh): 100 Battery capacity (max) (mAh): 32000 Implementation: Pack External capacity indication: None Features: Impedance Track™ algorithm, SHA-1 Authentication Operating temperature range (°C): -40 to 85 Rating: Catalog Cell chemistry: Li-Ion/Li-Polymer Number of series cells: Single Cell Communication interface: HDQ, I2C Battery capacity (min) (mAh): 100 Battery capacity (max) (mAh): 32000 Implementation: Pack External capacity indication: None Features: Impedance Track™ algorithm, SHA-1 Authentication Operating temperature range (°C): -40 to 85 Rating: Catalog

Number of series cells: 1 Charge current (max) (A): 3 Vin (max) (V): 6.2 Cell chemistry: Li-Ion/Li-Polymer Battery charge voltage (min) (V): 3.5 Battery charge voltage (max) (V): 4.44 Absolute max Vin (max) (V): 15 Control topology: Switch-Mode Buck Control interface: I2C Vin (min) (V): 3.9 Rating: Catalog Operating temperature range (°C): -40 to 85 Number of series cells: 1 Charge current (max) (A): 3 Vin (max) (V): 6.2 Cell chemistry: Li-Ion/Li-Polymer Battery charge voltage (min) (V): 3.5 Battery charge voltage (max) (V): 4.44 Absolute max Vin (max) (V): 15 Control topology: Switch-Mode Buck 更多

Number of series cells: 1, 2, 3, 4 Charge current (max) (A): 8.128 Vin (max) (V): 24 Battery charge voltage (min) (V): 1.024 Battery charge voltage (max) (V): 19.2 Absolute max Vin (max) (V): 30 Control topology: Switch-Mode Buck Control interface: SMBus Vin (min) (V): 4.5 Rating: Catalog Operating temperature range (°C): -40 to 85 Number of series cells: 1, 2, 3, 4 Charge current (max) (A): 8.128 Vin (max) (V): 24 Battery charge voltage (min) (V): 1.024 Battery charge voltage (max) (V): 19.2 Absolute max Vin (max) (V): 30 Control topology: Switch-Mode Buck Control interface: SMBus Vin (min) (V): 4.5 更多
