Type: Omnipolar switch Supply current (µA): 3500 Bandwidth (kHz): 10 Supply voltage (min) (V): 2.7 Supply voltage (max) (V): 38 Rating: Catalog Operating temperature range (°C): -40 to 125 Output: Open drain Type: Omnipolar switch Supply current (µA): 3500 Bandwidth (kHz): 10 Supply voltage (min) (V): 2.7 Supply voltage (max) (V): 38 Rating: Catalog Operating temperature range (°C): -40 to 125 Output: Open drain

Type: 2D Latch Operate point (typ) (mT): 1.4, 3 Operate point (max) (mT): 2.6, 5.3 Release point (min) (mT): -5.3, -2.6 Supply current (µA): 6000 Bandwidth (kHz): 40 Supply voltage (min) (V): 2.5 Supply voltage (max) (V): 38 Rating: Catalog Operating temperature range (°C): -40 to 125 Output: Open drain Type: 2D Latch Operate point (typ) (mT): 1.4, 3 Operate point (max) (mT): 2.6, 5.3 Release point (min) (mT): -5.3, -2.6 Supply current (µA): 6000 Bandwidth (kHz): 40 Supply voltage (min) (V): 2.5 Supply voltage (max) (V): 38 Rating: Catalog 更多

Type: 2D Latch Operate point (typ) (mT): 1.4, 3 Operate point (max) (mT): 2.6, 5.3 Release point (min) (mT): -5.3, -2.6 Supply current (µA): 6000 Bandwidth (kHz): 40 Supply voltage (min) (V): 2.5 Supply voltage (max) (V): 38 Rating: Catalog Operating temperature range (°C): -40 to 125 Output: Open drain Type: 2D Latch Operate point (typ) (mT): 1.4, 3 Operate point (max) (mT): 2.6, 5.3 Release point (min) (mT): -5.3, -2.6 Supply current (µA): 6000 Bandwidth (kHz): 40 Supply voltage (min) (V): 2.5 Supply voltage (max) (V): 38 Rating: Catalog 更多

Type: Unipolar switch Operate point (typ) (mT): 4, 6, 10, 15 Operate point (max) (mT): 5, 7, 11, 16.1 Release point (min) (mT): 1, 3, 6.8, 11.4 Supply current (µA): 3500, 6000 Bandwidth (kHz): 40 Supply voltage (min) (V): 2.5 Supply voltage (max) (V): 38 Rating: Catalog Operating temperature range (°C): -40 to 125 Output: Current Type: Unipolar switch Operate point (typ) (mT): 4, 6, 10, 15 Operate point (max) (mT): 5, 7, 11, 16.1 Release point (min) (mT): 1, 3, 6.8, 11.4 Supply current (µA): 3500, 6000 Bandwidth (kHz): 40 Supply voltage (min) (V): 2.5 Supply voltage (max) (V): 38 Rating: Catalog 更多

Type: Unipolar switch Operate point (typ) (mT): 2.9, 9.2, 17.9 Operate point (max) (mT): 4.7, 14, 25.4 Release point (min) (mT): 0.1, 2.7, 5.1 Supply current (µA): 2300 Bandwidth (kHz): 30 Supply voltage (min) (V): 2.5 Supply voltage (max) (V): 5.5 Rating: Automotive Operating temperature range (°C): -40 to 150 Output: Open drain Type: Unipolar switch Operate point (typ) (mT): 2.9, 9.2, 17.9 Operate point (max) (mT): 4.7, 14, 25.4 Release point (min) (mT): 0.1, 2.7, 5.1 Supply current (µA): 2300 Bandwidth (kHz): 30 Supply voltage (min) (V): 2.5 Supply voltage (max) (V): 5.5 Rating: Automotive 更多

Type: Unipolar switch Operate point (typ) (mT): 2.9, 9.2, 17.9 Operate point (max) (mT): 4.4, 12.5, 22.7 Release point (min) (mT): 0.4, 3.6, 6.7 Supply current (µA): 2300 Bandwidth (kHz): 30 Supply voltage (min) (V): 2.5 Supply voltage (max) (V): 5.5 Rating: Catalog Operating temperature range (°C): -40 to 125 Output: Open drain Type: Unipolar switch Operate point (typ) (mT): 2.9, 9.2, 17.9 Operate point (max) (mT): 4.4, 12.5, 22.7 Release point (min) (mT): 0.4, 3.6, 6.7 Supply current (µA): 2300 Bandwidth (kHz): 30 Supply voltage (min) (V): 2.5 Supply voltage (max) (V): 5.5 Rating: Catalog 更多

Type: Latch Operate point (typ) (mT): 0.7, 1.8 Operate point (max) (mT): 2.9, 4.5 Release point (min) (mT): -4.5, -2.9 Supply current (µA): 2300 Bandwidth (kHz): 30 Supply voltage (min) (V): 2.5 Supply voltage (max) (V): 5.5 Rating: Automotive Operating temperature range (°C): -40 to 150 Output: Open drain Type: Latch Operate point (typ) (mT): 0.7, 1.8 Operate point (max) (mT): 2.9, 4.5 Release point (min) (mT): -4.5, -2.9 Supply current (µA): 2300 Bandwidth (kHz): 30 Supply voltage (min) (V): 2.5 Supply voltage (max) (V): 5.5 Rating: Automotive 更多

Type: Latch Operate point (typ) (mT): 0.7, 1.8 Operate point (max) (mT): 2, 3.7 Release point (min) (mT): -3.7, -2 Supply current (µA): 2300 Bandwidth (kHz): 30 Supply voltage (min) (V): 2.5 Supply voltage (max) (V): 5.5 Rating: Catalog Operating temperature range (°C): -40 to 125 Output: Open drain Type: Latch Operate point (typ) (mT): 0.7, 1.8 Operate point (max) (mT): 2, 3.7 Release point (min) (mT): -3.7, -2 Supply current (µA): 2300 Bandwidth (kHz): 30 Supply voltage (min) (V): 2.5 Supply voltage (max) (V): 5.5 Rating: Catalog 更多

Type: Latch Operate point (typ) (mT): 2 Operate point (max) (mT): 3.8 Release point (min) (mT): -3.8 Supply current (µA): 2300 Bandwidth (kHz): 30 Supply voltage (min) (V): 2.5 Supply voltage (max) (V): 5.5 Rating: Catalog Operating temperature range (°C): -40 to 135 Output: Push-Pull output driver Type: Latch Operate point (typ) (mT): 2 Operate point (max) (mT): 3.8 Release point (min) (mT): -3.8 Supply current (µA): 2300 Bandwidth (kHz): 30 Supply voltage (min) (V): 2.5 Supply voltage (max) (V): 5.5 Rating: Catalog 更多

Type: Latch Operate point (typ) (mT): 2 Operate point (max) (mT): 3.3 Release point (min) (mT): -3.3 Supply current (µA): 1.3, 142 Bandwidth (kHz): 0.02, 2.5 Supply voltage (min) (V): 1.65 Supply voltage (max) (V): 5.5 Rating: Catalog Operating temperature range (°C): -40 to 85 Output: Push-Pull output driver Type: Latch Operate point (typ) (mT): 2 Operate point (max) (mT): 3.3 Release point (min) (mT): -3.3 Supply current (µA): 1.3, 142 Bandwidth (kHz): 0.02, 2.5 Supply voltage (min) (V): 1.65 Supply voltage (max) (V): 5.5 Rating: Catalog 更多
