DRV10974


数据:
分类: 微电路 / 半导体集成电路 / 接口电路 / 驱动器

描述: 12V 标称电压、2.5A 峰值无传感器正弦控制三相 BLDC 电机驱动器

Rating: Catalog Architecture: Integrated FET Control topology: Sensorless, Sinusoidal Control interface: 1xPWM, Analog Vs (min) (V): 4.4 Vs ABS (max) (V): 20 Operating temperature range (°C): -40 to 125 Rating: Catalog Architecture: Integrated FET Control topology: Sensorless, Sinusoidal Control interface: 1xPWM, Analog Vs (min) (V): 4.4 Vs ABS (max) (V): 20 Operating temperature range (°C): -40 to 125

UCC27511A


数据:
分类: 微电路 / 半导体集成电路 / 接口电路 / 驱动器

描述: 具有 5V UVLO、分离输出和 5V 输入电压处理能力的 4A/8A 单通道栅极驱动器

Number of channels: 1 Power switch: GaNFET, IGBT, MOSFET Peak output current (A): 8 Input supply voltage (min) (V): 4.5 Input supply voltage (max) (V): 18 Features: Split Output Operating temperature range (°C): -40 to 140 Rise time (ns): 9 Fall time (ns): 7 Propagation delay time (µs): 0.013 Input threshold: CMOS, TTL Channel input logic: Inverting, Non-Inverting Input negative voltage (V): -5 Rating: Catalog Undervoltage lockout (typ) (V): 4 Driver configuration: Dual inputs Number of channels: 1 Power switch: GaNFET, IGBT, MOSFET Peak output current (A): 8 Input supply voltage (min) (V): 4.5
Input supply voltage (max) (V): 18 Features: Split Output Operating temperature range (°C): -40 to 140 Rise time (ns): 9 Fall time (ns): 7 Propagation delay time (µs): 0.013 Input threshold: CMOS, TTL Channel input logic: Inverting, Non-Inverting Input negative voltage (V): -5 Rating: Catalog Undervoltage lockout (typ) (V): 4 Driver configuration: Dual inputs

DRV10987


数据:
分类: 微电路 / 半导体集成电路 / 接口电路 / 驱动器

描述: 12V 至 24V 标称电压、3.5A 峰值无传感器正弦控制三相 BLDC 电机驱动器

Rating: Catalog Architecture: Integrated FET Control topology: Sensorless, Sinusoidal Control interface: 1xPWM, Analog, Serial Vs (min) (V): 6.2 Vs ABS (max) (V): 45 Operating temperature range (°C): -40 to 125 Rating: Catalog Architecture: Integrated FET Control topology: Sensorless, Sinusoidal Control interface: 1xPWM, Analog, Serial Vs (min) (V): 6.2 Vs ABS (max) (V): 45 Operating temperature range (°C): -40 to 125

UCC27710


数据:
分类: 微电路 / 半导体集成电路 / 接口电路 / 驱动器

描述: 具有互锁功能的 0.5A/1.0A、620V 半桥栅极驱动器

Bootstrap supply voltage (max) (V): 620 Power switch: IGBT, MOSFET Input supply voltage (min) (V): 10 Input supply voltage (max) (V): 22 Peak output current (A): 1 Operating temperature range (°C): -40 to 125 Undervoltage lockout (typ) (V): 10 Rating: Catalog Propagation delay time (µs): 0.1 Rise time (ns): 35 Fall time (ns): 16 Iq (mA): 0.25 Input threshold: CMOS, TTL Channel input logic: Noninverting Switch node voltage (V): -11 Features: Interlock Driver configuration: CMOS compatible, Dual, Noninverting, TTL compatible Bootstrap supply voltage (max) (V): 620 Power switch: IGBT, MOSFET Input supply voltage (min) (V): 10
Input supply voltage (max) (V): 22 Peak output current (A): 1 Operating temperature range (°C): -40 to 125 Undervoltage lockout (typ) (V): 10 Rating: Catalog Propagation delay time (µs): 0.1 Rise time (ns): 35 Fall time (ns): 16 Iq (mA): 0.25 Input threshold: CMOS, TTL Channel input logic: Noninverting Switch node voltage (V): -11 Features: Interlock Driver configuration: CMOS compatible, Dual, Noninverting, TTL compatible

DRV3220-Q1


数据:
分类: 微电路 / 半导体集成电路 / 接口电路 / 驱动器

描述: 具有增强保护功能的汽车类 12V 和 24V 电池三相栅极驱动器

Rating: Automotive Architecture: Gate driver Control interface: 3xPWM, 6xPWM Gate drive (A): 1 Vs (min) (V): 4.75 Vs ABS (max) (V): 60 Features: SPI/I2C, Watchdog timer Operating temperature range (°C): -40 to 125 TI functional safety category: Functional Safety-Compliant Rating: Automotive Architecture: Gate driver Control interface: 3xPWM, 6xPWM Gate drive (A): 1 Vs (min) (V): 4.75 Vs ABS (max) (V): 60 Features: SPI/I2C, Watchdog timer Operating temperature range (°C): -40 to 125 TI functional safety category: Functional Safety-Compliant

UCC27712-Q1


数据:
分类: 微电路 / 半导体集成电路 / 接口电路 / 驱动器

描述: 具有互锁功能的汽车类 1.8A/2.8A、620V 半桥栅极驱动器

Bootstrap supply voltage (max) (V): 620 Power switch: IGBT, MOSFET Input supply voltage (min) (V): 10 Input supply voltage (max) (V): 20 Peak output current (A): 2.8 Operating temperature range (°C): -40 to 140 Undervoltage lockout (typ) (V): 10 Rating: Automotive Propagation delay time (µs): 0.1 Rise time (ns): 16 Fall time (ns): 10 Iq (mA): 0.25 Input threshold: CMOS, TTL Channel input logic: Noninverting Switch node voltage (V): -11 Features: Interlock Driver configuration: CMOS compatible, Dual, Noninverting, TTL compatible Bootstrap supply voltage (max) (V): 620 Power switch: IGBT, MOSFET Input supply voltage (min) (V): 10
Input supply voltage (max) (V): 20 Peak output current (A): 2.8 Operating temperature range (°C): -40 to 140 Undervoltage lockout (typ) (V): 10 Rating: Automotive Propagation delay time (µs): 0.1 Rise time (ns): 16 Fall time (ns): 10 Iq (mA): 0.25 Input threshold: CMOS, TTL Channel input logic: Noninverting Switch node voltage (V): -11 Features: Interlock Driver configuration: CMOS compatible, Dual, Noninverting, TTL compatible

DRV8323


数据:
分类: 微电路 / 半导体集成电路 / 接口电路 / 驱动器

描述: 具有电流分流放大器的最大 65V 三相智能栅极驱动器

Rating: Catalog Architecture: Gate driver Control interface: 1xPWM, 3xPWM, 6xPWM Gate drive (A): 1 Vs (min) (V): 6 Vs ABS (max) (V): 65 Operating temperature range (°C): -40 to 125 Rating: Catalog Architecture: Gate driver Control interface: 1xPWM, 3xPWM, 6xPWM Gate drive (A): 1 Vs (min) (V): 6 Vs ABS (max) (V): 65 Operating temperature range (°C): -40 to 125

UCC27712


数据:
分类: 微电路 / 半导体集成电路 / 接口电路 / 驱动器

描述: 支持互锁功能的 1.8A/2.8A、620V 半桥驱动器

Bootstrap supply voltage (max) (V): 620 Power switch: IGBT, MOSFET Input supply voltage (min) (V): 10 Input supply voltage (max) (V): 20 Peak output current (A): 2.8 Operating temperature range (°C): -40 to 125 Undervoltage lockout (typ) (V): 10 Rating: Catalog Propagation delay time (µs): 0.1 Rise time (ns): 16 Fall time (ns): 10 Iq (mA): 0.25 Input threshold: CMOS, TTL Channel input logic: Noninverting Switch node voltage (V): -11 Features: Interlock Driver configuration: CMOS compatible, Dual, Noninverting, TTL compatible Bootstrap supply voltage (max) (V): 620 Power switch: IGBT, MOSFET Input supply voltage (min) (V): 10
Input supply voltage (max) (V): 20 Peak output current (A): 2.8 Operating temperature range (°C): -40 to 125 Undervoltage lockout (typ) (V): 10 Rating: Catalog Propagation delay time (µs): 0.1 Rise time (ns): 16 Fall time (ns): 10 Iq (mA): 0.25 Input threshold: CMOS, TTL Channel input logic: Noninverting Switch node voltage (V): -11 Features: Interlock Driver configuration: CMOS compatible, Dual, Noninverting, TTL compatible

UCC27212A-Q1


数据:
分类: 微电路 / 半导体集成电路 / 接口电路 / 驱动器

描述: 具有 5V UVLO 的汽车类 4A、120V 半桥栅极驱动器

Bootstrap supply voltage (max) (V): 120 Power switch: MOSFET Input supply voltage (min) (V): 5 Input supply voltage (max) (V): 17 Peak output current (A): 4 Operating temperature range (°C): -40 to 150 Undervoltage lockout (typ) (V): 5 Rating: Automotive Propagation delay time (µs): 0.02 Rise time (ns): 7.2 Fall time (ns): 5.5 Iq (mA): 0.001 Input threshold: TTL Channel input logic: TTL Switch node voltage (V): -20 TI functional safety category: Functional Safety-Capable Driver configuration: Dual inputs Bootstrap supply voltage (max) (V): 120 Power switch: MOSFET Input supply voltage (min) (V): 5
Input supply voltage (max) (V): 17 Peak output current (A): 4 Operating temperature range (°C): -40 to 150 Undervoltage lockout (typ) (V): 5 Rating: Automotive Propagation delay time (µs): 0.02 Rise time (ns): 7.2 Fall time (ns): 5.5 Iq (mA): 0.001 Input threshold: TTL Channel input logic: TTL Switch node voltage (V): -20 TI functional safety category: Functional Safety-Capable Driver configuration: Dual inputs

UCC27212


数据:
分类: 微电路 / 半导体集成电路 / 接口电路 / 驱动器

描述: 具有 5V UVLO 和负电压处理能力的 4A、120V 半桥栅极驱动器

Bootstrap supply voltage (max) (V): 120 Power switch: MOSFET Input supply voltage (min) (V): 5 Input supply voltage (max) (V): 17 Peak output current (A): 4 Operating temperature range (°C): -40 to 150 Undervoltage lockout (typ) (V): 5 Rating: Catalog Propagation delay time (µs): 0.02 Rise time (ns): 7.2 Fall time (ns): 5.5 Iq (mA): 0.001 Input threshold: TTL Channel input logic: TTL Switch node voltage (V): -20 Driver configuration: Dual inputs Bootstrap supply voltage (max) (V): 120 Power switch: MOSFET Input supply voltage (min) (V): 5 Input supply voltage (max) (V): 17
Peak output current (A): 4 Operating temperature range (°C): -40 to 150 Undervoltage lockout (typ) (V): 5 Rating: Catalog Propagation delay time (µs): 0.02 Rise time (ns): 7.2 Fall time (ns): 5.5 Iq (mA): 0.001 Input threshold: TTL Channel input logic: TTL Switch node voltage (V): -20 Driver configuration: Dual inputs
