INFINEON

Infineon 英飞凌专注于迎接现代社会的三大科技挑战：高能效、移动性和安全性，为汽车和工业功率器件、芯片卡和安全应用提供半导体和系统解决方案。英飞凌的产品素以高可靠性、卓越质量和创新性著称，并在模拟和混合信号、射频、功率以及嵌入式控制装置领域掌握尖端技术。

SAL-TC270TP-64F200NDC

分类:
数据:

简介: A powerful AURIX™ microcontroller for automotive & industrial applications with a frequency of 200MHz and up to 4MB of Flash

SRAM (incl. Cache): 472.0kByte CAN Nodes: 4 A/D Input Lines(incl. FADC): 60 Program Memory: 4.0MByte Number of ADC Modules: 14.0 EEPROM Emulation: yes Instruction Width([bits]): 32/16 DMA Channels: 64 External Bus Interface: no Fast Flash Programming: no DSP Functionality: yes On-chip Clock Generation: yes I/O Operation Voltages: 3.3V I/O Operation Voltages: 5.0V Touch/LED Matrix Control: no On-chip Voltage Regulator: yes Real Time Clock: yes Floating Point Unit: yes Oscillator Watchdog: yes Watchdog Timer: yes 更多

eMMC: no SPI: 4.0 LIN: 4.0 # of cores / lockstep cores: 3/2 Hardware Accelerator: no Additional Features: Ethernet Type of Memory: Flash Temperature: -40°C - +150 °C Family: AURIX™ 1G Classification: ISO 26262-compliant ASIL/SIL support: ASIL-D/SIL-3

SAL-TC275TP-64F200NDC

分类:
数据:

简介: A powerful AURIX™ microcontroller for automotive & industrial applications with a frequency of 200MHz, up to 4MB of Flash and a LQFP-176 package

SRAM (incl. Cache): 472.0kByte CAN Nodes: 4 A/D Input Lines(incl. FADC): 48 Program Memory: 4.0MByte Number of ADC Modules: 14.0 EEPROM Emulation: yes Instruction Width([bits]): 32/16 DMA Channels: 64 External Bus Interface: no Fast Flash Programming: no DSP Functionality: yes On-chip Clock Generation: yes I/O Operation Voltages: 3.3V I/O Operation Voltages: 5.0V Touch/LED Matrix Control: no On-chip Voltage Regulator: yes Real Time Clock: yes Floating Point Unit: yes Watchdog Timer: yes Oscillator Watchdog: yes 更多

LIN: 4.0 SPI: 4.0 eMMC: no # of cores / lockstep cores: 3/2 Hardware Accelerator: no Additional Features: Ethernet Type of Memory: Flash Temperature: -40°C - +150 °C Family: AURIX™ 1G Classification: ISO 26262-compliant Budgetary Price €/1k: 18.85 ASIL/SIL support: ASIL-D/SIL-3

SAL-TC275TP-64F200WDC

分类:
数据:

简介: A powerful AURIX™ microcontroller for automotive & industrial applications with a frequency of 200 MHz, up to 4MB of Flash and a LQFP-176 package

SRAM (incl. Cache): 472.0kByte CAN Nodes: 4 A/D Input Lines(incl. FADC): 48 Program Memory: 4.0MByte Number of ADC Modules: 14.0 EEPROM Emulation: yes Instruction Width([bits]): 32/16 DMA Channels: 64 External Bus Interface: no Fast Flash Programming: no DSP Functionality: yes On-chip Clock Generation: yes I/O Operation Voltages: 3.3V I/O Operation Voltages: 5.0V Touch/LED Matrix Control: no On-chip Voltage Regulator: yes Real Time Clock: yes Floating Point Unit: yes Oscillator Watchdog: yes Watchdog Timer: yes 更多

SAL-TC277T-64F200SDC

分类:
数据:

简介: A powerful AURIX™ microcontroller for automotive & industrial applications with a frequency of 200MHz, up to 4MB of Flash and a LFBGA-292 Package

SRAM (incl. Cache): 472.0kByte CAN Nodes: 4 A/D Input Lines(incl. FADC): 60 Program Memory: 4.0MByte Number of ADC Modules: 14.0 EEPROM Emulation: yes Instruction Width([bits]): 32/16 DMA Channels: 64 External Bus Interface: no Fast Flash Programming: no DSP Functionality: yes On-chip Clock Generation: yes I/O Operation Voltages: 3.3V I/O Operation Voltages: 5.0V Touch/LED Matrix Control: no On-chip Voltage Regulator: yes Real Time Clock: yes Floating Point Unit: yes Watchdog Timer: yes Oscillator Watchdog: yes 更多

LIN: 4.0 SPI: 4.0 eMMC: no # of cores / lockstep cores: 3/2 Hardware Accelerator: no Additional Features: Ethernet Type of Memory: Flash Temperature: -40°C - +150 °C Family: AURIX™ 1G Classification: ISO26262-compliant Budgetary Price €/1k: 17.03 Budgetary Price €/1k: 17.03 ASIL/SIL support: ASIL-D/SIL-3

SAL-TC277TP-64F200NDC

分类:
数据:

简介: A powerful AURIX™ microcontroller for automotive & industrial applications with a frequency of 200MHz, up to 4MB of Flash and a LFBGA-292 Package

SRAM (incl. Cache): 472.0kByte CAN Nodes: 4 A/D Input Lines(incl. FADC): 60 Program Memory: 4.0MByte Number of ADC Modules: 14.0 EEPROM Emulation: yes Instruction Width([bits]): 32/16 DMA Channels: 64 External Bus Interface: no Fast Flash Programming: no DSP Functionality: yes On-chip Clock Generation: yes I/O Operation Voltages: 3.3V I/O Operation Voltages: 5.0V Touch/LED Matrix Control: no On-chip Voltage Regulator: yes Real Time Clock: yes Floating Point Unit: yes Watchdog Timer: yes Oscillator Watchdog: yes 更多

SAL-TC290TC-96F300BC

分类:
数据:

简介: A powerful AURIX™ microcontroller for automotive & industrial applications with a frequency of 300MHz, up to 6MB of Flash and a S-BDWBT-0 Package

SRAM (incl. Cache): 456.0kByte CAN Nodes: 6 A/D Input Lines(incl. FADC): 94 Program Memory: 6.0MByte Number of ADC Modules: 21.0 EEPROM Emulation: yes Instruction Width([bits]): 32/16 DMA Channels: 128 External Bus Interface: 1 Fast Flash Programming: no DSP Functionality: yes On-chip Clock Generation: yes I/O Operation Voltages: 3.3V I/O Operation Voltages: 5.0V Touch/LED Matrix Control: no Watchdog Timer: yes Real Time Clock: yes Oscillator Watchdog: yes On-chip Voltage Regulator: yes Floating Point Unit: yes 更多

Additional Features: Ethernet LIN: 6.0 SPI: 4.0 eMMC: no # of cores / lockstep cores: 3/1 Hardware Accelerator: no Type of Memory: Flash Temperature: -40°C - +150 °C Family: AURIX™ 1G Classification: ISO 26262-compliant ASIL/SIL support: ASIL-D/SIL-3

SAL-TC290TP-128F300NBC

分类:
数据:

简介: A powerful AURIX™ microcontroller for automotive & industrial applications with a frequency of 300MHz, up to 8MB of Flash and a S-BDWBT-0 Package

SRAM (incl. Cache): 728.0kByte CAN Nodes: 6 A/D Input Lines(incl. FADC): 94 Program Memory: 8.0MByte Number of ADC Modules: 21.0 EEPROM Emulation: yes Instruction Width([bits]): 32/16 DMA Channels: 128 External Bus Interface: 1 Fast Flash Programming: no DSP Functionality: yes On-chip Clock Generation: yes I/O Operation Voltages: 3.3V I/O Operation Voltages: 5.0V Touch/LED Matrix Control: no Watchdog Timer: yes Real Time Clock: yes Oscillator Watchdog: yes On-chip Voltage Regulator: yes Floating Point Unit: yes 更多

Additional Features: Hardware Security Module Additional Features: Ethernet eMMC: no SPI: 4.0 LIN: 6.0 # of cores / lockstep cores: 3/1 Hardware Accelerator: no Type of Memory: Flash Temperature: -40°C - +150 °C Family: AURIX™ 1G Classification: ISO 26262-compliant ASIL/SIL support: ASIL-D/SIL-3

SAL-TC298TP-128F300NBC

分类:
数据:

简介: A powerful AURIX™ microcontroller for automotive & industrial applications with a frequency of 300MHz, up to 8MB of Flash and a BGA-416 Package

SRAM (incl. Cache): 728.0kByte CAN Nodes: 6 A/D Input Lines(incl. FADC): 94 Program Memory: 8.0MByte Number of ADC Modules: 21.0 EEPROM Emulation: yes Instruction Width([bits]): 32/16 DMA Channels: 128 External Bus Interface: 1 Fast Flash Programming: no DSP Functionality: yes On-chip Clock Generation: yes I/O Operation Voltages: 3.3V I/O Operation Voltages: 5.0V Touch/LED Matrix Control: no On-chip Voltage Regulator: yes Floating Point Unit: yes Oscillator Watchdog: yes Real Time Clock: yes Watchdog Timer: yes 更多

Additional Features: Hardware Security Module Additional Features: Ethernet LIN: 6.0 SPI: 4.0 eMMC: no # of cores / lockstep cores: 3/1 Hardware Accelerator: no Type of Memory: Flash Temperature: -40°C - +150 °C Family: AURIX™ 1G Classification: ISO26262-compliant ASIL/SIL support: ASIL-D/SIL-3

SAL-TC299TP-128F300NBC

分类:
数据:

简介: A powerful AURIX™ microcontroller for automotive & industrial applications with a frequency of 300MHz, up to 8MB of Flash and a LFBGA-516 Package

SRAM (incl. Cache): 728.0kByte CAN Nodes: 6 A/D Input Lines(incl. FADC): 94 Program Memory: 8.0MByte Number of ADC Modules: 21.0 EEPROM Emulation: yes Instruction Width([bits]): 32/16 DMA Channels: 128 External Bus Interface: 1 Fast Flash Programming: no DSP Functionality: yes On-chip Clock Generation: yes I/O Operation Voltages: 3.3V I/O Operation Voltages: 5.0V Touch/LED Matrix Control: no On-chip Voltage Regulator: yes Real Time Clock: yes Floating Point Unit: yes Oscillator Watchdog: yes Watchdog Timer: yes 更多

Additional Features: Hardware Security Module Additional Features: Ethernet Additional Features: Safety IO Monitor eMMC: no SPI: 4.0 LIN: 6.0 # of cores / lockstep cores: 3/1 Hardware Accelerator: no Type of Memory: Flash Temperature: -40°C - +150 °C Family: AURIX™ 1G Classification: ISO26262-compliant Budgetary Price €/1k: 36.39 Budgetary Price €/1k: 36.39 ASIL/SIL support: ASIL-D/SIL-3

SAK-TC212L-8F133FAC

分类:
数据:

简介: A powerful AURIX™ microcontroller for automotive & industrial applications with a frequency of 133 MHz, up to 0.5MB of Flash and a TQFP-80 package

SRAM (incl. Cache): 56.0kByte CAN Nodes: 3 A/D Input Lines(incl. FADC): 14 Program Memory: 0.5MByte Number of ADC Modules: 2.0 Instruction Width([bits]): 32/16 DMA Channels: 16 External Bus Interface: no Fast Flash Programming: no DSP Functionality: yes On-chip Clock Generation: yes I/O Operation Voltages: 3.3V Touch/LED Matrix Control: no Watchdog Timer: yes Real Time Clock: yes Oscillator Watchdog: yes On-chip Voltage Regulator: yes Floating Point Unit: yes # of cores / lockstep cores: 1/1 Hardware Accelerator: no 更多

LIN: 2.0 SPI: 4.0 eMMC: no Type of Memory: Flash Temperature: -40°C - +125°C Family: AURIX™ 1G Classification: ISO 26262-compliant Budgetary Price €/1k: 6.13 ASIL/SIL support: ASIL-D/SIL-3
