AWRL6432AOP

数据:
分类: 微电路 / 半导体集成电路 / 射频电路

描述: 采用封装天线的汽车级单芯片 57GHz 至 64GHz 毫米波雷达传感器

IWRL6432AOP

数据:
分类: 微电路 / 半导体集成电路 / 射频电路

描述: 带集成天线的单芯片低功耗 57GHz 至 64GHz 工业毫米波雷达传感器

Frequency range: 57 - 64 GHz Number of receivers: 3 Number of transmitters: 2 TX power (dBm): 11 Arm CPU: Arm Cortex-M4F at 160 MHz Coprocessors: Radar Hardware Accelerator Interface type: CAN-FD, I2C, QSPI, SPI, UART RAM (kByte): 1024 Operating temperature range (°C): -40 to 105 TI functional safety category: Functional Safety-Compliant Power supply solution: TPS628502-Q1 Rating: Catalog Frequency range: 57 - 64 GHz Number of receivers: 3 Number of transmitters: 2 TX power (dBm): 11 Arm CPU: Arm Cortex-M4F at 160 MHz Coprocessors: Radar Hardware Accelerator Interface type: CAN-FD, I2C, QSPI, SPI, UART RAM (kByte): 1024 更多

Operating temperature range (°C): -40 to 105 TI functional safety category: Functional Safety-Compliant Power supply solution: TPS628502-Q1 Rating: Catalog

AFE7950-SP

数据:
分类: 微电路 / 半导体集成电路 / 射频电路

描述: 耐辐射加固保障 (RHA)、高达 12GHz 的 4 发送、6 接收射频采样收发器

Number of input channels: 6 Resolution (Bits): 14 Sample rate (max) (Msps): 3000 Features: High-performance, Input buffer Analog input BW (MHz): 12000 Power consumption (typ) (mW): 6359 Operating temperature range (°C): -40 to 85 Rating: Space Number of input channels: 6 Resolution (Bits): 14 Sample rate (max) (Msps): 3000 Features: High-performance, Input buffer Analog input BW (MHz): 12000 Power consumption (typ) (mW): 6359 Operating temperature range (°C): -40 to 85 Rating: Space

AWRL6432

数据:
分类: 微电路 / 半导体集成电路 / 射频电路

描述: 单芯片低功耗 57GHz 至 64GHz 汽车级毫米波雷达传感器

Frequency range: 57 - 64 GHz Number of receivers: 3 Number of transmitters: 2 ADC sampling rate (max) (Msps): 12.5 Arm CPU: Arm Cortex-M4F at 160 MHz Interface type: CAN-FD, I2C, LIN, QSPI, SPI, UART Hardware accelerators: Radar hardware accelerator RAM (kByte): 1024 Rating: Automotive Operating temperature range (°C): -40 to 125 TI functional safety category: Functional Safety-Compliant Power supply solution: LP87524B-Q1, LP87524J-Q1, LP87524P-Q1, LP87702-Q1 Frequency range: 57 - 64 GHz Number of receivers: 3 Number of transmitters: 2 ADC sampling rate (max) (Msps): 12.5 Arm CPU: Arm Cortex-M4F at 160 MHz Interface type: CAN-FD, I2C, LIN, QSPI, SPI, UART Hardware accelerators: Radar hardware accelerator RAM (kByte): 1024 更多

Rating: Automotive Operating temperature range (°C): -40 to 125 TI functional safety category: Functional Safety-Compliant Power supply solution: LP87524B-Q1, LP87524J-Q1, LP87524P-Q1, LP87702-Q1

IWRL6432

数据:
分类: 微电路 / 半导体集成电路 / 射频电路

描述: 单芯片低功耗 57GHz 至 64GHz 工业毫米波雷达传感器

Frequency range: 57 - 64 GHz Number of receivers: 3 Number of transmitters: 2 ADC sampling rate (ksps): 12500 TX power (dBm): 11 Arm CPU: Arm Cortex-M4F at 160 MHz Coprocessors: Radar Hardware Accelerator Interface type: CAN-FD, I2C, QSPI, SPI, UART RAM (kByte): 1024 Operating temperature range (°C): -40 to 105 TI functional safety category: Functional Safety-Compliant Power supply solution: TPS628501-Q1, TPS628502-Q1 Rating: Catalog Frequency range: 57 - 64 GHz Number of receivers: 3 Number of transmitters: 2 ADC sampling rate (ksps): 12500 TX power (dBm): 11 Arm CPU: Arm Cortex-M4F at 160 MHz Coprocessors: Radar Hardware Accelerator 更多

Interface type: CAN-FD, I2C, QSPI, SPI, UART RAM (kByte): 1024 Operating temperature range (°C): -40 to 105 TI functional safety category: Functional Safety-Compliant Power supply solution: TPS628501-Q1, TPS628502-Q1 Rating: Catalog

IWR1843AOP

数据:
分类: 微电路 / 半导体集成电路 / 射频电路

描述: 集成封装天线、DSP 和 MCU 的单芯片 76GHz 至 81GHz 工业雷达传感器

Frequency range: 76 - 81 GHz Number of receivers: 4 Number of transmitters: 3 ADC sampling rate (ksps): 25000 TX power (dBm): 12 Arm CPU: ARM R4F @ 200MHz Coprocessors: Radar Hardware Accelerator DSP type: 1 C67x DSP @ 600MHz Interface type: CAN, CAN-FD, I2C, LVDS, QSPI, SPI, UART RAM (kByte): 2048 Operating temperature range (°C): -40 to 105 Power supply solution: LP87702-Q1, LP87745-Q1 Rating: Catalog Frequency range: 76 - 81 GHz Number of receivers: 4 Number of transmitters: 3 ADC sampling rate (ksps): 25000 TX power (dBm): 12 Arm CPU: ARM R4F @ 200MHz Coprocessors: Radar Hardware Accelerator 更多

DSP type: 1 C67x DSP @ 600MHz Interface type: CAN, CAN-FD, I2C, LVDS, QSPI, SPI, UART RAM (kByte): 2048 Operating temperature range (°C): -40 to 105 Power supply solution: LP87702-Q1, LP87745-Q1 Rating: Catalog

AFE7769D

数据:
分类: 微电路 / 半导体集成电路 / 射频电路

描述: 具有双反馈路径和集成 CFR/DPD 的四通道射频收发器

Applications: Wireless infrastructure Number of TXs and RXs: 4 TX Number of DUCs per TX: 1 Number of DDCs per RX: 1 RF frequency (max) (MHz): 6000 RF frequency (min) (MHz): 600 Operating temperature range (°C): -40 to 85 Rating: Catalog Applications: Wireless infrastructure Number of TXs and RXs: 4 TX Number of DUCs per TX: 1 Number of DDCs per RX: 1 RF frequency (max) (MHz): 6000 RF frequency (min) (MHz): 600 Operating temperature range (°C): -40 to 85 Rating: Catalog

AFE7728D

数据:
分类: 微电路 / 半导体集成电路 / 射频电路

描述: 具有双反馈路径和集成 CFR/DPD 的双通道射频收发器 - 200MHz

Applications: Wireless infrastructure Number of TXs and RXs: 2 TX RF frequency (max) (MHz): 6000 RF frequency (min) (MHz): 600 Operating temperature range (°C): -40 to 85 Rating: Catalog Applications: Wireless infrastructure Number of TXs and RXs: 2 TX RF frequency (max) (MHz): 6000 RF frequency (min) (MHz): 600 Operating temperature range (°C): -40 to 85 Rating: Catalog

AFE7768D

数据:
分类: 微电路 / 半导体集成电路 / 射频电路

描述: 具有双反馈路径和集成 CFR/DPD 的四通道射频收发器 - 200MHz

Applications: Wireless infrastructure Number of TXs and RXs: 4 TX RF frequency (max) (MHz): 6000 RF frequency (min) (MHz): 600 Operating temperature range (°C): -40 to 85 Rating: Catalog Applications: Wireless infrastructure Number of TXs and RXs: 4 TX RF frequency (max) (MHz): 6000 RF frequency (min) (MHz): 600 Operating temperature range (°C): -40 to 85 Rating: Catalog

AFE7953

数据:
分类: 微电路 / 半导体集成电路 / 射频电路

描述: 具有 12GSPS DAC 和 3GSPS ADC 的双通道发送、双通道接收、600MHz 至 12GHz 射频采样 AFE

Applications: General purpose Number of TXs and RXs: 2 TX Number of DUCs per TX: 2 Number of DDCs per RX: 2 RF frequency (max) (MHz): 12000 RF frequency (min) (MHz): 600 Operating temperature range (°C): -40 to 85 Rating: Catalog Applications: General purpose Number of TXs and RXs: 2 TX Number of DUCs per TX: 2 Number of DDCs per RX: 2 RF frequency (max) (MHz): 12000 RF frequency (min) (MHz): 600 Operating temperature range (°C): -40 to 85 Rating: Catalog
