INFINEON

Infineon 英飞凌专注于迎接现代社会的三大科技挑战： 高能效、 移动性和 安全性，为汽车和工业功率器件、芯片卡和安全应用提供半导体和系统解决方案。英飞凌的产品素以高可靠性、卓越质量和创新性著称，并在模拟和混合信号、射频、功率以及嵌入式控制装置领域掌握尖端技术。

SAL-TC233L-32F200FAC

分类:
数据:

简介: A powerful AURIX™ microcontroller for automotive & industrial applications with a frequency of 200MHz, up to 2MB of Flash and a TQFP-100 package

SRAM (incl. Cache): 192.0kByte CAN Nodes: 6 A/D Input Lines: 24 A/D Input Lines(incl. FADC): 24 Program Memory: 2.0MByte Watchdog Timer: yes Real Time Clock: yes Oscillator Watchdog: yes On-chip Voltage Regulator: yes On-chip Clock Generation: yes Floating Point Unit: yes DSP Functionality: yes Number of ADC Modules: 2.0 Instruction Width([bits]): 32/16 I/O Operation Voltages: 3.3V DMA Channels: 16 External Bus Interface: no Fast Flash Programming: no Touch/LED Matrix Control: no Hardware Accelerator: no
# of cores / lockstep cores: 1/1 eMMC: no SPI: 4.0 LIN: 2.0 Type of Memory: Flash Temperature: -40°C - +150 °C Family: AURIX™ 1G Classification: ISO 26262-compliant Budgetary Price €/1k: 8.04 ASIL/SIL support: ASIL-D/SIL-3

SAL-TC233LP-32F200FAC

分类:
数据:

简介: A powerful AURIX™ microcontroller for automotive & industrial applications with a frequency of 200MHz, up to 2MB of Flash, and a TQFP-100 package

SRAM (incl. Cache): 192.0kByte CAN Nodes: 6 A/D Input Lines: 24 A/D Input Lines(incl. FADC): 24 Program Memory: 2.0MByte Watchdog Timer: yes Real Time Clock: yes Oscillator Watchdog: yes On-chip Voltage Regulator: yes On-chip Clock Generation: yes Floating Point Unit: yes DSP Functionality: yes Number of ADC Modules: 2.0 Instruction Width([bits]): 32/16 I/O Operation Voltages: 3.3V DMA Channels: 16 External Bus Interface: no Fast Flash Programming: no Touch/LED Matrix Control: no # of cores / lockstep cores: 1/1
Hardware Accelerator: no LIN: 2.0 SPI: 4.0 eMMC: no Type of Memory: Flash Temperature: -40°C - +150 °C Family: AURIX™ 1G Classification: ISO 26262-compliant Budgetary Price €/1k: 9.65 ASIL/SIL support: ASIL-D/SIL-3

SAL-TC233LP-32F200NAC

分类:
数据:

简介: A powerful AURIX™ microcontroller for automotive & industrial applications with a frequency of 200MHz, up to 2MB of Flash and a TQFP-100 package

SRAM (incl. Cache): 192.0kByte CAN Nodes: 6 A/D Input Lines: 24 A/D Input Lines(incl. FADC): 24 Program Memory: 2.0MByte Watchdog Timer: yes Real Time Clock: yes Oscillator Watchdog: yes On-chip Voltage Regulator: yes On-chip Clock Generation: yes Floating Point Unit: yes DSP Functionality: yes Number of ADC Modules: 2.0 Instruction Width([bits]): 32/16 I/O Operation Voltages: 3.3V DMA Channels: 16 External Bus Interface: no Fast Flash Programming: no Touch/LED Matrix Control: no # of cores / lockstep cores: 1/1
Hardware Accelerator: no eMMC: no SPI: 4.0 LIN: 2.0 Type of Memory: Flash Temperature: -40°C - +150 °C Family: AURIX™ 1G Classification: ISO 26262-compliant Budgetary Price €/1k: 11.1 ASIL/SIL support: ASIL-D/SIL-3

SAL-TC237L-32F200SAC

分类:
数据:

简介: A powerful AURIX™ microcontroller for automotive & industrial applications with a frequency of 200MHz, up to 2MB of Flash and a LFBGA-292 package

SRAM (incl. Cache): 192.0kByte CAN Nodes: 6 A/D Input Lines: 24 A/D Input Lines(incl. FADC): 24 Program Memory: 2.0MByte Watchdog Timer: yes Real Time Clock: yes Oscillator Watchdog: yes On-chip Voltage Regulator: yes On-chip Clock Generation: yes Floating Point Unit: yes DSP Functionality: yes Number of ADC Modules: 2.0 Instruction Width([bits]): 32/16 I/O Operation Voltages: 3.3V DMA Channels: 16 External Bus Interface: no Fast Flash Programming: no Touch/LED Matrix Control: no # of cores / lockstep cores: 1/1
Hardware Accelerator: no LIN: 2.0 SPI: 4.0 eMMC: no Type of Memory: Flash Temperature: -40°C - +150 °C Family: AURIX™ 1G Classification: ISO 26262-compliant Budgetary Price €/1k: 9.84 ASIL/SIL support: ASIL-D/SIL-3

SAL-TC237LP-32F200NAC

分类:
数据:

简介: A powerful 1st generation AURIX™ microcontroller with a frequency of 200MHz, up to 2MB of Flash and a LFBGA-292 package

SRAM (incl. Cache): 192.0kByte CAN Nodes: 6 A/D Input Lines: 24 A/D Input Lines(incl. FADC): 24 Program Memory: 2.0MByte Watchdog Timer: yes Real Time Clock: yes Oscillator Watchdog: yes On-chip Voltage Regulator: yes On-chip Clock Generation: yes Floating Point Unit: yes DSP Functionality: yes Number of ADC Modules: 2.0 Instruction Width([bits]): 32/16 I/O Operation Voltages: 3.3V DMA Channels: 16 External Bus Interface: no Fast Flash Programming: no Touch/LED Matrix Control: no # of cores / lockstep cores: 1/1
Hardware Accelerator: no eMMC: no SPI: 4.0 LIN: 2.0 Type of Memory: Flash Temperature: -40°C - +150 °C Family: AURIX™ 1G Classification: ISO 26262-compliant Budgetary Price €/1k: 13.17 ASIL/SIL support: ASIL-D/SIL-3

SAL-TC237LP-32F200SAC

分类:
数据:

简介: A powerful AURIX™ microcontroller for automotive & industrial applications with a frequency of 200MHz, up to 2MB of Flash and a LFBGA-292 package

SRAM (incl. Cache): 192.0kByte CAN Nodes: 6 A/D Input Lines: 24 A/D Input Lines(incl. FADC): 24 Program Memory: 2.0MByte Watchdog Timer: yes Real Time Clock: yes Oscillator Watchdog: yes On-chip Voltage Regulator: yes On-chip Clock Generation: yes Floating Point Unit: yes DSP Functionality: yes Number of ADC Modules: 2.0 Instruction Width([bits]): 32/16 DMA Channels: 16 External Bus Interface: no Fast Flash Programming: no Touch/LED Matrix Control: no I/O Operation Voltages: 3.3V LIN: 2.0
SPI: 4.0 eMMC: no # of cores / lockstep cores: 1/1 Hardware Accelerator: no Type of Memory: Flash Temperature: -40°C - +150 °C Family: AURIX™ 1G Classification: ISO 26262-compliant Budgetary Price €/1k: 11.72 ASIL/SIL support: ASIL-D/SIL-3

SAL-TC260D-40F200NBC

分类:
数据:

简介: A powerful AURIX™ microcontroller for automotive & industrial applications with a frequency of 200MHz, up to 2.5MB of Flash and a S-BDWBT-0 package

SRAM (incl. Cache): 240.0kByte CAN Nodes: 5 A/D Input Lines(incl. FADC): 59 Program Memory: 2.5MByte EEPROM Emulation: yes Number of ADC Modules: 7.0 Instruction Width([bits]): 32/16 DMA Channels: 48 External Bus Interface: no Fast Flash Programming: no Additional Features: Dual Core Additional Features: Lockstep Additional Features: Safety IO Monitor Additional Features: Stand-By Controller eMMC: no SPI: 4.0 LIN: 4.0 # of cores / lockstep cores: 2/1 Hardware Accelerator: no Watchdog Timer: yes
Real Time Clock: yes On-chip Clock Generation: yes On-chip Voltage Regulator: yes Additional Features: Ethernet DSP Functionality: Yes Floating Point Unit: Yes Oscillator Watchdog: Yes Type of Memory: Flash Temperature: -40°C - +150 °C Family: AURIX™ 1G Classification: ISO 26262-compliant ASIL/SIL support: ASIL-D/SIL-3

SAL-TC264D-40F200NBC

分类:
数据:

简介: A powerful AURIX™ microcontroller for automotive & industrial applications with a frequency of 200MHz, up to 2.5MB of Flash and a LQFP-144 package

SRAM (incl. Cache): 240.0kByte CAN Nodes: 5 A/D Input Lines(incl. FADC): 43 Program Memory: 2.5MByte EEPROM Emulation: yes Number of ADC Modules: 7.0 Instruction Width([bits]): 32/16 DMA Channels: 48 External Bus Interface: no Fast Flash Programming: no Additional Features: Dual Core Additional Features: Lockstep Additional Features: Safety IO Monitor Additional Features: Stand-By Controller LIN: 4.0 SPI: 4.0 eMMC: no # of cores / lockstep cores: 2/1 Hardware Accelerator: no I/O Operation Voltages max: 5.0V
On-chip Clock Generation: yes On-chip Voltage Regulator: yes Oscillator Watchdog: yes Watchdog Timer: yes Floating Point Unit: yes Real Time Clock: Yes DSP Functionality: Yes Type of Memory: Flash Temperature: -40°C - +150 °C Family: AURIX™ 1G Classification: ISO 26262-compliant Budgetary Price €/1k: 15.94 ASIL/SIL support: ASIL-D/SIL-3

SAL-TC265D-40F200NBC

分类:
数据:

简介: A powerful AURIX™ microcontroller for automotive & industrial applications with a frequency of 200 MHz, up to 2.5MB of Flash and a LQFP-176 package

SRAM (incl. Cache): 240.0kByte CAN Nodes: 5 A/D Input Lines(incl. FADC): 53 Program Memory: 2.5MByte EEPROM Emulation: yes Number of ADC Modules: 7.0 Instruction Width([bits]): 32/16 DMA Channels: 48 External Bus Interface: no Fast Flash Programming: no Additional Features: Dual Core Additional Features: Lockstep Additional Features: Safety IO Monitor Additional Features: Stand-By Controller eMMC: no SPI: 4.0 LIN: 4.0 # of cores / lockstep cores: 2/1 Hardware Accelerator: no Watchdog Timer: yes
Oscillator Watchdog: yes On-chip Voltage Regulator: yes On-chip Clock Generation: yes Floating Point Unit: yes I/O Operation Voltages max: 5.0V DSP Functionality: yes Real Time Clock: Yes Type of Memory: Flash Temperature: -40°C - +150 °C Family: AURIX™ 1G Classification: ISO 26262-compliant Budgetary Price €/1k: 15.94 ASIL/SIL support: ASIL-D/SIL-3

SAL-TC267D-40F200NBC

分类:
数据:

简介: A powerful AURIX™ microcontroller for automotive & industrial applications with a frequency of 200MHz, up to 2.5MB of Flash and a LFBGA-292 package

SRAM (incl. Cache): 240.0kByte CAN Nodes: 5 A/D Input Lines(incl. FADC): 59 Program Memory: 2.5MByte EEPROM Emulation: yes Number of ADC Modules: 7.0 Instruction Width([bits]): 32/16 DMA Channels: 48 External Bus Interface: no Fast Flash Programming: no Additional Features: Dual Core Additional Features: Lockstep Additional Features: Safety IO Monitor Additional Features: Stand-By Controller LIN: 4.0 SPI: 4.0 eMMC: no # of cores / lockstep cores: 2/1 Hardware Accelerator: no On-chip Voltage Regulator: yes
On-chip Clock Generation: yes Oscillator Watchdog: yes Floating Point Unit: yes DSP Functionality: yes Watchdog Timer: yes Real Time Clock: Yes I/O Operation Voltages max: 5.0V Type of Memory: Flash Temperature: -40°C - +150 °C Family: AURIX™ 1G Classification: ISO 26262-compliant Budgetary Price €/1k: 18.72 ASIL/SIL support: ASIL-D/SIL-3
