ESD155-B2-W0201
数据:
分类: 半导体分立器件和附件 / 二极管 / 普通二极管 / 瞬态抑制二极管
描述: Two line, bi-directional ESD protection device, 3.6 V, 0.18 pF, 0201
Protected Lines: 2
I[R] max: 20.0nA
V[cl typ. reverse](@16A): 5.4V
R[dyn](forward): 0.16Ω
R[dyn](reverse): 0.16Ω
V[ESD] max: 15.0kV
I[EFT ]: 50A
I[PP]: 2A
C[L ]: 0.31pF
V[WM] max: 3.6V
C[L ]: 0.2pF
V[ESD] max: 20.0kV
R[dyn](reverse): 0.45Ω
R[dyn](forward): 0.45Ω
I[R]: 1.0nA
V[cl typ. reverse](TLP 16A): 14
V[cl typ. reverse](TLP 30A): 20
I[EFT ]: 50A
I[PP]: 3A
Protected Lines: 1
V[WM] max: 3.6V
V[WM] max: 5.3V
C[L ]: 0.4pF
V[ESD] max: 20.0kV
R[dyn](reverse): 0.6Ω
R[dyn](forward): 0.5Ω
I[R]: 10.0nA
V[cl typ. reverse](TLP 16A): 19
V[cl typ. reverse](TLP 30A): 28
I[EFT ]: 50A
I[PP]: 3A
Protected Lines: 1
ESD156-B1-W0201
数据:
分类: 半导体分立器件和附件 / 二极管 / 普通二极管 / 瞬态抑制二极管
描述: Bi-directional ESD protection device, 3.6 V, 0.19 pF, 0201
Protected Lines: 1
V[WM] max: 3.6V
I[R]: 0.5nA
V[cl typ. reverse](@16A): 5.3V
R[dyn](forward): 0.16Ω
R[dyn](reverse): 0.16Ω
V[ESD] max: 15.0kV
I[EFT ]: 50A
I[PP]: 2A
C[L ] max: 0.21pF
I[R]: 1.0nA
V[ESD] max: 20.0kV
R[dyn](reverse): 0.45Ω
C[L ]: 0.2pF
R[dyn](forward): 0.45Ω
V[cl typ. reverse](@16A): 14.0V
I[PP]: 3A
I[EFT ]: 50A
V[cl typ. reverse](TLP 30A): 20
Protected Lines: 1
V[cl typ. reverse](TLP 16A): 14
V[WM] max: 3.6V
C[L ]: 0.28pF
V[ESD] max: 25.0kV
I[R] max: 20.0nA
I[EFT ]: 50A
I[PP]: 2.5A
Protected Lines: 1
V[cl typ. reverse]: 20V
V[cl typ. reverse](@16A) max: 20.0V
R[dyn] max: 0.78Ω
V[WM] max: 5.5V
V[WM] min: -5.5V
ESD252-B1-W01005
数据:
分类: 半导体分立器件和附件 / 二极管 / 普通二极管 / 瞬态抑制二极管
描述: High Operating Voltage, Multipurpose, Bi Directional ESD/ Transient Protection Diode (TVS: transient voltage suppressor)
C[L ]: 30.0pF
I[EFT ]: 60A
Protected Lines: 1
R[dyn](reverse): 0.06Ω
R[dyn](forward): 0.06Ω
V[ESD] max: 29.0kV
V[cl typ. reverse](@16A): 5.6V
V[cl typ. reverse](TLP 16A): 5.6V
V[WM] max: 3.3V
I[R]: 1.0nA
I[PP]: 8 A
C[L ]: 0.3pF
V[ESD] max: 18.0kV
R[dyn](forward): 0.8Ω
R[dyn](reverse): 0.8Ω
V[cl typ. reverse](TLP 16A): 27V
V[cl typ. reverse](TLP 30A): 41V
I[R] max: 20.0nA
I[EFT ]: 50A
I[PP]: 2.5A
Protected Lines: 1
V[cl typ. reverse](@16A): 20.0V
V[WM] max: 5.5V
V[WM] min: -5.5V
I[R]: 1.0nA
I[R]: 0.1nA
V[ESD] max: 12.0kV
R[dyn](reverse): 1.5Ω
C[L ]: 0.1pF
R[dyn](forward): 1.5Ω
V[cl typ. reverse](@16A): 29.0V
Protected Lines: 1
V[cl typ. reverse](TLP 16A): 30
V[WM] max: 5.5V
I[EFT ]: 30 A
I[PP]: 2 A
ESD127-U1-W0201
数据:
分类: 半导体分立器件和附件 / 二极管 / 普通二极管 / 瞬态抑制二极管
描述: Uni-directional ESD protection device, 3.3 V, 1 pF, 0201
V[WM] max: 3.3V
I[R] max: 50.0nA
V[cl typ. reverse](@16A): 2.5V
R[dyn](forward): 0.06Ω
R[dyn](reverse): 0.06Ω
V[ESD] max: 20.0kV
I[EFT ]: 60A
I[PP]: 1A
Protected Lines: 1
C[L ] max: 1.0pF
