TLE9852QX
数据:
分类: 微电路 / 半导体集成电路 / 数字集成电路 / 微处理器(MPU) / 微控制器(MCU)
描述: MOTIX™ TLE9852QX provides cost-effective solid-state solution for window lift
T[j] max: 150.0°C
Solid Flash: 48.0kByte
RAM: 4.0kByte
Frequency: 40.0MHz
Interfaces: PWM + LIN
Operational Amplifier: NO
Temperature: - 40°C - 150°C
Operating Voltage max: 28.0V
Clock Frequency max: 40.0MHz
Instruction Set Architecture: Arm® Cortex® M0
Currently planned availability until at least: 2038
Technology: MOTIX™ MCU (SoC)
Family: MOTIX™ 32-bit motor control SoC
TLE9854QX
数据:
分类: 微电路 / 半导体集成电路 / 数字集成电路 / 微处理器(MPU) / 微控制器(MCU)
描述: MOTIX™ TLE9854QX offers high integration to optimize target applications such as sunroof
Interfaces: PWM + LIN
Frequency: 40.0MHz
RAM: 4.0kByte
Solid Flash: 64.0kByte
T[j] max: 150.0°C
Operational Amplifier: YES
Temperature: - 40°C - 150°C
Operating Voltage max: 28.0V
Clock Frequency max: 40.0MHz
Instruction Set Architecture: Arm® Cortex® M0
Currently planned availability until at least: 2038
Technology: MOTIX™ MCU (SoC)
Family: MOTIX™ 32-bit motor control SoC
TLE9851QXW
数据:
分类: 微电路 / 半导体集成电路 / 数字集成电路 / 微处理器(MPU) / 微控制器(MCU)
描述: MOTIX™TLE9851QXW optimizes single-phase DC pumps and fans such as HVAC blower
Interfaces: PWM + LIN
Frequency: 40.0MHz
RAM: 4.0kByte
Solid Flash: 64.0kByte
T[j] max: 175.0°C
Operational Amplifier: YES
Temperature: - 40°C - 175°C
Operating Voltage max: 28.0V
Clock Frequency max: 40.0MHz
Instruction Set Architecture: Arm® Cortex® M0
Technology: MOTIX™ MCU (SoC)
Currently planned availability until at least: 2035
Family: MOTIX™ 32-bit motor control SoC
TLE9867QXA20
数据:
分类: 微电路 / 半导体集成电路 / 数字集成电路 / 微处理器(MPU) / 微控制器(MCU)
描述: The MOTIX™ TLE9867QXA20 enables optimization of your DC motor drive applications
Solid Flash: 64.0kByte
RAM: 6.0kByte
Frequency: 24.0MHz
Low Side Switch: 0
High Side Switch: 0
High Voltage Monitor Input: 1
GPIO: 10
Interfaces: PWM + LIN
Operational Amplifier: Yes
MOSFET Drivers(Low Side): 2
MOSFET Drivers(High Side): 2
PN MOS DRIVER: No
T[j] max: 150.0°C
Language: SPICE
Product Category: Microcontroller (MCU)
Temperature: - 40°C - 150°C
Operating Voltage max: 28.0V
Clock Frequency max: 24.0MHz
Instruction Set Architecture: Arm® Cortex®-M3
Currently planned availability until at least: 2038
更多
Technology: MOTIX™ MCU (SoC)
Family: MOTIX™ 32-bit motor control SoC
TLE9861QXA20
数据:
分类: 微电路 / 半导体集成电路 / 数字集成电路 / 微处理器(MPU) / 微控制器(MCU)
描述: The MOTIX™ TLE9861QXA20 can be used for applications using PWM such as cooling fan
Solid Flash: 36.0kByte
RAM: 3.0kByte
Frequency: 24.0MHz
High Side Switch: 0
Low Side Switch: 0
High Voltage Monitor Input: 1
GPIO: 10
Interfaces: PWM
Operational Amplifier: Yes
MOSFET Drivers(Low Side): 2
MOSFET Drivers(High Side): 2
PN MOS DRIVER: No
T[j] max: 150.0°C
Language: SPICE
Product Category: Microcontroller (MCU)
Temperature: - 40°C - 150°C
Operating Voltage max: 28.0V
Clock Frequency max: 24.0MHz
Instruction Set Architecture: Arm® Cortex®-M3
Currently planned availability until at least: 2038
更多
Technology: MOTIX™ MCU (SoC)
Family: MOTIX™ 32-bit motor control SoC
TLE9883QTA62
数据:
分类: 微电路 / 半导体集成电路 / 数字集成电路 / 微处理器(MPU) / 微控制器(MCU)
描述: The MOTIX™ TLE9883QTA62 is a 2-phase motor driver with CAN-FD
GPIO: 14
High Voltage Monitor Input: 1
Instruction Set Architecture: Arm® Cortex®-M3
Low Side Switch: 0
MOSFET Drivers(High Side): 2
MOSFET Drivers(Low Side): 2
Operating Voltage max: 28.0V
Operational Amplifier: Yes
PN MOS DRIVER: No
Product Category: Microcontroller (MCU)
RAM: 32.0kByte
Solid Flash: 256.0kByte
T[j] max: 150.0°C
Temperature: - 40°C - 150°C
Frequency: 60.0MHz
Clock Frequency max: 60.0MHz
Interfaces: CAN FD
Technology: MOTIX™ MCU (SoC)
Currently planned availability until at least: 2038
Family: MOTIX™ 32-bit motor control SoC
TLE9842QX
数据:
分类: 微电路 / 半导体集成电路 / 数字集成电路 / 微处理器(MPU) / 微控制器(MCU)
描述: MOTIX™ TLE9842QX can be used for the most cost-effective solution for motor control using relays
Solid Flash: 36.0kByte
RAM: 2.0kByte
Frequency: 25.0MHz
High Side Switch: 1
Low Side Switch: 2
High Voltage Monitor Input: 4
GPIO: 10
Interfaces: LIN
Operational Amplifier: NO
PN MOS DRIVER: NO
T[j] max: 150.0°C
Temperature: - 40°C - 150°C
Operating Voltage max: 28.0V
Clock Frequency max: 25.0MHz
Instruction Set Architecture: Arm® Cortex® M0
Technology: MOTIX™ MCU (SoC)
Currently planned availability until at least: 2035
Family: MOTIX™ 32-bit motor control SoC
TLE9867QXA40
数据:
分类: 微电路 / 半导体集成电路 / 数字集成电路 / 微处理器(MPU) / 微控制器(MCU)
描述: The MOTIX™ TLE9867QXA40 has an integrated H-Bridge for your DC motor control application
Solid Flash: 64.0kByte
RAM: 6.0kByte
Frequency: 40.0MHz
High Side Switch: 0
Low Side Switch: 0
High Voltage Monitor Input: 1
GPIO: 10
Interfaces: PWM + LIN
Operational Amplifier: Yes
MOSFET Drivers(Low Side): 2
MOSFET Drivers(High Side): 2
PN MOS DRIVER: No
T[j] max: 150.0°C
Language: SPICE
Product Category: Microcontroller (MCU)
Temperature: - 40°C - 150°C
Operating Voltage max: 28.0V
Clock Frequency max: 40.0MHz
Instruction Set Architecture: Arm® Cortex®-M3
Currently planned availability until at least: 2038
更多
Technology: MOTIX™ MCU (SoC)
Family: MOTIX™ 32-bit motor control SoC
TLE9868QXB20
数据:
分类: 微电路 / 半导体集成电路 / 数字集成电路 / 微处理器(MPU) / 微控制器(MCU)
描述: The MOTIX™ TLE9868QXB20 is the perfect fit for your wiper including absolute angle sensing
Solid Flash: 128.0kByte
RAM: 4.0kByte
Frequency: 20.0MHz
Interfaces: PWM + LIN
T[j] max: 150.0°C
GPIO: 10
High Side Switch: 0
High Voltage Monitor Input: 1
Low Side Switch: 0
MOSFET Drivers(Low Side): 2
MOSFET Drivers(High Side): 2
Operational Amplifier: 0
PN MOS DRIVER: NO
Language: SPICE
Product Category: Microcontroller (MCU)
Temperature: - 40°C - 150°C
Operating Voltage max: 28.0V
Clock Frequency max: 20.0MHz
Instruction Set Architecture: Arm® Cortex®-M3
Currently planned availability until at least: 2038
更多
Technology: MOTIX™ MCU (SoC)
Family: MOTIX™ 32-bit motor control SoC
TLE9850QX
数据:
分类: 微电路 / 半导体集成电路 / 数字集成电路 / 微处理器(MPU) / 微控制器(MCU)
描述: MOTIX™TLE9850QX is designed for unidirectional automotive applications such as HVAC Blower
Frequency: 40.0MHz
RAM: 4.0kByte
T[j] max: 150.0°C
Solid Flash: 48.0kByte
Interfaces: PWM + LIN
Operational Amplifier: YES
Temperature: - 40°C - 150°C
Operating Voltage max: 28.0V
Clock Frequency max: 40.0MHz
Instruction Set Architecture: Arm® Cortex® M0
Technology: MOTIX™ MCU (SoC)
Currently planned availability until at least: 2035
Family: MOTIX™ 32-bit motor control SoC
