FAN3121CMPX
制造商: ONSEMI数据:
分类: 微电路 / 半导体集成电路 / 接口电路 / 驱动器
描述: CMOS 输入、单通道同相输入、11.4 A 峰值灌电流、10.6 A 源电流低端栅极驱动器
状态: 已停产
Compliance: Pb A H P
Power Switch: MOSFET
Number of Outputs: 1
Topology: Single
Isolation Type: Non-Isolated
Vin Max (V): -
VCC Max (V): 18
Rise Time (ns): 23
Fall Time (ns): 19
Drive Source Current Typ (A): 11.4
Drive Sink Current Typ (A): 10.6
Turn On Prop. Delay Typ (ns): 18
Turn Off Prop. Delay Typ (ns): 18
Delay Matching: -
Package Type: WDFN-8
MSL Type: 1
MSL Temp (°C): 260
ON Target: No
参考价格: Price N/A
FAN3121TMPX
制造商: ONSEMI数据:
分类: 微电路 / 半导体集成电路 / 接口电路 / 驱动器
描述: TTL 输入，单反相输出，峰值 11.4A 汲电流，10.6A 源电流低压侧门极驱动器
状态: 量产中
Compliance: Pb A H P
Power Switch: MOSFET
Number of Outputs: 1
Topology: Single
Isolation Type: Non-Isolated
Vin Max (V): -
VCC Max (V): 18
Rise Time (ns): 23
Fall Time (ns): 19
Drive Source Current Typ (A): 11.4
Drive Sink Current Typ (A): 10.6
Turn On Prop. Delay Typ (ns): 23
Turn Off Prop. Delay Typ (ns): 23
Delay Matching: -
Package Type: WDFN-8
MSL Type: 1
MSL Temp (°C): 260
ON Target: Yes
参考价格: $0.7882
FAN3121TMX
制造商: ONSEMI数据:
分类: 微电路 / 半导体集成电路 / 接口电路 / 驱动器
描述: TTL 输入，单反相输出，峰值 11.4A 汲电流，10.6A 源电流低压侧门极驱动器
状态: 已停产
Compliance: Pb A H P
Power Switch: MOSFET
Number of Outputs: 1
Topology: Single
Isolation Type: Non-Isolated
Vin Max (V): -
VCC Max (V): 18
Rise Time (ns): 23
Fall Time (ns): 19
Drive Source Current Typ (A): 11.4
Drive Sink Current Typ (A): 10.6
Turn On Prop. Delay Typ (ns): 23
Turn Off Prop. Delay Typ (ns): 23
Delay Matching: -
Package Type: SOIC-8
MSL Type: 1
MSL Temp (°C): 260
ON Target: No
参考价格: Price N/A
FAN3122CMX
制造商: ONSEMI数据:
分类: 微电路 / 半导体集成电路 / 接口电路 / 驱动器
描述: CMOS 输入，单非反相输出，峰值 11.4A 汲电流，10.6A 源电流，低压侧门极驱动器
状态: 量产中
Compliance: Pb A H P
Power Switch: MOSFET
Number of Outputs: 1
Topology: Single
Isolation Type: Non-Isolated
Vin Max (V): -
VCC Max (V): 18
Rise Time (ns): 23
Fall Time (ns): 19
Drive Source Current Typ (A): 11.4
Drive Sink Current Typ (A): 10.6
Turn On Prop. Delay Typ (ns): 18
Turn Off Prop. Delay Typ (ns): 18
Delay Matching: -
Package Type: SOIC-8
MSL Type: 1
MSL Temp (°C): 260
ON Target: Yes
参考价格: $0.9936
FAN3122CMPX
制造商: ONSEMI数据:
分类: 微电路 / 半导体集成电路 / 接口电路 / 驱动器
描述: CMOS 输入，单非反相输出，峰值 11.4A 汲电流，10.6A 源电流，低压侧门极驱动器
状态: 量产中
Compliance: Pb A H P
Power Switch: MOSFET
Number of Outputs: 1
Topology: Single
Isolation Type: Non-Isolated
Vin Max (V): -
VCC Max (V): 18
Rise Time (ns): 23
Fall Time (ns): 19
Drive Source Current Typ (A): 11.4
Drive Sink Current Typ (A): 10.6
Turn On Prop. Delay Typ (ns): 18
Turn Off Prop. Delay Typ (ns): 18
Delay Matching: -
Package Type: WDFN-8
MSL Type: 1
MSL Temp (°C): 260
ON Target: Yes
参考价格: $0.9299
FAN3122TMPX
制造商: ONSEMI数据:
分类: 微电路 / 半导体集成电路 / 接口电路 / 驱动器
描述: TTL 输入，非反相单输出，峰值 11.4A 汲电流，10.6A 源电流，低压侧门极驱动器
状态: 量产中
Compliance: Pb A H P
Power Switch: MOSFET
Number of Outputs: 1
Topology: Single
Isolation Type: Non-Isolated
Vin Max (V): -
VCC Max (V): 18
Rise Time (ns): 23
Fall Time (ns): 19
Drive Source Current Typ (A): 11.4
Drive Sink Current Typ (A): 10.6
Turn On Prop. Delay Typ (ns): 23
Turn Off Prop. Delay Typ (ns): 23
Delay Matching: -
Package Type: WDFN-8
MSL Type: 1
MSL Temp (°C): 260
ON Target: Yes
参考价格: $0.8062
FAN3122TMX
制造商: ONSEMI数据:
分类: 微电路 / 半导体集成电路 / 接口电路 / 驱动器
描述: TTL 输入，非反相单输出，峰值 11.4A 汲电流，10.6A 源电流，低压侧门极驱动器
状态: 量产中
Compliance: Pb A H P
Power Switch: MOSFET
Number of Outputs: 1
Topology: Single
Isolation Type: Non-Isolated
Vin Max (V): -
VCC Max (V): 18
Rise Time (ns): 23
Fall Time (ns): 19
Drive Source Current Typ (A): 11.4
Drive Sink Current Typ (A): 10.6
Turn On Prop. Delay Typ (ns): 23
Turn Off Prop. Delay Typ (ns): 23
Delay Matching: -
Package Type: SOIC-8
MSL Type: 1
MSL Temp (°C): 260
ON Target: Yes
参考价格: $0.8173
状态: 量产中
Compliance: Pb A H P
Power Switch: MOSFET
Number of Outputs: 1
Topology: Single
Isolation Type: Non-Isolated
Vin Max (V): 20.3
VCC Max (V): 20
Rise Time (ns): 23
Fall Time (ns): 19
Drive Source Current Typ (A): 7.1
Drive Sink Current Typ (A): 9.7
Turn On Prop. Delay Typ (ns): 23
Turn Off Prop. Delay Typ (ns): 23
Delay Matching: -
Package Type: SOIC-8 EP
MSL Type: 3
MSL Temp (°C): 260
ON Target: No
参考价格: $0.6603
状态: 量产中
Compliance: Pb A H P
Power Switch: MOSFET
Number of Outputs: -
Topology: Single
Isolation Type: Non-Isolated
Vin Max (V): -
VCC Max (V): 18
Rise Time (ns): -
Fall Time (ns): -
Drive Source Current Typ (A): 11.4
Drive Sink Current Typ (A): 10.6
Turn On Prop. Delay Typ (ns): 23
Turn Off Prop. Delay Typ (ns): 23
Delay Matching: -
Package Type: SOIC-8
MSL Type: 3
MSL Temp (°C): 260
ON Target: No
参考价格: $0.6723
Number of channels: 1
Isolation rating: Reinforced
Withstand isolation voltage (VISO) (Vrms): 5000
Working isolation voltage (VIOWM) (Vrms): 1500
Transient isolation voltage (VIOTM) (VPK): 8000
Power switch: IGBT, MOSFET, SiCFET
Peak output current (A): 4.5
Output VCC/VDD (max) (V): 33
Output VCC/VDD (min) (V): 14
Input threshold: 4 mA, 4mA
Operating temperature range (°C): -40 to 125
Rating: Catalog
Bootstrap supply voltage (max) (V): 1500
Fall time (ns): 25
Undervoltage lockout (typ) (V): 12
Number of channels: 1
Isolation rating: Reinforced
Withstand isolation voltage (VISO) (Vrms): 5000
Working isolation voltage (VIOWM) (Vrms): 1500
Transient isolation voltage (VIOTM) (VPK): 8000
更多
Power switch: IGBT, MOSFET, SiCFET
Peak output current (A): 4.5
Output VCC/VDD (max) (V): 33
Output VCC/VDD (min) (V): 14
Input threshold: 4 mA, 4mA
Operating temperature range (°C): -40 to 125
Rating: Catalog
Bootstrap supply voltage (max) (V): 1500
Fall time (ns): 25
Undervoltage lockout (typ) (V): 12
