TAC5211

数据:
分类: 微电路 / 半导体集成电路 / 接口电路 / 编译码电路

描述: High-performance mono audio codec with 119dB dynamic range ADC and 120dB dynamic range DAC

Number of ADC channels: 1 Number of DAC channels: 1 Digital audio interface: I2S, L, TDM Analog inputs: 1 Analog outputs: 1 Sampling rate (max) (kHz): 768 Rating: Catalog ADC SNR (typ) (dB): 119 DAC SNR (typ) (dB): 120 Operating temperature range (°C): -40 to 125 Number of ADC channels: 1 Number of DAC channels: 1 Digital audio interface: I2S, L, TDM Analog inputs: 1 Analog outputs: 1 Sampling rate (max) (kHz): 768 Rating: Catalog ADC SNR (typ) (dB): 119 DAC SNR (typ) (dB): 120 Operating temperature range (°C): -40 to 125

TAC5212

数据:
分类: 微电路 / 半导体集成电路 / 接口电路 / 编译码电路

描述: High-performance stereo audio codec with 119dB dynamic range ADC and 120dB dynamic range DAC

Number of ADC channels: 2 Number of DAC channels: 2 Digital audio interface: I2S, L, TDM Analog inputs: 2 Analog outputs: 2 Sampling rate (max) (kHz): 768 Rating: Catalog ADC SNR (typ) (dB): 119 DAC SNR (typ) (dB): 120 Operating temperature range (°C): -40 to 125 Number of ADC channels: 2 Number of DAC channels: 2 Digital audio interface: I2S, L, TDM Analog inputs: 2 Analog outputs: 2 Sampling rate (max) (kHz): 768 Rating: Catalog ADC SNR (typ) (dB): 119 DAC SNR (typ) (dB): 120 Operating temperature range (°C): -40 to 125

TAC5242

数据:
分类: 微电路 / 半导体集成电路 / 接口电路 / 编译码电路

描述: Hardware-control stereo audio codec with 119dB dynamic range ADC and 120dB dynamic range DAC

Number of ADC channels: 2 Number of DAC channels: 2 Digital audio interface: I2S, L, TDM Analog inputs: 2 Analog outputs: 2 Sampling rate (max) (kHz): 192 Rating: Catalog ADC SNR (typ) (dB): 119 DAC SNR (typ) (dB): 120 Operating temperature range (°C): -40 to 125 Number of ADC channels: 2 Number of DAC channels: 2 Digital audio interface: I2S, L, TDM Analog inputs: 2 Analog outputs: 2 Sampling rate (max) (kHz): 192 Rating: Catalog ADC SNR (typ) (dB): 119 DAC SNR (typ) (dB): 120 Operating temperature range (°C): -40 to 125

TLV320AIC3109-Q1

数据:
分类: 微电路 / 半导体集成电路 / 接口电路 / 编译码电路

描述: 汽车类低功耗 96kHz 单声道音频编解码器

Number of ADC channels: 1 Number of DAC channels: 1 Digital audio interface: DSP, I2S, L, R, TDM Analog inputs: 4 Analog outputs: 6 Sampling rate (max) (kHz): 96 Rating: Automotive Features: Mono headphone amplifier ADC SNR (typ) (dB): 92 DAC SNR (typ) (dB): 102 Operating temperature range (°C): -40 to 105 Number of ADC channels: 1 Number of DAC channels: 1 Digital audio interface: DSP, I2S, L, R, TDM Analog inputs: 4 Analog outputs: 6 Sampling rate (max) (kHz): 96 Rating: Automotive Features: Mono headphone amplifier ADC SNR (typ) (dB): 92 更多

DAC SNR (typ) (dB): 102 Operating temperature range (°C): -40 to 105

TLV320AIC3268

数据:
分类: 微电路 / 半导体集成电路 / 接口电路 / 编译码电路

描述: TLV320AIC3268 超低功耗立体声音频编解码器

Number of ADC channels: 2 Number of DAC channels: 2 Digital audio interface: DSP, I2S, L&R, PCM, TDM Analog inputs: 8 Analog outputs: 7 Sampling rate (max) (kHz): 192 Rating: Catalog Features: MiniDSP, Mono Class-D amplifier, Stereo headphone amplifier ADC SNR (typ) (dB): 95 DAC SNR (typ) (dB): 105 Operating temperature range (°C): -40 to 85 Number of ADC channels: 2 Number of DAC channels: 2 Digital audio interface: DSP, I2S, L&R, PCM, TDM Analog inputs: 8 Analog outputs: 7 Sampling rate (max) (kHz): 192 Rating: Catalog Features: MiniDSP, Mono Class-D amplifier, Stereo headphone amplifier ADC SNR (typ) (dB): 95 更多

DAC SNR (typ) (dB): 105 Operating temperature range (°C): -40 to 85

TLV320AIC3254-Q1

数据:
分类: 微电路 / 半导体集成电路 / 接口电路 / 编译码电路

描述: 采用 miniDSP 和 PowerTune™ 技术的汽车类超低功耗立体声音频编解码器

Number of ADC channels: 2 Number of DAC channels: 2 Digital audio interface: DSP, I2S, L, R, TDM Analog inputs: 6 Analog outputs: 4 Sampling rate (max) (kHz): 192 Rating: Automotive ADC SNR (typ) (dB): 93 DAC SNR (typ) (dB): 100 Operating temperature range (°C): -40 to 85 Number of ADC channels: 2 Number of DAC channels: 2 Digital audio interface: DSP, I2S, L, R, TDM Analog inputs: 6 Analog outputs: 4 Sampling rate (max) (kHz): 192 Rating: Automotive ADC SNR (typ) (dB): 93 DAC SNR (typ) (dB): 100 Operating temperature range (°C): -40 to 85

TLV320AIC3263

数据:
分类: 微电路 / 半导体集成电路 / 接口电路 / 编译码电路

描述: 具有 miniDSP、D 类扬声器、DirectPath 耳机和 4 个数字麦克风的低功耗立体声音频编解码器

Number of ADC channels: 2 Number of DAC channels: 2 Digital audio interface: DSP, I2S, L&R, PCM, TDM Analog inputs: 8 Analog outputs: 7 Sampling rate (max) (kHz): 192 Rating: Catalog Features: MiniDSP, Mono Class-D amplifier, Stereo headphone amplifier ADC SNR (typ) (dB): 93 DAC SNR (typ) (dB): 101 Operating temperature range (°C): -40 to 85 Number of ADC channels: 2 Number of DAC channels: 2 Digital audio interface: DSP, I2S, L&R, PCM, TDM Analog inputs: 8 Analog outputs: 7 Sampling rate (max) (kHz): 192 Rating: Catalog Features: MiniDSP, Mono Class-D amplifier, Stereo headphone amplifier ADC SNR (typ) (dB): 93 更多

DAC SNR (typ) (dB): 101 Operating temperature range (°C): -40 to 85

TLV320AIC3212

数据:
分类: 微电路 / 半导体集成电路 / 接口电路 / 编译码电路

描述: 具有集成 D 类扬声器、听筒驱动器和 DirectPath™ 的低功耗立体声编解码器

Number of ADC channels: 2 Number of DAC channels: 2 Digital audio interface: DSP, I2S, L&R, PCM, TDM Analog inputs: 8 Analog outputs: 7 Sampling rate (max) (kHz): 192 Rating: Catalog Features: Stereo Class-D amplifier, Stereo headphone amplifier ADC SNR (typ) (dB): 93 DAC SNR (typ) (dB): 100 Operating temperature range (°C): -40 to 85 Number of ADC channels: 2 Number of DAC channels: 2 Digital audio interface: DSP, I2S, L&R, PCM, TDM Analog inputs: 8 Analog outputs: 7 Sampling rate (max) (kHz): 192 Rating: Catalog Features: Stereo Class-D amplifier, Stereo headphone amplifier ADC SNR (typ) (dB): 93 更多

DAC SNR (typ) (dB): 100 Operating temperature range (°C): -40 to 85

TLV320AIC3262

数据:
分类: 微电路 / 半导体集成电路 / 接口电路 / 编译码电路

描述: 具有 miniDSP 立体声 D 类扬声器、DirectPath 耳机的低功耗立体声编解码器

Number of ADC channels: 2 Number of DAC channels: 2 Digital audio interface: DSP, I2S, L&R, PCM, TDM Analog inputs: 8 Analog outputs: 7 Sampling rate (max) (kHz): 192 Rating: Catalog Features: MiniDSP, Stereo Class-D amplifier, Stereo headphone amplifier ADC SNR (typ) (dB): 93 DAC SNR (typ) (dB): 101 Operating temperature range (°C): -40 to 85 Number of ADC channels: 2 Number of DAC channels: 2 Digital audio interface: DSP, I2S, L&R, PCM, TDM Analog inputs: 8 Analog outputs: 7 Sampling rate (max) (kHz): 192 Rating: Catalog Features: MiniDSP, Stereo Class-D amplifier, Stereo headphone amplifier ADC SNR (typ) (dB): 93 更多

DAC SNR (typ) (dB): 101 Operating temperature range (°C): -40 to 85

PCM3070

数据:
分类: 微电路 / 半导体集成电路 / 接口电路 / 编译码电路

描述: 具有嵌入式 miniDSP 的立体声音频编解码器

Number of ADC channels: 2 Number of DAC channels: 2 Digital audio interface: DSP, I2S, L, R, TDM Analog inputs: 6 Analog outputs: 4 Sampling rate (max) (kHz): 192 Rating: Catalog Features: MiniDSP, Phase-locked loop (PLL), Stereo headphone amplifier ADC SNR (typ) (dB): 93 DAC SNR (typ) (dB): 100 Operating temperature range (°C): -40 to 85 Number of ADC channels: 2 Number of DAC channels: 2 Digital audio interface: DSP, I2S, L, R, TDM Analog inputs: 6 Analog outputs: 4 Sampling rate (max) (kHz): 192 Rating: Catalog Features: MiniDSP, Phase-locked loop (PLL), Stereo headphone amplifier ADC SNR (typ) (dB): 93 更多

DAC SNR (typ) (dB): 100 Operating temperature range (°C): -40 to 85
