TLE9201SG

数据:
分类: 微电路 / 半导体集成电路 / 接口电路 / 驱动器

描述: The MOTIX™ TLE9201SG is a general purpose 6A H-Bridge for industrial and automotive applications

R[DS (on)]: 100.0mΩ I[q]: 19.0µA I[D(lim)](multiple): 6.0 A Diagnostics: SPI & Status Flag Protect: SC Protect: OT Protect: OC Mounting: SMT R[DS (on)](switch): 100.0mΩ I[q]: 13.0mA Inhibit: Yes Operating Voltage max: 28.0V Technology: MOTIX™ Bridge Currently planned availability until at least: 2037 Normal Operating Voltage Range: 5 V - 28 V Temperature max: 150.0°C RDSON_H(typ): 100.0mΩ RDSON_L(typ): 100.0mΩ Over current detection min: 6.0A Supply Voltage absolute max ratings: 40.0V

IFX9201SG

数据:
分类: 微电路 / 半导体集成电路 / 接口电路 / 驱动器

描述: The MOTIX™ IFX9201SG a general purpose 6A H-bridgedesigned for the control of small DC motors and inductive load

R[DS (on)]: 100.0mΩ I[D(lim)](multiple): 6.0 A Diagnostics: SPI & Status Flag Protect: SC Protect: OT Protect: OC Mounting: SMT R[DS (on)](switch): 100.0mΩ I[q]: 19.0µA I[q]: 13.0mA Language: PLECS Product Category: Motor Control ICs Inhibit: Yes Operating Voltage max: 36.0V Technology: MOTIX™ Bridge Currently planned availability until at least: 2037 Normal Operating Voltage Range: 5 V - 36 V RDSON_H(typ): 100.0mΩ RDSON_L(typ): 100.0mΩ Over current detection min: 6.0A Temperature max: 125.0°C

TLE9561QX

数据:
分类: 微电路 / 半导体集成电路 / 接口电路 / 驱动器

描述: The MOTIX™ TLE9561QX is a multifunctional system IC with integrated power supply, communication interfaces, multiple half-bridges

Channels: 8.0 Configuration: Half Bridge Quiescent Current: 18 μA (typ) Sleep Mode Transmission Rate max: 5.0MBit/s Voltage Regulator Output((VCC1)): 5V / 250 mA Output Drivers: 1 x Dual-stage Charge Pump Output Drivers: 4 x High-Side Switch 150 mA Wake-up Inputs: Wake Pins, CAN Temperature: - 40°C - 150°C Technology: MOTIX™ SBC Operating Voltage max: 28.0V Currently planned availability until at least: 2038 Family: MOTIX™ motor system ICs (SBC) Interfaces: SPI Qualification: Automotive Classification: ISO26262-ready Temperature max: 150.0°C Transceiver: 1 x CAN FD Gate current max: 100.0mA Supply Voltage absolute max ratings: 40.0V Supply Voltage max: 28.0V

TLE9561-3QX

数据:
分类: 微电路 / 半导体集成电路 / 接口电路 / 驱动器

描述: The MOTIX™ TLE9561-3QX is a multifunctional system IC with integrated power supply, communication interfaces, multiple half-bridges

Channels: 8.0 Configuration: Half Bridge Transmission Rate max: 5.0MBit/s Quiescent Current: 18 μA (typ) Sleep Mode Voltage Regulator Output((VCC1)): 5V / 250 mA Output Drivers: 1 x Dual-stage Charge Pump Output Drivers: 4 x High-Side Switch 150 mA Wake-up Inputs: Wake Pins, CAN Temperature: - 40°C - 150°C Technology: MOTIX™ SBC Operating Voltage max: 28.0V Currently planned availability until at least: 2038 Family: MOTIX™ motor system ICs (SBC) Interfaces: SPI Qualification: Automotive Classification: ISO26262-ready Temperature max: 150.0°C Transceiver: 1 x CAN FD Gate current max: 100.0mA Supply Voltage absolute max ratings: 40.0V Supply Voltage max: 28.0V

BTM9021EP

数据:
分类: 微电路 / 半导体集成电路 / 接口电路 / 驱动器

描述: The MOTIX™ BTM9021EP is a fully integrated H-bridge motor driver with small footprint and adjustable slew rate at two levels for an improved EMC performance. It operates via SPI interface.

Operating Voltage max: 40.0V Protect: Overtemperature Protect: undervoltage Protect: overcurrent Protect: short circuit Protect: crosscurrent Diagnostics: Open load detection Diagnostics: current sense Normal Operating Voltage Range: 7 V - 18 V Digital interface: SDI Digital interface: SCLK Digital interface: CS Digital interface: SDO Pulse current (at 85°C)(for tpulse≤ 1 s): 5.8A Pulse current (at 85°C)(for tpulse ≤ 10 s): 6.9A Product validation: AEC-Q100 (Grade 1) I[D(lim)](multiple): min 20.0 A Technology: MOTIX™ Bridge R[DS (on)]: 42.0mΩ Currently planned availability until at least: 2038 更多

Interfaces: SPI Classification: ISO26262-ready Temperature max: 150.0°C RDSON_H(typ): 42.0mΩ RDSON_L(typ): 42.0mΩ Over current detection min: 20.0A Supply Voltage absolute max ratings: 40.0V

TLE94112ES

数据:
分类: 微电路 / 半导体集成电路 / 接口电路 / 驱动器

描述: The MOTIX™ TLE94112ES is a protected twelve-fold half-bridge driver designed especially for automotive motion control applications

I[D(lim)](multiple): 12 x 0.9A Inhibit: Yes I[q]: 0.6µA Mounting: SMT Operating Voltage max: 20.0V R[DS (on) ] (multiple): 850 mOhm Diagnostics: OC, TW, TSD, PSF, OL, SPI_ERR, NPOR Protect: SC, OT, UV, OV, OL Temperature: - 40°C - 150°C Currently planned availability until at least: 2037 Technology: MOTIX™ Bridge RDSON_H(typ): 850.0mΩ RDSON_L(typ): 850.0mΩ Over current detection min: 0.9A Supply Voltage absolute max ratings: 40.0V

BTM9020EP

数据:
分类: 微电路 / 半导体集成电路 / 接口电路 / 驱动器

描述: The MOTIX™ BTM9020EP is a fully integrated H-bridge motor driver with small footprint and adjustable slew rate at two levels for an improved EMC performance. It operates via direct interface.

Operating Voltage max: 40.0V Protect: Overtemperature Protect: undervoltage Protect: overcurrent Protect: short circuit Protect: crosscurrent Diagnostics: Open load detection Diagnostics: current sense Normal Operating Voltage Range: 7 V - 18 V Digital interface: INA Digital interface: INB Digital interface: SEL Digital interface: PWM Pulse current (at 85°C)(for tpulse≤ 1 s): 5.8A Pulse current (at 85°C)(for tpulse ≤ 10 s): 6.9A Product validation: AEC-Q100 (Grade 1) I[D(lim)](multiple): min 20.0 A Technology: MOTIX™ Bridge R[DS (on)]: 42.0mΩ Currently planned availability until at least: 2038 更多

Classification: ISO26262-ready Temperature max: 150.0°C RDSON_H(typ): 42.0mΩ RDSON_L(typ): 42.0mΩ Over current detection min: 20.0A Supply Voltage absolute max ratings: 40.0V

TLE94110ES

数据:
分类: 微电路 / 半导体集成电路 / 接口电路 / 驱动器

描述: The MOTIX™ TLE94110ES is a protected ten-fold half-bridge driver designed especially for automotive motion control applications

I[D(lim)](multiple): 10 x 0.9A I[q]: 0.6µA Inhibit: Yes Mounting: SMT Operating Voltage max: 20.0V R[DS (on) ] (multiple): 850 mOhm Temperature: - 40°C - 150°C Diagnostics: OC, TW, TSD, PSF, OL, SPI_ERR, NPOR Protect: SC, OT, UV, OV, OL Currently planned availability until at least: 2037 Technology: MOTIX™ Bridge RDSON_H(typ): 850.0mΩ RDSON_L(typ): 850.0mΩ Over current detection min: 0.9A Supply Voltage absolute max ratings: 40.0V

TLE9562-3QX

数据:
分类: 微电路 / 半导体集成电路 / 接口电路 / 驱动器

描述: The MOTIX™ TLE9562-3QX is a multifunctional system IC with integrated power supply, communication interfaces, multiple half-bridges

Quiescent Current: 18 μA (typ) Sleep Mode Configuration: Half Bridge Channels: 8.0 Transmission Rate max: 5.0MBit/s Voltage Regulator Output((VCC1)): 5V / 250 mA Output Drivers: 1 x Dual-stage Charge Pump Output Drivers: 4 x High-Side Switch 150 mA Wake-up Inputs: Wake Pins, CAN, LIN Temperature: - 40°C - 150°C Technology: MOTIX™ SBC Operating Voltage max: 28.0V Currently planned availability until at least: 2038 Family: MOTIX™ motor system ICs (SBC) Interfaces: SPI Qualification: Automotive Classification: ISO26262-ready Temperature max: 150.0°C Transceiver: 1 x LIN Transceiver: 1 x CAN FD Gate current max: 100.0mA 更多

Supply Voltage absolute max ratings: 40.0V Supply Voltage max: 28.0V

TLE9564QX

数据:
分类: 微电路 / 半导体集成电路 / 接口电路 / 驱动器

描述: The MOTIX™ TLE9564QX is a multifunctional system IC with integrated power supply, communication interfaces, multiple half-bridges

|Product Group|: BLDC Motor System IC Channels: 6.0 Configuration: Three Phase Output Drivers: 1 x Dual-stage Charge Pump Output Drivers: 3 x High-Side Switch 150 mA Transceiver: 1 x LIN2.2 / J2602 Voltage Regulator Output((VCC1)): 5V / 250 mA Wake-up Inputs: Wake Pins, LIN Qualification: Automotive Temperature: - 40°C - 150°C Technology: MOTIX™ SBC Operating Voltage max: 28.0V Supply Voltage max: 28.0V Driving Capability: 90nC at 20kHz Current Sense Amplifier: 1xCSA Temperature max: 150.0°C Classification: ISO26262-ready Family: MOTIX™ motor system ICs (SBC) Currently planned availability until at least: 2038
