ADC32RF54

数据:
分类: 微电路 / 半导体集成电路 / 接口电路 / 模拟/数字(A/D)转换器

描述: 具有低噪声频谱密度 (NSD) 的双通道 14 位 2.6GSPS 射频采样 ADC

Sample rate (max) (Msps): 2600 Resolution (Bits): 14 Number of input channels: 2 Interface type: JESD204B Analog input BW (MHz): 2300 Features: High Dynamic Range, High Performance, Ultra High Speed Rating: Catalog Peak-to-peak input voltage range (V): 1.1 Power consumption (typ) (mW): 3400 SNR (dB): 65.5 ENOB (Bits): 10.5 SFDR (dB): 75 Operating temperature range (°C): -40 to 85 Input buffer: Yes Sample rate (max) (Msps): 2600 Resolution (Bits): 14 Number of input channels: 2 Interface type: JESD204B Analog input BW (MHz): 2300 Features: High Dynamic Range, High Performance, Ultra High Speed 更多

Rating: Catalog Peak-to-peak input voltage range (V): 1.1 Power consumption (typ) (mW): 3400 SNR (dB): 65.5 ENOB (Bits): 10.5 SFDR (dB): 75 Operating temperature range (°C): -40 to 85 Input buffer: Yes

ADS9815

数据:
分类: 微电路 / 半导体集成电路 / 接口电路 / 模拟/数字(A/D)转换器

描述: 具有集成模拟前端的八通道、18 位、1MSPS/通道、双路同步采样 ADC

Resolution (Bits): 18 Sample rate (max) (ksps): 1000 Number of input channels: 8 Interface type: Enhanced SPI, Serial CMOS Architecture: SAR Input type: Differential, Single-ended Multichannel configuration: Multiplexed Rating: Catalog Reference mode: External, Internal Input voltage range (max) (V): 12 Input voltage range (min) (V): -12 Features: Over-Voltage Protection, PGA Operating temperature range (°C): -40 to 125 Power consumption (typ) (mW): 220 Analog supply (min) (V): 4.75 Analog supply voltage (max) (V): 5.25 Digital supply (min) (V): 1.75 Digital supply (max) (V): 1.85 Resolution (Bits): 18 Sample rate (max) (ksps): 1000 更多

Number of input channels: 8 Interface type: Enhanced SPI, Serial CMOS Architecture: SAR Input type: Differential, Single-ended Multichannel configuration: Multiplexed Rating: Catalog Reference mode: External, Internal Input voltage range (max) (V): 12 Input voltage range (min) (V): -12 Features: Over-Voltage Protection, PGA Operating temperature range (°C): -40 to 125 Power consumption (typ) (mW): 220 Analog supply (min) (V): 4.75 Analog supply voltage (max) (V): 5.25 Digital supply (min) (V): 1.75 Digital supply (max) (V): 1.85

ADC12QJ1600-SP

数据:
分类: 微电路 / 半导体集成电路 / 接口电路 / 模拟/数字(A/D)转换器

描述: 耐辐射加固保障 (RHA)、300krad、12 位、四通道、1.6GSPS ADC

Sample rate (max) (Msps): 1600 Resolution (Bits): 12 Number of input channels: 4 Interface type: JESD204B, JESD204C Analog input BW (MHz): 6000 Features: Ultra High Speed Rating: Space Peak-to-peak input voltage range (V): 0.8 Power consumption (typ) (mW): 1910 Architecture: Folding Interpolating SNR (dB): 57.4 ENOB (Bits): 9 SFDR (dB): 64 Operating temperature range (°C): -55 to 125 Input buffer: Yes Radiation, TID (typ) (krad): 300 Radiation, SEL (MeV·cm2/mg): 120 Sample rate (max) (Msps): 1600 Resolution (Bits): 12 Number of input channels: 4 更多

Interface type: JESD204B, JESD204C Analog input BW (MHz): 6000 Features: Ultra High Speed Rating: Space Peak-to-peak input voltage range (V): 0.8 Power consumption (typ) (mW): 1910 Architecture: Folding Interpolating SNR (dB): 57.4 ENOB (Bits): 9 SFDR (dB): 64 Operating temperature range (°C): -55 to 125 Input buffer: Yes Radiation, TID (typ) (krad): 300 Radiation, SEL (MeV·cm2/mg): 120

DDC3256

数据:
分类: 微电路 / 半导体集成电路 / 接口电路 / 模拟/数字(A/D)转换器

描述: 256 通道 20kSPS 电流输入模数转换器

Number of input channels: 256 Resolution (Bits): 24 Features: Computed Tomography (CT) Operating temperature range (°C): 0 to 70 Interface type: LVDS/Serial Rating: Catalog Number of input channels: 256 Resolution (Bits): 24 Features: Computed Tomography (CT) Operating temperature range (°C): 0 to 70 Interface type: LVDS/Serial Rating: Catalog

ADS127L21

数据:
分类: 微电路 / 半导体集成电路 / 接口电路 / 模拟/数字(A/D)转换器

描述: 具有可编程 IIR 和 FIR 滤波器的 24 位、512kSPS 宽带宽 Δ-Σ ADC

Resolution (Bits): 24 Sample rate (max) (ksps): 1365 Number of input channels: 1 Interface type: SPI Architecture: Delta-Sigma Input type: Differential, Single-ended Rating: Catalog TI functional safety category: Functional Safety-Capable Reference mode: External Input voltage range (max) (V): 5 Input voltage range (min) (V): 0 Features: Daisy-Chainable, Oscillator, Small Size, Wideband Operating temperature range (°C): -40 to 125 Analog supply (min) (V): 2.85 Analog supply voltage (max) (V): 5.5 SNR (dB): 110 Digital supply (min) (V): 1.65 Digital supply (max) (V): 5.5 Resolution (Bits): 24 Sample rate (max) (ksps): 1365 更多

Number of input channels: 1 Interface type: SPI Architecture: Delta-Sigma Input type: Differential, Single-ended Rating: Catalog TI functional safety category: Functional Safety-Capable Reference mode: External Input voltage range (max) (V): 5 Input voltage range (min) (V): 0 Features: Daisy-Chainable, Oscillator, Small Size, Wideband Operating temperature range (°C): -40 to 125 Analog supply (min) (V): 2.85 Analog supply voltage (max) (V): 5.5 SNR (dB): 110 Digital supply (min) (V): 1.65 Digital supply (max) (V): 5.5

ADC12DJ5200SE

数据:
分类: 微电路 / 半导体集成电路 / 接口电路 / 模拟/数字(A/D)转换器

描述: 具有双通道 5.2GSPS 或单通道 10.4GSPS 的单端输入射频采样 12 位 ADC

Sample rate (max) (Msps): 5200, 10400 Resolution (Bits): 12 Number of input channels: 1, 2 Interface type: JESD204B, JESD204C Analog input BW (MHz): 6300 Features: High Performance, Ultra High Speed Rating: Catalog Power consumption (typ) (mW): 4000 Architecture: Folding Interpolating SNR (dB): 53.2 ENOB (Bits): 8.4 SFDR (dB): 65 Operating temperature range (°C): -40 to 85 Input buffer: Yes Sample rate (max) (Msps): 5200, 10400 Resolution (Bits): 12 Number of input channels: 1, 2 Interface type: JESD204B, JESD204C Analog input BW (MHz): 6300 Features: High Performance, Ultra High Speed 更多

Rating: Catalog Power consumption (typ) (mW): 4000 Architecture: Folding Interpolating SNR (dB): 53.2 ENOB (Bits): 8.4 SFDR (dB): 65 Operating temperature range (°C): -40 to 85 Input buffer: Yes

ADC12DJ5200-SP

数据:
分类: 微电路 / 半导体集成电路 / 接口电路 / 模拟/数字(A/D)转换器

描述: 耐辐射加固保障 (RHA)、300krad、12 位、双通道 5.2GSPS 或单通道 10.4GSPS ADC

Sample rate (max) (Msps): 5200, 10400 Resolution (Bits): 12 Number of input channels: 1, 2 Interface type: JESD204B, JESD204C Analog input BW (MHz): 7900 Features: Ultra High Speed Rating: Space Peak-to-peak input voltage range (V): 0.825 Power consumption (typ) (mW): 4000 Architecture: Folding Interpolating SNR (dB): 55.6 ENOB (Bits): 8.8 SFDR (dB): 65 Operating temperature range (°C): -55 to 125 Input buffer: Yes Radiation, TID (typ) (krad): 300 Radiation, SEL (MeV·cm2/mg): 120 Sample rate (max) (Msps): 5200, 10400 Resolution (Bits): 12 Number of input channels: 1, 2 更多

Interface type: JESD204B, JESD204C Analog input BW (MHz): 7900 Features: Ultra High Speed Rating: Space Peak-to-peak input voltage range (V): 0.825 Power consumption (typ) (mW): 4000 Architecture: Folding Interpolating SNR (dB): 55.6 ENOB (Bits): 8.8 SFDR (dB): 65 Operating temperature range (°C): -55 to 125 Input buffer: Yes Radiation, TID (typ) (krad): 300 Radiation, SEL (MeV·cm2/mg): 120

AMC1306M25E

数据:
分类: 微电路 / 半导体集成电路 / 接口电路 / 模拟/数字(A/D)转换器

描述: 具有 -55C 工作温度范围的增强型隔离调制器

Device type: Current sensing Peak-to-peak input voltage range (V): 250mV Interface type: Serial CMOS Sample rate (max) (Msps): 21 Rating: Catalog CMTI (min) (kV/µs): 50 Number of input channels: 1 Architecture: Delta-Sigma SNR (dB): 82 Operating temperature range (°C): -55 to 125 Power consumption (typ) (mW): 42.4 SFDR (dB): 83 Isolation rating: Reinforced Withstand isolation voltage (VISO) (Vrms): 5000 Working isolation voltage (VIOWM) (Vrms): 1500 Transient isolation voltage (VIOTM) (VPK): 7 Device type: Current sensing Peak-to-peak input voltage range (V): 250mV Interface type: Serial CMOS Sample rate (max) (Msps): 21 更多

Rating: Catalog CMTI (min) (kV/µs): 50 Number of input channels: 1 Architecture: Delta-Sigma SNR (dB): 82 Operating temperature range (°C): -55 to 125 Power consumption (typ) (mW): 42.4 SFDR (dB): 83 Isolation rating: Reinforced Withstand isolation voltage (VISO) (Vrms): 5000 Working isolation voltage (VIOWM) (Vrms): 1500 Transient isolation voltage (VIOTM) (VPK): 7

ADC34RF52

数据:
分类: 微电路 / 半导体集成电路 / 接口电路 / 模拟/数字(A/D)转换器

描述: 四通道、14 位、1.5GSPS、低噪声频谱密度 (NSD) 射频采样 ADC

Sample rate (max) (Msps): 1500 Resolution (Bits): 14 Number of input channels: 4 Interface type: JESD204B Analog input BW (MHz): 2300 Features: High Dynamic Range, High Performance, Ultra High Speed Rating: Catalog Peak-to-peak input voltage range (V): 1.1 Power consumption (typ) (mW): 2920 SNR (dB): 66.3 ENOB (Bits): 10.4 SFDR (dB): 72 Operating temperature range (°C): -40 to 85 Input buffer: No Sample rate (max) (Msps): 1500 Resolution (Bits): 14 Number of input channels: 4 Interface type: JESD204B Analog input BW (MHz): 2300 Features: High Dynamic Range, High Performance, Ultra High Speed 更多

Rating: Catalog Peak-to-peak input voltage range (V): 1.1 Power consumption (typ) (mW): 2920 SNR (dB): 66.3 ENOB (Bits): 10.4 SFDR (dB): 72 Operating temperature range (°C): -40 to 85 Input buffer: No

ADC3543

数据:
分类: 微电路 / 半导体集成电路 / 接口电路 / 模拟/数字(A/D)转换器

描述: 单通道、14 位、65MSPS、低噪声、超低功耗和低延迟 ADC

Sample rate (max) (Msps): 65 Resolution (Bits): 14 Number of input channels: 1 Interface type: CMOS Analog input BW (MHz): 900 Features: High Dynamic Range, High Performance, Low Power Rating: Catalog Peak-to-peak input voltage range (V): 2.25 Power consumption (typ) (mW): 84 Architecture: SAR SNR (dB): 79 ENOB (Bits): 12.8 SFDR (dB): 90 Operating temperature range (°C): -40 to 105 Input buffer: No Sample rate (max) (Msps): 65 Resolution (Bits): 14 Number of input channels: 1 Interface type: CMOS Analog input BW (MHz): 900 更多

Features: High Dynamic Range, High Performance, Low Power Rating: Catalog Peak-to-peak input voltage range (V): 2.25 Power consumption (typ) (mW): 84 Architecture: SAR SNR (dB): 79 ENOB (Bits): 12.8 SFDR (dB): 90 Operating temperature range (°C): -40 to 105 Input buffer: No
